Dynex DX-PT413 Quick Setup Manual

DX-PT413
4-Outlet 3-USB Power Hub
with Surge Protection
USB ports
AC outlets
Before using your new product, please read these instructions to prevent any damage.
QUICK SETUP GUIDE
Congratulations on your purchase of this Dynex Power Hub with
Surge Protection.
Features
• Three USB charging or power ports, 2.1A total charge
current—Fast charging for multiple smartphones or one tablet.
• 500 joules surge protection—Protects your devices from
damaging power surges and spikes.
• Protected LED indicator—Lights when the surge protection
feature is working properly. If this LED does not light or goes out,
the surge protection feature has reached full capacity and can no
longer absorb additional surges and spikes. The surge protector
should be replaced if this light goes out.
Using your power hub
1 Plug the surge protector into the upper outlet of a standard 120V
AC outlet, with the plastic plug in the ground jack of the lower
outlet.
Plastic plug
2 Plug the power cords from up to four devices into the AC outlets
on the surge protector.
3 The USB ports can be used to charge or power certain USB
devices.
Specifications
• Dimensions (L×W×D): 4.8" × 3.1" × 1.4" (not including plug)
(122.5 × 79 × 35 mm)
Electrical specifications:
• Load rating: 15 amps
• Line voltage: 125V AC @ 60 Hz
• Maximum surge current: 15,000 amps
• Maximum energy dissipation: 500 joules
• Clamping voltage: L-N = 800 volts
• UL-1449 certified
Other specifications:
• Connected equipment limited warranty: $100,000 max
