Dynex DX-U24H41 Quick Setup Manual

Before using your new product, please read these instructions to prevent
any damage.
USB 2.0 4-Port Hub
DX-U24H41
Package contents
• USB 2.0 4-Port Hub
• AC adapter 5V/2A
• USB cable
• Quick Setup Guide
System requirements
• Computer with a USB 2.0 or USB3.0 port
• Latest version of Windows ®8,
Windows® 7, Windows Vista®, or
Windows® XP; or Mac OS X 10.4 or later
• Minimum free disk space: 600MB
recommended
Features
• Complies with USB 2.0
• Compatible with USB 1.1 devices
• Supports transfer rates of up to
480Mbps
• Adds four USB 2.0 ports to your USB
2.0 enabled computer
• Blue LED power indicator
• Supports hot-swappable and Plug &
Play capability
• Supports over-current protection at
USB host port
QUICK SETUP GUIDE
Upstream port (to computer)
LED
Downstream ports (to devices)
Installing your hub
Note: When you connect your hub to a
computer, the computer detects your hub and
automatically installs the driver.
1 Connect the smaller end of the USB
cable to the upstream port on the rear of
the hub and connect the larger end of
the USB cable to an open USB port on
your computer.
2 Plug the AC power adapter into your
hub's DC jack and into a power outlet.
3 Connect your USB devices into your hub.
Note: Do not disconnect from your computer or
USB device during data transfer. Doing so may
corrupt your data or damage your devices.
DC jack
