LAN MAC EEPROM Utility

LAN EEPROM Utility enables to change the MAC address.
Perfer the following steps to use the LAN EEPROM Utility:
1. Create a DOS bootable USB HDD.
2. Copy the AN MAC EEPROM Utility to the HDD and remove the HDD form the computer.
3. Reboot the computer and press F2 during the boot sequence to enter the setup menu.
4. Select the Boot menu item and move the entry "USB HDD" to the first position. Refer to
Boot.
5. Insert the USB HDD and reboot the computer.
6. At the command prompt, navigate to the C Root folder.
7. Open the file Mac.ini, edit the MAC.ini file, change the MAC address, fill in the
xx-xx-xx-xx-xx-xx, and save it.
Current_MAC_address = xx-xx-xx-xx-xx-xx
Command = 00-00-00-4C-14-A0 (Figure 2-31).
Figure 2-31. Edit MAC.ini file
