D H V - 1 5 0 H I n d o o r A i r Q u a l i t y S y s t e m
Installation, Operation & Service Instructions
Table of Contents
1. Specifications ................................................... 1
2. Installation......................................................... 1
2.1 Location ........................................................ 1
2.2 Electrical Requirements ................................ 2
2.3 Condensate Removal.................................... 2
2.4 Ducting ......................................................... 3
2.4A Installing Duct Collars............................. 3
2.4B Ducting for Dehumidification................... 3
2.4C Ducting for Fresh Air .............................. 3
2.4D Constant Airflow Regulator Option.......... 4
2.4E Installation in a basement ....................... 4
2.4F Installation in an attic.............................. 4
2.4G Installation with (2) HVAC systems ......... 4
2.5 Quiet Installation ........................................... 5
3. Operation........................................................... 7
3.1 Humidity/Fan Control Panel .......................... 7
3.3 Humidity Control Adjustment ........................ 7
3.4 Fan/Filter Switch........................................... 7
3.5 Ventilation Timer .......................................... 7
3.6 High Efficiency Air Filter ............................... 8
3.7 Low Pressure Control.................................... 8
4. Maintenance ...................................................... 9
4.1 Standard Air Filter......................................... 9
4.2 High Efficiency Air Filter ............................... 9
4.3 Fresh Air Return ........................................... 9
5. Service............................................................... 9
5.1 Warranty Notice............................................ 9
5.2 Technical description .................................... 9
5.3 Troubleshooting .......................................... 10
5.4 Refrigerant Charging .................................. 11
5.5 Fan Replacement ....................................... 11
5.6 Compressor/Capacitor Replacement........... 11
5.6B Replacing Burned Out Compressor........ 12
5.6C Replacing Compressor-Nonburn Out ...... 12
5.7 Remote Controls......................................... 12
5.7A Humidity Control.................................... 12
5.7B Ventilation Timer ................................... 13
5.8 Defrost Thermostat ..................................... 13
5.9 Electric Ventilation Damper ........................ 13
5.10 Low Pressure Control ................................ 13
5.11 Condensate Pump Kit ............................... 13
6. Electrical Schematic ....................................... 14
7. Pictorial Electrical Diagram............................ 15
8. Service Parts List............................................ 16
9. The DHV-150H ................................................. 16
F:\W06\AldesW06\DOCFILES\782DHV-150HInst.doc
DHV-150H
DEHUMIDIFYING VENTILATOR
Humidity Control Panel ... 7
&
10. Optional Parts List .......................................... 17
11. Accessories..................................................... 17
12.
............................................... 18
Serial No. ________________________________
Purchase Date ____________________________
Dealer's Name ____________________________
Read the installation, operation and maintenance
instructions carefully before installing and using this
unit. Proper adherence to these instructions is essential
to obtain maximum benefit from your DHV-150H
(Dehumidifying Ventilator) Indoor Air Quality System.
1 Specifications
Model: DHV-150H Indoor Air Quality System
Electrical: 110-120 VAC, 12 Amps, 60 Hz, grounded
Capacity: 145 pints/day @ 80 F, 60% RH
Operating Temp. Range: 53 F min., 105 F max.
Air Flow: 400 CFM without external ducting
290 CFM @ .40 IWG external static
Refrigerant Charge: 2 lb., 2 oz. R-22
Duct connections: round 10" & 6" inlets, 10" outlet
Filter Size:
Pleated cloth: 2" X 20" X 24"
High Efficiency: 4" X 20" X 24"
Size (w/o duct collars):
46" long x 25" wide x 20.5 " high
Installed Weight: 145 lb.
2 Installation
2.1 Location
The DHV-150H can be installed in a variety of locations
to meet the owner's needs as listed below. In all cases
keep the following cautions in mind:
Install the unit INDOORS IN A SPACE THAT IS
PROTECTED FROM FREEZING AND
FLOODING.
Install the unit with space to access the front panel
for maintenance and service. Also allow easy
access to the filter cover panel. DO NOT INSTALL
UNIT WITH THE FRONT PANEL OR FILTER
COVER PANEL INACCESSIBLE.
INSTALLATION
OPERATION
MAINTENANCE
782DHV12-00
782DHV150H-10-00
Rev:10/30/2002
Advertisement
Table of Contents
Related Manuals for American Aldes DHV-150H
Summary of Contents for American Aldes DHV-150H
-
Page 1: Table Of Contents
Installed Weight: 145 lb. 2 Installation 2.1 Location The DHV-150H can be installed in a variety of locations to meet the owner's needs as listed below. In all cases keep the following cautions in mind: Install the unit INDOORS IN A SPACE THAT IS PROTECTED FROM FREEZING AND FLOODING. -
Page 2: Electrical Requirements
Use care to keep the hose as flat to the floor as possible, excessive humps will prevent proper drainage. If the DHV-150H is located too far from a drain for the attached hose to reach, inexpensive 1/2" PVC pipe can be used to extend it. It is commonly available in 10' lengths from building supply, plumbing or hardware stores. -
Page 3: Ducting
If fresh make-up air is desired see section 2.4C. The outlet of the DHV-150H is located on the end of the unit. A second 10” round collar is supplied with the unit. Cut and remove the safety grid, then bend the tabs on the collar inside the hole in the cabinet end. -
Page 4: D Constant Airflow Regulator Option
HVAC system. Connect an insulated duct from outside to the 6” collar of the DHV-150H if you wish to provide optional fresh make-up air. Crawl Space Installation: Install a separate return for the DHV-150H in a central area of the structure. -
Page 5: Quiet Installation
A length of 10 feet or more of acoustical flex ducting on the outlet of the DHV-150H will reduce air noise from the fan. A length of flexible ducting on all DHV-150H duct connections is recommended to reduce noise and... - Page 6 Figure 1: DHV-150H in a Basement With a Forced Air System Incorporating a Central Return Figure 2: DHV-150H in an Attic with a Forced Air System Incorporating a Central Return...
-
Page 7: Operation
The DHV-150H can be equipped with various accessories to enhance its operation. A remote control panel must be used with the DHV-150H. There are two remote control panels from which to choose. The humidity/fan control panel is used to control humidity and the fan. -
Page 8: High Efficiency Air Filter
If the timer fails to operate or operates erratically, check that the control panel receives 24Vac from the DHV-150H. If 24Vac is present at the control panel, reset the timer by pressing the reset button at the bottom center of the timer face. The reset button is the small recessed button with an R beneath it located below the 1…7 and h buttons. -
Page 9: Maintenance
To access the air filter, remove the filter access panel from the end of the DHV-150H by unscrewing the two thumbscrews and sliding the panel to the left until it is free from underneath the side panel. The filter(s) should be readily visible and can be removed by pulling them straight out of the DHV-150H. -
Page 10: Troubleshooting
maintain nearly constant pressure and temperature across the entire coil, from inlet to outlet. The mixture of gas and liquid refrigerant enter the accumulator after leaving the evaporator coil. The accumulator prevents any liquid refrigerant from reaching the compressor. The compressor evacuates the cool refrigerant gas from the accumulator and compresses it to a high pressure and temperature to repeat the process. -
Page 11: Refrigerant Charging
6. Turn on the fan switch; the fan should run. Turn off the fan switch. 7. Turn on the humidity control; the compressor and fan should run. 8. If these tests work, the problem is most likely in the field control wiring. 5.4 Refrigerant Charging If the refrigerant charge is lost due to service or a leak, a new charge must be accurately weighed in. -
Page 12: B Replacing Burned Out Compressor
5.7 Remote Controls Devices mounted on a panel that is remote from the unit control the DHV-150H. You may or may not have the devices listed below depending on the model of the remote control panel that you purchased. If the... -
Page 13: B Ventilation Timer
This switch should be installed in series with the field wire that connects the blue (#5) lead from the DHV-150H to the blue (#5) lead on the control panel. If the pump fails, this switch opens the compressor control circuit and stops water production before the reservoir overflows. -
Page 14: Electrical Schematic
Figure 4. Electric Schematics of the DHV-150H... -
Page 15: Pictorial Electrical Diagram
Figure 5: Pictorial Electrical Diagrams of DHV-150H... -
Page 16: Service Parts List
SERVICE PARTS LIST: DHV-150H Indoor Air Quality System ITEM PART NO. AL98996 4017777 4023645 4022595 4022484 4022740 4022563 4021470 4021648 4022563 4024270 4020924 4024360 4022593 4021626 4023875 4023928 4022219 4020623 4022487 4024359 QTY. DESCRIPTION Air Filter, Pleated Cloth Capillary Tube, .059" X .124" X 32.00" (not shown) Compressor Service Kit, Carlyle (EBA120111A) (Includes Compressor, Capacitor &... -
Page 17: Optional Parts List
OPTIONAL PARTS LIST: DHV-150H Indoor Air Quality System ITEM PART NO. QTY. AL98995 AL99027 AL99006 4024155 4024125 4023660 AL23040 4024153 4021495 4024150 4024122 4020554 4022486 AL99982 AL22023 AL16370 AL16371 AL16372 AL16373 DESCRIPTION Air Filter, High Efficiency, Pleated Microglass Paper, 90 -95 Check Damper, 10"... -
Page 18: Limited Warranty
Second through Fifth Year: American ALDES warrants that for a period of five (5) years, the condenser, evaporator, and compressor of the unit will operate free of defect in materials or workmanship, or American ALDES, at its option will repair or replace the defective parts, provided that labor and transportation costs are borne by the end-user. - Page 19 Date Service Notes...
