Specifications - Sharp AD-AT12ST Instruction Manual

5
F
6
b
5
Secure the speaker with the speaker mounting screws
ers F .
6
Connect the cable b to the speaker.
For speaker connections, refer to the operation manual of the unit.
7
Adjust the height of the speaker.
Notes:
A quite heavy load will be applied to the bottom of the stand after the speaker is mounted
on it. Make sure that the position where it is placed is firm and strong enough to support it.
Fasten the screws tight before placing or moving the speaker stand.
Tighten the screws regularly as they may be loosened after mounting
the speaker on it.
If used with the screws loosened, the speaker may fall and cause
injury or damage to people and the speaker itself.
For the speaker direction, refer to the figure.
To adjust the height of the speaker after positioning it, pay attention to cables not to break
them.
Clean the stand with soft cloth dampened with neutral detergent. Never use organic sol-
vents such as benzine, thinner, etc.

Specifications

Load capacity: 1.5 kg (3.3 lbs.) or less
Maximum outside dimensions: 270 mm (W)
(10-11/16" (W)
Weight: Approx. 2.5 kg (5.5 lbs.)
SHARP CORPORATION
7
E
1,104 mm – 746 mm
(43-1/2" – 29-1/2")
E and spring wash-
1,104 mm (H) 270 mm (D)
43-1/2" (H) 10-11/16" (D) )
