Summary of Contents for Samsung WA8034B1
-
Page 1: Table Of Contents
Owner’s Instructions Before operating the unit, please read this manual throughly, and retain for future reference. FEATURES SAFETY INSTRUCTIONS DESCRIPTION OF PARTS CONTROL PANEL WASHING PROCEDURE Fuzzy course Heavy course Speedy course Wool course Saree course Delay start course MANUAL FUNCTIONS INSTALLATION &... -
Page 2: Features
FEATURES FUZZY CONTROL uzzy control operates with best washing course by sensing the washload like artificial intelligence. TRANSPARENT WINDOW This Transparent Window is the new concept to solve the curiosity of users to see inside of washing machine while operation. While operation, the laundry progress inside of washing machine can be checked by looking through the transparent window. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS WARNING! To reduce the risk of fire, electric shock, or injury to persons when using your appliance, take care to adhere to the following precautions. Where an unearthed power cord is not fitted, Place clothes evenly into the washer as unevenly distributed laundry may cause be sure that the washer is grounded. -
Page 4: Description Of Parts
DESCRIPTION OF PARTS Be sure to keep the lid WATER SUPPLY closed during washing HOSE(HOT) and spinning. WATER SUPPLY HOSE (COLD) DRAIN-HOSE (PUMP) SPIN BASKET FABRIC SOFTENER DISPENSER Stainless “CENTER-JET” BLEACH INLET PULSATOR POWER CORD MAGIC FILTER SOUND ABSORPTION Lint will be collected in the PANEL filter during washing. -
Page 5: Control Panel
CONTROL PANEL POWER BUTTON WATER LEVEL SELECT BUTTON Press this button once to operate. According to the washload,select the Press once again to turn the washer off. water level ; START/HOLD BUTTON MEDIUM HIGH EXTRA LOW LOW Use to pause and restart the operation. WATER SUPPLY SELECT BUTTON To change the washing procedure during As you press this button, the type of water... -
Page 6: Washing Procedure
WASHING PROCEDURE Before starting washing, check the following; Connect the water supply hose to the water tap. Leave a tap open. Plug the power cord in. Make sure to lay down the drain hose.(In case no drain pump) Put the laundry into the washer and add detergent,too. Be careful not to overload. -
Page 7: Saree Course
SAREE COURSE DELAY START COURSE Select this course when Select this course when you have to go out or do something else. you have to go out or do something else. Press the power button to "ON". Press the power button to "ON". POWER POWER Press the course... -
Page 8: Installation & Maintenance
INSTALLATION & MAINTENANCE ENVIRONMENT ASSEMBLING THE SOUND ABSORBING PANEL Leave some space Tilt the washer a little and lift up the panel until it clicks, Maintain at least 10cm between the washer and the wall. filnaly fix the panel with screw to the base as shown in the figure. Place the washer on a sturdy flat surface. -
Page 9: Cleaning The Magic Filter
CLEANING THE FILTER NET 1.Push the upper part of 2.Open the cover as 3.Clean the filter. 4. Close the cover and insert the lower part of the filter in the basket first and the filter and pull in. shown in the figure. then push the filter with "click"... -
Page 10: Troubleshooting
TROUBLESHOOTING Washing machine won't work Water dose not drain Is the water tap opened? Is the drain hose down?(No pump) Is the washer plugged in? Is the drain hose frozen? Is the power cut off? Is the drain hose clogged? Is there enough water? If the water dose not drain in 6 minutes, a buzzer will sound,and the...
