Samsung SGH-A110 Service Manual

Samsung SGH-A110 Service Manual

Dual band mobile cellular phone
Hide thumbs Also See for SGH-A110:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
SERVICE
Dual Band Mobile Cellular Phone
DUAL BAND Mobile
Cellular Phone
SGH-A100
SGH-A110
SGH-A188
Manual
CONTENTS
1. Electrical Parts List
2. Exploded Views and Parts List
3. Block Diagram
4. PCB Views
5. Schematic Diagrams

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGH-A110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung SGH-A110

Summary of Contents for Samsung SGH-A110

  • Page 1 DUAL BAND Mobile Cellular Phone SGH-A100 SGH-A110 SGH-A188 SERVICE Manual Dual Band Mobile Cellular Phone CONTENTS 1. Electrical Parts List 2. Exploded Views and Parts List 3. Block Diagram 4. PCB Views 5. Schematic Diagrams...
  • Page 2 ELECTRONICS ©Samsung Electronics Co.,Ltd. August. 2000 Pinted in Korea. Code No.: GH68-01018A BASIC.

  • Page 3: Electrical Parts List

    PMO-REFLECTOR LED SGH-A100, ACRYL, -, -, - GH72-00509A PMO-HINGE DUMMY SGH-A100, POM, BLK, -, - GH75-00147A MEC-SUA. HINGE SCH-A100, -, BLK GH70-00020A IPR-SPRING HINGE SCH-A100, STS304, GH72-00290A PMO-HOUSING HINGE SCH-A100, PC, BLK, -, - SAMSUNG Proprietary-Contents may change without notice...
  • Page 4 PMO-REAR COVER SGH-A100, PC, D/GRY, -, - GH72-00513A PMO-SIM LOCKER SGH-A100, PC, D/GRY, -, - GH72-00514A PMO-IRDA WINDOW SGH-A100, PC, VIO, -, - GH73-00157A RMO-EARPHONE COVER SGH-A100, URETHAN, -, GH99-02189A PAA MAIN-SGH2300 SGH-A100, -, GERM, -, -, -, - SAMSUNG Proprietary-Contents may change without notice...

  • Page 5: C-Ceramic, Chip 0.15Nf, 5 %, 50 V, Np0, Tp

    C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005 2203-001432 C122 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005 2203-001432 C123 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005 SAMSUNG Proprietary-Contents may change without notice...
  • Page 6 C-CERAMIC, CHIP 470pF, 10 %, 50 V, X7R, TP, 1005, - 2203-000812 C313 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005 2203-000812 C314 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005 SAMSUNG Proprietary-Contents may change without notice...
  • Page 7 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005 2203-000359 C403 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005 2203-005065 C404 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608 SAMSUNG Proprietary-Contents may change without notice...

  • Page 8: Table Of Contents

    C-CERAMIC, CHIP 1nF, 10 %, 50 V, X7R, TP, 1005, - 2203-000628 C528 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005 2203-000489 C529 C-CERAMIC, CHIP 2.2nF, 10 %, 50 V, X7R, TP, 1005, - SAMSUNG Proprietary-Contents may change without notice...
  • Page 9 2203-000233 C569 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005 2203-000466 C570 C-CERAMIC, CHIP 0.001nF, 0.25pF, 50 V, NP0, TP, 1005 2203-000466 C571 C-CERAMIC, CHIP 0.001nF, 0.25pF, 50 V, NP0, TP, 1005 SAMSUNG Proprietary-Contents may change without notice...
  • Page 10 C640 C-CERAMIC, CHIP 0.033nF, 5 %, 25 V, NP0, TP, 0603 2203-005683 C643 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603 2203-000812 C644 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005 SAMSUNG Proprietary-Contents may change without notice...

  • Page 11: C-Ceramic, Chip 0.033Nf, 5 %, 50 V, Np0,

    INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8mm 2703-001600 L311 INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8mm 2703-001232 L313 INDUCTOR-SMD 1.5 uH, 10 %, 1.6x0.8x0.8mm 2703-001547 L314 INDUCTOR-SMD 10 nH, 5 %, 1.8x1.12x1.02mm 2703-001547 L315 INDUCTOR-SMD 10 nH, 5 %, 1.8x1.12x1.02mm SAMSUNG Proprietary-Contents may change without notice...
  • Page 12 TR-DIGITAL RN1104, NPN, 100M W, 47K/47K, SSM, TP 0504-000168 Q607 TR-DIGITAL RN1104, NPN, 100M W, 47K/47K, SSM, TP 0501-002202 Q608 TR-SMALL SIGNAL MMBT2222AWT1, NPN, 150m W, 0504-000168 Q609 TR-DIGITAL RN1104, NPN, 100M W, 47K/47K, SSM, TP SAMSUNG Proprietary-Contents may change without notice 1-10...
  • Page 13 R-CHIP 22 ohm, 5 %, 1/16 W, DA, TP, 1005 2007-000172 R312 R-CHIP 10 ohm, 5 %, 1/16 W, DA, TP, 1005 2007-000146 R313 R-CHIP 6.8 kohm, 5 %, 1/16 W, DA, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-11...
  • Page 14 R-CHIP 5.1 kohm, 5 %, 1/16 W, DA, TP, 1005 2007-001305 R521 R-CHIP 120 ohm, 5 %, 1/16 W, DA, TP, 1005 2007-001305 R522 R-CHIP 120 ohm, 5 %, 1/16 W, DA, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-12...
  • Page 15 R-CHIP 12 kohm, 5 %, 1/16 W, DA, TP, 1005 2007-000140 R648 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005 2007-000142 R649 R-CHIP 2.7 kohm, 5 %, 1/16 W, DA, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-13...
  • Page 16 IC-AUDIO AMP 4864, MSOP, 8P, 118MIL, -, -, PLASTIC, 6 V, 0504-001071 U604 TR-DIGITAL UMD9N, NPN/PNP, 150m W, 4.7, UMT6, TP 1203-001515 U605 IC-BATTERY 1510, SSOP, 16P, 150MIL, PLASTIC, 3 0801-002399 U606 IC-CMOS LOGIC TC7S86FU, EX-OR GATE, SSOP, 5P, 11 SAMSUNG Proprietary-Contents may change without notice 1-14...
  • Page 17 DIODE-TVS SMS05C, 6 V, 300 W, SOT-23-6 0406-001051 ZD606 DIODE-TVS SMS05C, 6 V, 300 W, SOT-23-6 0404-001044 ZD608 DIODE-SCHOTTKY UPS5817, 20 V, 1A, SMD, TP 0404-001044 ZD609 DIODE-SCHOTTKY UPS5817, 20 V, 1A, SMD, TP SAMSUNG Proprietary-Contents may change without notice 1-15...
  • Page 18 U505 TR-DIGITAL BCR10PN, NPN/PNP, 250 mW, 10K/10K, 0504-001042 U506 TR-DIGITAL BCR10PN, NPN/PNP, 250 mW, 10K/10K, 0504-001042 U516 TR-DIGITAL BCR10PN, NPN/PNP, 250 mW, 10K/10K, 0504-001071 U604 TR-DIGITAL UMD9N, NPN/PNP, 150 mW, 4.7, UMT6, TP SAMSUNG Proprietary-Contents may change without notice 1-16...
  • Page 19 2007-000140 R651 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 2007-000140 R652 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 2007-000140 R654 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, SAMSUNG Proprietary-Contents may change without notice 1-17...
  • Page 20 2007-000775 R643 R-CHIP 33 kohm, 5 %, 1/16 W, DA, TP, 2007-001119 R614 R-CHIP 680 ohm, 5 %, 1/16 W, DA, TP, 2007-001292 R612 R-CHIP 33 ohm, 5 %, 1/16 W, DA, TP, SAMSUNG Proprietary-Contents may change without notice 1-18...

  • Page 21: C-Ceramic, Chip 0.1Nf, 5 %, 50 V, Np0,

    C-CERAMIC, CHIP 0.1 nF, 5 %, 50 V, NP0, TP, 2203-000233 C510 C-CERAMIC, CHIP 0.1 nF, 5 %, 50 V, NP0, TP, 2203-000233 C544 C-CERAMIC, CHIP 0.1 nF, 5 %, 50 V, NP0, TP, SAMSUNG Proprietary-Contents may change without notice 1-19...
  • Page 22 C-CERAMIC, CHIP 0.022 nF, 5 %, 50 V, NP0, TP, 2203-000628 C526 C-CERAMIC, CHIP 0.022 nF, 5 %, 50 V, NP0, TP, 2203-000628 C528 C-CERAMIC, CHIP 0.022 nF, 5 %, 50 V, NP0, TP, SAMSUNG Proprietary-Contents may change without notice 1-20...
  • Page 23 C-CERAMIC, CHIP 47 nF, +80-20 %, 16 V, Y5 V, TP, 2203-001432 C126 C-CERAMIC, CHIP 47 nF, +80-20 %, 16 V, Y5 V, TP, 2203-001432 C127 C-CERAMIC, CHIP 47 nF, +80-20 %, 16 V, Y5 V, TP, SAMSUNG Proprietary-Contents may change without notice 1-21...
  • Page 24 C-CERAMIC, CHIP 0.033 nF, 5 %, 25 V, NP0, TP, 0603 2203-005682 C650 C-CERAMIC, CHIP 0.033 nF, 5 %, 25 V, NP0, TP, 0603 2203-005683 C625 C-CERAMIC, CHIP 0.008 nF, 0.5 pF, 25 V, NP0, TP, 0603 SAMSUNG Proprietary-Contents may change without notice 1-22...

  • Page 25: C-Ta, Chip 220 Uf, 20 %, 6.3 V, Lz, Tp,

    INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8 mm 2703-001600 L310 INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8 mm 2703-001600 L311 INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8 mm 2703-001708 L505 INDUCTOR-SMD 5.6 nH, 10 %, 1.0x0.5x0.5 mm SAMSUNG Proprietary-Contents may change without notice 1-23...
  • Page 26 GH73-00263A RMO-FOLD HOLDER SGH-A100, RUBBER, -, D/GRY, - GH74-00257A MPR-TAPE WINDOW LCD SGH-A100, TESA, T0.2, TRP, - GH74-00258A MPR-TAPE MOTOR SGH-A100, TESA, T0.4, BLK, - GH74-00259A MPR-TAPE MAGNETIC SGH-A100, TESA, T0.2, TRP, - SAMSUNG Proprietary-Contents may change without notice 1-24...
  • Page 27 GH68-00518B LABEL(P)-SEAL SGH-A100, ART, 100G, 46, 34, -, WHT, -, GH68-00619D LABEL(R)-MAIN(CHNA) SGH-A188, MAT, 0.05, 46.5, 36, -, GH68-01335A LABEL(P)-GSM UNIT BARCODE SGH-A110, ART, 100G, GH68-11057A LABEL(P)-MS BAR CODE SCH-1900, ART, 100 x 155, GH69-00470A BOX(P)-CARTON MAIN GERM, SGH-A100, SW3, GH69-00589A CUSHION-COVER SGH-A188, FROCKING(T0.6), -, -, -,...
  • Page 28 BATTERY-540M, CGR, ENG, MAIN 3.7 V, 540mAH, -, GH44-00103A ADAPTOR-SGHA100 TA SGH-A100, AC/DC, -, 85~265VAC GH44-00139A ADAPTOR-SGHA100 DTC DTCA10G, SGH-A100, -, GH92-00911A PBA MAIN-SGHA110 SGH-A110, -, USA, -, -, -, -, -, - 0401-001033 D201 DIODE-SWITCHING MCL4154, 25 V, 200 mA, M-MELF, TP 0404-000108 ZD407...
  • Page 29 R-CHIP 2 kohm, 5 %, 1/16 W, DA, TP, 1005 2007-000138 R214 R-CHIP 100 ohm, 5 %, 1/16 W, DA, TP, 1005 2007-000138 R322 R-CHIP 100 ohm, 5 %, 1/16 W, DA, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-27...
  • Page 30 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005 2007-000148 R535 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005 2007-000148 R603 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-28...
  • Page 31 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005 2007-001298 R328 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005 2007-001298 R519 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-29...
  • Page 32 R-CHIP 0 ohm, 5 %, 1/16 W, DA, TP, 1005 2007-007833 R406 R-CHIP 0.68 ohm, 2 %, 1/10 W, DA, TP, 2012 2007-007875 R637 R-CHIP 160 kohm, 1 %, 1/16 W, DA, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-30...
  • Page 33 C-CERAMIC, CHIP 0.12 nF, 5 %, 50 V, NP0, TP, 1005 2203-000330 C117 C-CERAMIC, CHIP 0.012 nF, 5 %, 50 V, NP0, TP, 1005 2203-000330 C350 C-CERAMIC, CHIP 0.012 nF, 5 %, 50 V, NP0, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-31...
  • Page 34 C-CERAMIC, CHIP 0.033 nF, 5 %, 50 V, NP0, TP, 1005 2203-000812 C314 C-CERAMIC, CHIP 0.033 nF, 5 %, 50 V, NP0, TP, 1005 2203-000812 C321 C-CERAMIC, CHIP 0.033 nF, 5 %, 50 V, NP0, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-32...
  • Page 35 C-CERAMIC, CHIP 47 nF, +80-20 %, 16 V, Y5 V, TP, 1005 2203-001432 C107 C-CERAMIC, CHIP 47 nF, +80-20 %, 16 V, Y5 V, TP, 1005 2203-001432 C112 C-CERAMIC, CHIP 47 nF, +80-20 %, 16 V, Y5 V, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-33...
  • Page 36 C-CERAMIC, CHIP 0.0047 nF, 0.1 pF, 50 V, NP0, TP, 1005 2203-005446 C303 C-CERAMIC, CHIP 0.0027 nF, 0.1 pF, 50 V, NP0, TP, 1005 2203-005446 C304 C-CERAMIC, CHIP 0.0027 nF, 0.1 pF, 50 V, NP0, TP, 1005 SAMSUNG Proprietary-Contents may change without notice 1-34...
  • Page 37 C-FILM, CHIP 10 nF, 5 %, 16 V, TP, 2012, - 2301-001230 C346 C-FILM, CHIP 10 nF, 5 %, 16 V, TP, 2012, - 2404-001020 C620 C-TA, CHIP 10 uF, 20 %, 10 V, GP, TP, 3216, 3.2 SAMSUNG Proprietary-Contents may change without notice 1-35...
  • Page 38 INDUCTOR-SMD 6.8 nH, 10 %, 1.6 x 0.8 x 0.8 mm 2703-001600 L310 INDUCTOR-SMD 6.8 nH, 10 %, 1.6 x 0.8 x 0.8 mm 2703-001600 L311 INDUCTOR-SMD 6.8 nH, 10 %, 1.6 x 0.8 x 0.8 mm SAMSUNG Proprietary-Contents may change without notice 1-36...
  • Page 39 CONNECTOR-HEADER BOX, 30P, 2R, 0.5 mm, SMD-S, 3722-001456 CN604 JACK-PHONE 2P, 2.6PI, AUF, BLK, - 4302-001081 BAT1 BATTERY-LI(2ND) -, .25MAH, COIN, 0.03 mA, -, - 4709-001144 U503 COUPLER-DIRECTION 897.5/1747.5 MHz, 19DB/14DB, GH96-00894A ELA ETC-SGHA100 EAR-MIC SGH-A100, -, USA, SAMSUNG Proprietary-Contents may change without notice 1-37...

  • Page 40: Exploded View And Its Parts List

    2. Exploded View and its Parts List 2-1 SGH-A100/A110/A188 Cellular phone Exploded View SAMSUNG Proprietary-Contents may change without notice...
  • Page 41 GH92-00724A NPR-ANTENNA BUSHING GH71-00076A GH71-00076A GH71-00076A ANTENNA GH42-00042B GH42-00042A GH42-00042C MEC-REAR-COVER GH75-00320B GH75-00320A GH75-00320C 16-1 RMO-EAR-JACK GH73-00157A GH73-00157A GH73-00157B SCREW-MACHINE 6001-001148 6001-001148 6001-001148 BATTERY GH43-00200A GH43-00199A GH43-00218A 540 mAH GH43-00156A GH43-00155A GH43-00217A 915 mAH SAMSUNG Proprietary-Contents may change without notice...
  • Page 42 Exploded view and its Part List 2-3 SGH-A110 Cellular phone Parts List (Silver) DESCRIPTION SEC.CODE REMARK SCREW-MACHINE 6001-000876 2PCS MEC-FOLDER-UPPER GH75-00318R DISPLAY-LCD GH96-00808A MOTOR GH31-00003A SPEAKER 3001-001126 WINDOW-LCD GH72-00515C MEC-FOLDER LOWER GH75-00319B MEC-FRONT COVER GH75-00316B RMO-VOLUME KEY GH72-00510C RMO-KEY PAD-RUBBER...
  • Page 43 GH92-00906A NPR-ANTENNA BUSHING GH71-00076A GH71-00076A GH71-00076A ANTENNA GH42-00042B GH42-00042A GH42-00042D MEC-REAR-COVER GH75-00320B GH75-00320A GH75-00320D 16-1 RMO-EAR-JACK GH73-00157D GH73-00157D GH73-00157D SCREW-MACHINE 6001-001148 6001-001148 6001-001148 BATTERY GH43-00258A GH43-00257A GH43-00256A 570 mAH GH43-00156B GH43-00155B GH43-00241A 917 mAH SAMSUNG Proprietary-Contents may change without notice...
  • Page 44 Exploded view and its Part List 2-5 Test Jig (GH80-00161A) SWITCH MODE AUTO DOWNLOAD DEBUG DEBUG HIGH HIGH CONNECT HIGH HIGH CONNECT SAMSUNG Proprietary-Contents may change without notice...
  • Page 45 Exploded view and its Part List 2-6 RF Cable 2-7 Test Cable (GH39-00002A) (GH39-00042A) 2-8 Cigarette Lighter Adaptor 2-9 SGH-A100/A110 Travel Adaptor (GH44-00112A) (GH44-00103A) 2-8 SGH-A188 Travel Adaptor (GH44-00103C) SAMSUNG Proprietary-Contents may change without notice...
  • Page 46 Exploded view and its Part List 2-10 Test Connection Method SAMSUNG Proprietary-Contents may change without notice...
  • Page 47 V t est R m t _Ct l Audi o ci r c ui t Si m _Dat Si m _En Dai _R eset Cl k _Rqst D ai _Cl k Boost _E n SAMSUNG Proprietary-Contents may change without notice...
  • Page 48 4. PCB Diagrams 4-1 SGH-A100 Main PCB Top Diagram SAMSUNG Proprietary-Contents may change without notice...
  • Page 49 PCB diagrams 4-2 SGH-A110/SGH-A188 Main PCB Top Diagram Samsung Electronics...
  • Page 50 PCB diagrams 4-3 SGH-A100 Main PCB Bottom Diagram Samsung Electronics...
  • Page 51 PCB diagrams 4-4 SGH-A110/SGH-A188 Main PCB Bottom Diagram Samsung Electronics...
  • Page 52 5. Circuit Diagrams 5-1 SGH-A100 Integrated Analog Circuit Diagram 2 0 0 0 . 0 3 . 0 7 SAMSUNG Proprietary-Contents may change without notice...
  • Page 53 Circuit diagrams 5-2 SGH-A110 Integrated Analog Circuit Diagram SGH-A110 Integrated Analog Circuit Diagram REV: 2000.6.12 MP1.3 Samsung Electronics...
  • Page 54 Circuit diagrams 5-3 SGH-A188 Integrated Analog Circuit Diagram SGH-A188 Integrated Analog Circuit Diagram REV: 2000.6.12 MP1.4 Samsung Electronics...
  • Page 55 Circuit diagrams 5-4 SGH-A100 M46 Asic Circuit Diagram 2 0 0 0 . 0 3 . 0 7 Samsung Electronics...
  • Page 56 Circuit diagrams 5-5 SGH-A110 M46 Asic Circuit Diagram SGH-A1 SGH-A110 M46 Asic Circuit Diagram Asic Circuit Diagram REV: 2000.6.12 MP1.3 Samsung Electronics...
  • Page 57 Circuit diagrams 5-6 SGH-A188 M46 Asic Circuit Diagram SGH-A188 M46 Asic Circuit Diagram REV: 2000.6.12 MP1.4 Samsung Electronics...
  • Page 58 Circuit diagrams 5-7 SGH-A100 Dual Synthesizer Circuit Diagram 2 0 0 . 0 3 . 0 7 Samsung Electronics...
  • Page 59 Circuit diagrams 5-8 SGH-A110 Dual Synthesizer Circuit Diagram SGH-A110 Dual Synthesizer + Transceiver Circuit Diagram REV: 2000.6.12 MP1.3 Samsung Electronics...
  • Page 60 Circuit diagrams 5-9 SGH-A188 Dual Synthesizer Circuit Diagram SGH-A188 Dual Synthesizer + Transceiver Circuit Diagram REV: 2000.6.12 MP1.4 Samsung Electronics...
  • Page 61 Circuit diagrams 5-10 SGH-A100 Power Management Circuit Diagram 2 0 0 0 . 0 3 . 0 7 Samsung Electronics 5-10...
  • Page 62 Circuit diagrams 5-11 SGH-A110 Power Management Circuit Diagram SGH-A110 Power Managenemt Circuit Diagram REV: 2000.6.12 MP1.3 Samsung Electronics 5-11...
  • Page 63 Circuit diagrams 5-12 SGH-A188 Power Management Circuit Diagram SGH-A188 Power Managenemt Circuit Diagram 2000.6.12 MP1.4 Samsung Electronics 5-12...
  • Page 64 T r a n s m i t / R e c e i v e S w i t c h M em or y T r a n s m i t t e r Samsung Electronics 5-13...
  • Page 65 Circuit diagrams 5-14 SGH-A110 Transmit/Receive Switch, Transmitter, Receiver FrontEnd, Memory Circuit Diagram Receiver Front End Transmit / Receive Switch Memory Transmitter SGH-A188 Transmit / Receive Switch Transmitter Receiver Front End Memory Circuit Diagram REV: 2000.6.12 MP1.3 Samsung Electronics 5-14...
  • Page 66 Circuit diagrams 5-15 SGH-A188 Transmit/Receive Switch, Transmitter, Receiver FrontEnd, Memory Circuit Diagram Receiver Front End Transmit / Receive Switch Memory Transmitter SGH-A188 Transmit / Receive Switch Transmitter Receiver Front End Memory Circuit Diagram REV: 2000.6.12 MP1.4 Samsung Electronics 5-15...
  • Page 67 Circuit diagrams 5-16 SGH-A100 MMI Circuit Diagram Samsung Electronics 5-16...
  • Page 68 Circuit diagrams 5-17 SGH-A110 MMI Circuit Diagram SGH-A110 MMI and System Connector Interface MMI and System Connector Interface Circuit Diagram REV: 2000.6.12 MP1.3 Samsung Electronics 5-17...
  • Page 69 Circuit diagrams 5-18 SGH-A188 MMI Circuit Diagram SGH-A188 MMI and System Connector Interface MMI and System Connector Interface Circuit Diagram REV: 2000.6.12 MP1.4 Samsung Electronics 5-18...
