Traffic Display Legend

Viewing Incident Details:
To view the incident details, use the
Interface Dial to position the cursor
(round red circle) over an incident icon
and push in.
Incident Icons
Accident / Incident (other)
Construction Weather
Road Closed
Incident Icon Update Details:
• Typically M–F, 5:00 AM – 7:00
PM (varies by metropolitan area)
• Continuously updated
Map Scale
Traffic flow and incident icons are
displayed on the 5 mile (8 km) or
less map scale.
NOTE:
When driving to a destination on freeways that have traffic flow data, the route line is
used to display moderate and heavy traffic flow status instead of the colored bands
on the side of the road. The route line color indicates the following conditions:
• Free Flow Traffic - a section of the blue route line will be bordered with a light
green line (this may be difficult to see)
• Moderate Traffic Flow - a section of the route line will change from blue to
orange
• Heavy Traffic Flow - a section of the route line will change from blue to red
• Unknown Traffic Flow - a section of the route line is blue
20mi
2010 TSX
Getting Started
Hearing Incident Details:
To have the message read to you, push in on
the Interface Dial a second time.
To return to current position, say or select
Return.
Traffic Flow Data
(using bands parallel to the road)
Heavy traffic: 0 – 24 mph
Moderate traffic: 25 – 45 mph
Free flow traffic: 45+ mph
(shown for both sides of the freeway where
available)
Traffic Flow Data Update Details:
• Available 24 hours a day, 7 days a week
• Continuously updated
Navigation System
21
