Presets - LinPlug SaxLab User Manual

Presets

SaxLab 2's Presets section is located on the upper right of the instrument's
Front Panel. The Preset section contains the Preset Display and File Browser
as well as the MIDI Learn ECS.
Preset Display/File Browser
Preset Display/File Browser: The Preset Display consists of two displays. The
upper one shows the Current Bank and the lower one shows the Current
Preset. Whenever a new Preset is loaded using the file controls found below
these displays, the Current Preset display is updated with the name of the
new Preset and the Current Bank is updated with the name of the directory
that contains the new Preset.
By default the File Browser points to the factory presets installed with SaxLab
2. Presets can be changed in three different ways. A new Preset can be
loaded using the file controls, which work by clicking the Prev/Next ("arrow")
buttons located below the Current Preset display. Alternatively, the desired
Preset can be selected directly from the Current Preset display, which turns
into a menu when it is clicked. A Preset can also be changed by sending a
MIDI program change command to the instrument.
The Current Bank can be changed by loading a Preset from a different
directory or by selecting the desired location from the Current Bank display,
which turns into a menu when it is clicked.
LinPlug SaxLab User Guide 2.0.3
15
