- Page 1 MICROWA VE OVEN KOG-371H OPERATING INSTRUCTIONS Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. -
Page 3: Earthing Instructions
EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. -
Page 4: Specifications
SPECIFICATIONS POWER SUPPLY 230V~50Hz, SINGLE PHASE WITH EARTHING MICROWAVE 1200 W POWER GRILL 1050 W CONSUMPTION COMBINATION 2200 W MICROWAVE ENERGY OUTPUT 800W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (WXHXD) 465X279X360mm CAVITY DIMENSIONS (WXHXD) 290X220X306mm NET WEIGHT APPROX. 13.7Kg TIMER 59 min. 90 sec. POWER SELECTIONS 10 LEVELS CAVITY VOLUME... -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven: 1. Do not use the oven for any reason other than food 11. -
Page 6: Features Diagram
FEATURES DIAGRAM 1. Door seal - Door seal maintains the 8. Coupler - This fits over the shaft in the center microwave energy within the oven cavity and of the ovens cavity floor. This is to remain in prevents microwave leakage. the oven for all cooking. - Page 7 FEATURES DIAGRAM (continued) Def. Grill Combi Timer/g Frozen Pizza Fresh Vegetable Beverage Dish Warmer Pasta Auto Defrost Fish Poultry Meat COMBI GRILL Defrost Kitchen Power Clock Timer STOP/ START/ CLEAR SPEEDY COOK 13. Time set pad-Used to set the cooking time 20.
-
Page 8: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. a. Plug power supply cord into a 230V 50Hz power outlet. b. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 9: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever goes off, the display shows “ : 0” when the power comes back on. 1. -
Page 10: Weight Defrosting
WEIGHT DEFROSTING Auto Defrost lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch Meat pad. The Timer/g indicator light and “ 500 ” is displayed. Meat 2. Select the desired defrosting weight. The display will show what you touched. -
Page 11: Cooking In One Stage
COOKING IN ONE STAGE 1. Touch Power pad. The M/W indicator lights. (Select the desired power The display will show what you touched. Power level.) This example shows power level 5. Note : If steps 1 and 2 are omitted, the oven will cook at full power. -
Page 12: Grill Cooking
GRILL COOKING This function allows you to brown food quickly. The heating element is located in the top of the oven. There is no pre-heating the oven for grill cooking. Place food inside the oven when setting the controls. 1. Touch GRILL pad. The Grill indicator lights and “... -
Page 13: Kitchen Timer Mode
KITCHEN TIMER MODE Timer operates as a minute timer, can be set to delay cooking and used to set a holding time after cooking. However delay cooking can not be programmed for defrost. Timer operates without microwave energy. HOW TO USE AS A MINUTE TIMER 1. -
Page 14: Speedy Cook
SPEEDY COOK SPEEDY COOK allows you to reheat for 30 seconds at 100% (full power) by simply touching the SPEEDY COOK pad. By repeatedly touching the SPEEDY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments. - Page 15 ONE TOUCH COOKING (continued) 1. Touch Beverage pad once for When you touch Beverage pad once, “ 1 ” is Beverage 1 cup, twice for 2 cups or three displayed. times for 3 cups. After 1.5 seconds, the display is changed into cooking time and the oven starts cooking.
-
Page 16: Less, More
LESS, MORE To alter one touch cooking or cooking time whilst oven is in operation, use LESS or MORE.(except for defrosting) Press LESS/MORE to decrease/increase the one touch cooking time in multiples of 10 seconds. The overall one touch cooking time can be increased to a maximum of 59 minutes 50 seconds. Press LESS/MORE to decrease/increase the cooking time in multiples of 1 minute. -
Page 17: Cooking Utensils
COOKING UTENSILS Utensils should be checked to ensure that they are suitable for use in microwave ovens. Microwave energy is produced by high frequency radio waves. They are reflected from metal, but will pass through most cooking utensils without heating them. As the waves come into contact with the food, they are converted into heat energy. -
Page 18: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn’t work : 1. Check that the power cord is securely plugged in. 2. Check that the door is firmly closed. 3.
