Service Manual
AKL-3010RC
Cassette Player/Receiver with 4-Channel High Power Output
Full Detachable Face Panel
4-Channel high Power (40W 4Ch)
Electronic Tuning
Electronic Volume/Bass/Treble/Balance/ Fader
30Memory Capability (18FM+6MW+6LW)
Local/DX Switch
Loudness
Detachable Face for Anti-Theft
Logical cassette player
INSTRUCTION MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo AKL-3010RC
Summary of Contents for Daewoo AKL-3010RC
- Page 1 AKL-3010RC Cassette Player/Receiver with 4-Channel High Power Output Full Detachable Face Panel 4-Channel high Power (40W 4Ch) Electronic Tuning Electronic Volume/Bass/Treble/Balance/ Fader 30Memory Capability (18FM+6MW+6LW) Local/DX Switch Loudness Detachable Face for Anti-Theft Logical cassette player INSTRUCTION MANUAL...
-
Page 2: Wiring Connections
WIRING CONNECTIONS The pins in the ISO connector have the following functions (connector seen from the rear) A. ELECTRIC CONNECTIONS 4. Back-up+12V : YELLOW 5. +12V (electric antenna) : BLUE 6. Dimmer : PINK 7. +12V supply(from ignition lock) : RED 8. - Page 3 ASSEMBLY & REMOVAL OF THE APPARATUS NOTE ! Press knob(1) and remove front panel(2). (Always take the Only use the enclosed mounting components. Foreign cassette out first). Insert the enclosed handles(3) into the cutouts in components can upset operation. the apparatus, as in the figure, press the handles up somewhat so Please refer to your nearest dealer if you get any problems with that the lock tabs release and pull the apparatus out of the holder.
-
Page 4: Front Panel
FRONT PANEL Replacement of the front panel 1. Hold the panel at its top and bottom edges. 2. Press the left side of the panel in first. Then press the right-hand side in. Keep in mind: If any function does not work, take the panel off and put it back again. - Page 5 FUNCTION DESCRIPTION, CONTROLS 10 9 8 1. POWER ON / OFF 11. TAPE LOADING SLOT 2. AUDIO SELECTOR 12. TAPE EJECTION 3. TUNING AND TRACK UP / DOWN 13. TAPE FUNCTION 4. BAND CONTROL 14. AMS(AT TAPE MODE) / TOP 5.
- Page 6 RADIO 1. POWER ON/OFF (POWER, 1) 3. TUNING UP/DOWN CONTROL ( To switch the audio system off, press power button lightly. During the radio mode Simultaneously, the system memorizes all information about its Press the tuning up/down arrows( ) for less than 0.7 current setting, and restores the information when you turn the seconds to choose the radio station which you want to listen to system on by pressing the power on/off button again.
- Page 7 RADIO 5. PRESET STATION (Button 1-6, 5) 8. DISPLAY CONTROL (DISP, 8) Any station may be preset into these buttons by simply pressing When pressed belower than 1.5 seconds. and holding the buttons down for 2 seconds. Up to 18 FM (6 in present clock is displayed.
-
Page 8: Using The Rds Functions
RADIO USING THE RDS FUNCTIONS What is RDS? RDS digital data includes various data : The RDS(Radio Data System) is a digital information system PI ... Program Identification developed by the EBU(European Broadcasting Union). Pick-a- Recognizes the country code and the program of the channel. backed on normal FM broadcasts, RDS offers a variety of PS ... - Page 9 RADIO USING THE RDS FUNCTIONS 9. AF(network following) reception (AF, 9 ) The AF-function is only possible with FM. To select AF-function This unit returns to the stronger alternative transmitter in the list of switch to FM and press the button AF/REG for about 1.5 seconds. alternative frequencies(AF).
- Page 10 RADIO USING THE RDS FUNCTIONS 10. Traffic broadcast recognition (TA, 10) Change-over to regional program (REG, 10) At certain times some national radio stations broadcast regional If the button “TA/TPST” is pressed for less than 1.5 seconds, program. It is possible to pre-tune these station by pressing RDS-stations transmitting traffic information can be heard.
- Page 11 RADIO USING THE RDS FUNCTIONS What is EON? Traffic information recognition (TP, 10) If the RDS-station tuned on, the unit recognizes RDS-frequencies EON(Enhanced Other Network) is a new RDS service provided with traffic information(TP). “TP” will be indicated on the display in by certain station networks.
- Page 12 RADIO USING THE RDS FUNCTIONS Selecting the PTY function Program types Display Program types Display Depress the button for approx. 2 seconds to tune on the PTY- function. If the station just receives a PTY-program the indication Speech SPEECH Science SCIENCE of the program name lights in the display window.
-
Page 13: Cassette Player
CASSETTE PLAYER Listening to a tape 12. Tape ejection ( , 12 ) Insert a cassette tape. Press the “ ” button to remove your tape from the unit. Playback will start automatically 13. TAPE Button (TAPE, 13) If a cassette tape is already If a cassette tape is already inserted, press the this button. -
Page 14: Cd Changer Operation
CD CHANGER OPERATION To go to the beginning of a desired track DESIRED TRACK PRESSING SIDE 16. Automatic Music Search (AMS, 14) During playback, press the preset button 1 momentarily. Next track Track-Up ( Note: - The AMS function may not work when Proceeding track Track-Down ( - the blanks between tracks are shorter than 4 seconds... -
Page 15: Technical Specification
TECHNICAL SPECIFICATION GENERAL TAPE SECTION Power supply 13.8V DC(10.8-15.6 allowable) Wow and Flutter 0.35% Speaker impedance 4 or 8 ohm Signal to Noise ratio 50dB Output Power Maximum 40W 4CH Channel Separation 35dB Current Drain Frequency Response 63Hz-10KHz( 3dB) Tape Speed 4.75cm/sec Escutcheon (W D H)
