Page 1: Instruction Manual
Colour Television Instruction Manual MODEL NO. : DTK-28_ DTM-28_ DTM-29_ Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories. -
Page 2: L L Identity Of Features On Local And Remote Control
IDENTITY OF FEATURES ON LOCAL AND REMOTE CONTROL LOCAL CONTROL MAIN VIDEO AUDIO TV/AV VOLUME PROGRAMME AERIAL SCART SCART S-VHS HEAD- INDICATOR REMOTE POWER INPUT INPUT INPUT (Menu) DOWN/UP DOWN/UP TERMINAL SOCKET 1 SOCKET 2 PHONE SENSOR BUTTON (DTM-28_) BUTTON BUTTON (DTM-29_) REMOTE CONTROL... -
Page 3: Table Of Contents
CONTENTS L L IDENTITY OF FEATURES ON LOCAL AND REMOTE CONTROL L L IMPORTANT SAFEGUARDS L L INSTALLATION -Inserting Batteries into the Remote Control Unit -Aerial connection -Mains connection -Switching the set on and off -On screen display menu -Language selection -Automatic Tuning the TV Channels -Programme Edit -Manual Channel Setting... -
Page 4: Inserting Batteries Into The Remote Control Unit
INSTALLATION If the set is moved or placed in a different direction, the MAIN POWER button must be switched off for at least 15 minutes in order to take out a colour strain on the screen. INSERTING BATTERIES INTO THE REMOTE CONTROL UNIT Press down the battery compartment grip and slide the cover. -
Page 5: Switching The Set On And Off
SWITCHING THE SET ON AND OFF Switching On • Switch the set on with the MAIN POWER (ON/OFF) button. The INDICATOR will illuminate in Red. That means the set is on stand-by mode. • Press PR UP or DOWN button on the front of set or POWER button( ) or PR UP/DOWN button or one of the NUMBER button (0..9) on the remote controller. -
Page 6: Programme Edit
• Press the RIGHT button. Auto setup will begin, your stations will be located and stored. Please wait! • Please wait until the Edit menu appears. If you don’t want to edit programme now, escape from menu with the MENU button. -
Page 7: Manual Channel Setting
MANUAL CHANNEL SETTING Install • Press the NUMBER buttons (0..9) or the UP / DOWN button to select a pro- Auto Setup gramme number you want. Manual Tune • Locate the selection bar on the Manual tune at the Install menu. Fine Tune Edit •... -
Page 8: L L Daily Use
DAILY USE RECALL The RECALL button is used to display the current status: programme number, station name, sound system, clock. This display appear for 2 seconds. SELECTING A PROGRAMME NUMBER The set has totally 100 programme numbers, 0..99. The NUMBER buttons 0..9 are used for direct programme selection. To select two-digit programme, press the second numbered button within two seconds. -
Page 9: Timer
SOUND CONTROL • Press the MENU button. • Place the selection bar to the Sound with UP/DOWN button. Sound • Press the RIGHT button to call up Sound menu. Equalizer • Select the required function by moving the selection bar ith the UP / Effects Balance DOWN buttons. -
Page 10: Child Lock
Automatic clock setting and correction Even though you turn the TV off with MAIN POWER (ON/OFF) button, if you select a programme of your country which has Teletext or PDC transmission, clock will be set and corrected automatically. This function is only available for the countries as follows: Deutschland, Great Britain, France, Italy, Sweden, Switzerland, Netherlands, Ireland SETTING THE WAKE UP TIME / PROGRAMME... -
Page 11: L L Teletext
TELETEXT SWITCHING TELETEXT ON/OFF Press the TEXT button( The index page or the page viewed last will appear. Press the TEXT button again to return to the TV mode. COLOUR BUTTONS IN TOP/FLOF TELETEXT A red, green, yellow and blue field is shown at the bottom of the screen. If TOP or FLOF Teletext is transmitted by the station, pressing the correspond- ing colour button on the remote controller, you can select the desired page eas- ily. -
Page 12: L L Connecting The External Equipment
BRIGHTNESS AND CONTRAST CONTROL IN TELETEXT MODE Pressing the MENU button repeatdely in teletext mode, the brightness and contrast control menu will be displayed in the bottom of the screen. You can adjust these using the LEFT/RIGHT button on the remote con- troller.
