Service Guide
Colour Television
CHASSIS : CP-002
Model :
DTC-14 V1/V3/V4/V5/U1 TM
DTC-20 V1/V3/V4/V5/U1 TM
DTC-21 V1/V3/V4/U1/U3 TM
14/20/21 V1
14/20 V5
If you need further information ( IC, Circuit descriptions or
troubleshooting . . .) about this model,
Please visit our web site.( http://svc.dwe.co.kr)
Specifications
PAL/SECAM-B/G, D/K, I, H, NTSC-3.58/4.43, NTSC-5.5
TV Standard
100 ~ 250V AC, 50/60Hz
Mains Voltage
14" : 73W 20" : 78W
Power Voltage
16" : 75W 21" : 86W
- . 2 Speaker (at any MOD. 10% THD )
Sound output
Speaker
- . 2 Speaker : 7.5W 4 ohm
Memory channel
100 channels
Reception
VHF - L : CH2 - CH4
VHF - H : CH5 - CH12
channel Unit
Cable Band : CHS1' - CHS3', CHS1 - CHS20
Hyper Band : CHS21 - CHS40
UHF : CH21 - CH69
VG : R-28B04, TM : R-28B03
Remote control
Function
-. CHILD Lock (CH Lock)
-. 16 : 9 MODE
-. ZOOM MODE
-. Blue Back (ON/OFF)
-. Local Key Menu Control
-. Arrow puzzle Game
-. Monitor out
-. Simple SCART
-. Twitter Speaker
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/G No. : CP002P-010G1
14/20/21 V3
14/20/21 U1
: 5W + 5W (TWITTER 2.5W + 2.5W)
VG
-. CHILD Lock (Security code Lock)
-. OSD MESH
-. 16 : 9 MODE
-. ZOOM MODE
-. Blue Back (ON/OFF)
-. Local Key Control Menu Control
-. Monitor out
-. Simple SCART
-. Twitter Speaker
-. TELETEXT : 8 PAGE TELETEXT
14/20/21 V4
21 U3
TM
TOP/FLOF MODE
JAN. 2000
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo DTC-14
Summary of Contents for Daewoo DTC-14
-
Page 1: Specifications
S/G No. : CP002P-010G1 Service Guide Colour Television CHASSIS : CP-002 Model : DTC-14 V1/V3/V4/V5/U1 TM DTC-20 V1/V3/V4/V5/U1 TM DTC-21 V1/V3/V4/U1/U3 TM 14/20/21 V4 14/20/21 V1 14/20/21 V3 14/20 V5 14/20/21 U1 21 U3 If you need further information ( IC, Circuit descriptions or troubleshooting . -
Page 2: Important Service Notes
DAEWOO ELECTRONICS CO., LTD. is safe to operate without danger of electrical shock. Plug the AC line cord C.P.OBOX8003 SEOUL, KOREA... -
Page 3: Alignment Instructions
Alignment Instructions 1. AFT 1) Set a signal Generator with - RF FREQUENCY = 38.9MHz, 34.2MHz (L’ ) - RF OUTPUT LEVEL = 80 5dBuV - System = PAL / SECAM - B/G, D/K, I, H NTSC - 3.58/4.43 2) Connect the Signal Generator RF Output to P101 (Tuner IF Output). There must be no signal input to the tuner. - Page 4 6.3 HORIZONTAL CENTER 1) Apply a RETMA PATTERN signal. 2) Adjust picture centering with H-CENTER LEFT/RIGHT keys. 7. DATA PRESET(D.P) ADJUSTMENTS 1) Receive a 91 channel. 2) Adjust the SHARPNESS to 0. 3) Enter the service mode using the user remote control by pressing buttons in sequence as follows R ---->...
-
Page 5: Teletext Mode
TV mode TELETEXT mode POWER POWER NUMBER 0-9 NORMAL NUMBER 0-9 INDEX PR(CURSOR) UP PAGE UP VOLUME UP NORMAL/OK SUBPAGE (CURSOR RIGHT) MENU MENU PAGE DOWN PR(CURSOR ) DOWN MENU HOLD VOLUME DOWN (CURSOR LEFT) MUTE REVEAL MUTE RECALL SIZE CANCEAL SLEEP Not Used... - Page 6 Service MODE OSD R BIAS G BIAS B BIAS R DRIVE G DRIVE B DRIVE V CENTER ?? V SIZE H CENTER ?? FINE POW LAST OFF SUB BRI OUTPUT MONI BRIGHT CONTRAST 54 COLOUR...
-
Page 7: Service Parts List
Service Parts List ® is a recommendable part for stock. is safety component, so it must be used the same component. PART CODE PART NAME PART DESCRIPTION REMARK PART CODE PART NAME PART DESCRIPTION REMARK PART CODE PART NAME PART DESCRIPTION REMARK PART CODE PART NAME... - Page 8 PART CODE PART NAME PART DESCRIPTION REMARK PART CODE PART NAME PART DESCRIPTION REMARK PART CODE PART NAME PART DESCRIPTION REMARK PART CODE PART NAME PART DESCRIPTION REMARK CC534 HCFK334ZCA C CHIP CERA 50V Y5V 0.33MF Z 2012 F801B 4857415001 CLIP FUSE PFC5000-0702 L805...
- Page 9 PART CODE PART NAME PART DESCRIPTION REMARK PART CODE PART NAME PART DESCRIPTION REMARK PART CODE PART NAME PART DESCRIPTION REMARK RC304 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012 14" RC605 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012 SF102 5PK9652M-- FILTER SAW...
- Page 10 Inch Different Parts List INCH PART CODE PART NAME PART DESCRIPTION REMARK INCH PART CODE PART NAME PART DESCRIPTION REMARK CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP 48519A4710 CRT GROUND NET 1401S-1015-1P C304 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP ZZ131 48519A5110 CRT GROUND NET...
- Page 12 : Video : Audio...
