  • Page 1 P/N:48586113E101-R2...
  • Page 2 REAR PROJECTION TV INSTRUCTION MANUAL DJ - 4710 / 5510 DJ - 4720 / 5520 DJ - 4710E / 5510E DJ - 4720E / 5520E DSJ-4710CRM / 5510CRM DSJ-4720CRM / 5520CRM...
  • Page 3 PROJECTION TV CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 4: Important Safeguards

    IMPORTANT SAFEGUARDS Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. Read, Retain and Follow All Instructions Read all safety and operating instructions before operating the TV. Retain the safety and operating instructions for future reference.

  • Page 5: Replacement Parts

    12. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
  • Page 6 Warning This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user's own safety, and the proper operation of the product. In case of an accident, please unplug the unit from the outlet immediately. To reduce the risk of electric shock, do not Do not put any object that contains water - remove cover or back.
  • Page 7 Caution Please keep the user's manual in a safe place for future reference. This section must be read carefully and followed by the user when installing and transporting the product. Do not put volatile substance-such as Do not put a magnetic related substance, or Do not expose the product to a dusty or benzene, naphtha- near the product since it telephone near the product since it may...
  • Page 8 This product has advantages as follows. MAIN POWER TIMER STAND BY MENU TV/COMP. TV/VIDEO POWER Large Screen Adopts Dolby Virtual Your viewing is made more enjoyable because You can enjoy vivid and stereo sound as in your new projection TV has a 47” screen. a theatre.

  • Page 9: Table Of Contents

    Table of Contents Installation and Maintenance Antenna Connection Video Connection Camcorder & Video Game Connection DVD Connection Cable TV Broadcasting Connection Name of Each Part Basic Guide Method To Use Basic Menu To Watch TV Setting Up TV Stations Selection of Input Signal Application Guide Screen Adjustment Adjustment of Colour Match...

  • Page 10: Antenna Connection

    Antenna Connection Indoor Antenna Connection 1. Connect the feeder cable of the antenna to the combining adapter. WHEN THE IMAGE IS NOT CLEAR Unclear screen image and bad reception may be a cause of wrong antenna connection. Be sure to check its direction and place when installing.
  • Page 11 CTV Antenna Connection Such community TV Antenna installation may be found in most of co-op apartments. When a feeder cable is used ANT/CABLE Use fly lead from antenna wallsocket to TV...
  • Page 12 Outdoor Antenna Connection Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses Single Antenna Connection. VHF Antenna UHF Antenna COMPONENT AUDIO ANT/CABLE Separate Antenna Connection. ANT/CABLE -10-...

  • Page 13: Video Connection

    Video Connection Connecting with an External Source You may connect S-Video input to enjoy clearer and brighter picture images. You can make the connection with the AV4 input. Connection is not necessary in Mono mode. Connecting with SCART VIDEO 1. Prepare the scart lead for picture / sound. 2.

  • Page 14: Camcorder & Video Game Connection

    Camcorder & Video Game Connection Watching the Camcorder Recording on TV -Use the input jack provided at the side panel of the TV set. -Use the same connection method for Video Game. Video game -12-...

  • Page 15: Dvd Connection

    DVD Connection (Component Video Method) -480i input signal is possible for DVD input. -DVD screen output is composed of three separate primary colour jack(Y/Cb/Cr), resulting in a higher image quality. -Y/Cb/Cr, may also be noted as Y/PB/PR or Y/Pb/Pr in different DVD players. -The DVD player s audio output must be connected to the DVD audio input socket at the back of the TV set.

  • Page 16: Cable Tv Broadcasting Connection

    Cable TV Broadcasting Connection External Input Connection Source Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver. You may make the connection to any of the Component input and SCART input AV1, AV2 &...
  • Page 17 Antenna Input Connection Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver. Cable TV Broadcasting Station -15-...

  • Page 18: Name Of Each Part

    Name of Each Part Front Panel Buttons on the TV set have the same function as those of the remote controller. Front Panel Button If you turn the TV set off by pressing the ON/OFF button at this panel, it is as unplugging the power cord from the outlet since this will prevent all operation of both the TV set and the remote controller.

  • Page 19: Side And Rear Panel

    Side and Rear Panel Side Panel It is convenient to use the input jacks provided at the side panel when connecting to the camcorder or Video Game. COMPONENT AUDIO COMPONENT AUDIO Rear Panel -17-...
  • Page 20 Parts of the remote controller This remote controller is universal; thus, it may be convertible for TV, Video, CTV, etc. Power Mute Recall AV1 / AV2 / S-VHS2 / AV3 / AV4(S-VHS4) /Component/RF Program number (0-9) Use to select channel directly 0~9 Sleep Childlock This feature is used to set up the time of...
  • Page 21 Page Down Page Up Blue Yellow Green Size Text/TV Cancel Reveal Index Subpage Hold When the TV screen image is unclear BATTERY INSTALLATION Do not drop or spill liquid on it. Push to open the cover of the remote controller Do not expose to heat, dust, or humidity Set the batteries in the battery cell after checking the polarity, and then replace the cover.

  • Page 22: Method To Use Basic Menu

    Method To Use Basic Menu Basic Menu - The basic menu appears on the screen if you press the menu button of the remote control. - There are 5 items Picture, Screen, Sound, Function, and Install in the basic menu. - Each item has sub-items under it.

  • Page 23: To Watch Tv

    To Watch TV On/Off, Number, Mute, Recall, ¢ ∏ / ¢ ∫ / °Â/°„ - Buttons with same name in the main body performs same function. Press the “ON/OFF” button of the front of the set. • The buttons of the remote control and the main body operate only when pressing the “ON/OFF”...
  • Page 24 TO Watch TV Press the “ON/OFF” button. • Press the “ON/OFF” button of the ON/OFF main body. • The main power lamp turns on in red colour. • Press the “Power” button of the main body or the “Power” button of the remote control.

  • Page 25: Setting Up Tv Stations

    Setting Up TV Stations Auto Tuning - All stations that can be received are stored by this method. It is recommended that you use Auto tuning during installation of this set. Repeatedly press the Menu button to select the Install menu. Normal Mode Brightness...

  • Page 26: Auto Tuning

    Auto Tuning Press the VOL¢º ¢º button to display the Auto tuning menu. Select the country you require with “¢∏ ¢∏ VOL¢∫ ¢∫ ” button. Auto Tuning Country Set Norway PR 19 Pal / Secam OK Start Country Set Exit MENU Press the OK button.
  • Page 27 Edit The Edit menu shows you information as follows: - Program position assignment : Program number and Station name, Real channel number. - Picture information : PAL, SECAM, SECAM-L - Sound information : Auto, L, DK3, DK2, DK1, I, BG - Skip : information : Yes, No Deleting the program positions •...

  • Page 28: Manual Tuning

    Manual tuning Press the Number buttons(0~9) or the “°ÂPR°„” button to select a program number you want. VIRTUAL SOUND DOLBY MODE PICTURE ASPECT STILL Locate the selection bar on the Manual tuning at the Install menu. -26-...
  • Page 29 Press the “¢∏ ¢∏ VOL¢∫ ¢∫ ” buttons. • A tuning screen will appear and cursor will move from left to right / from right to left. If you want to stop tuning press the Menu button. After searching a station, you must press the OK button to store the Program.

  • Page 30: Fine Tuning

    Fine tuning - If you are unable to get a good picture or sound because of a poor broadcasting signal, it is possible to adjust the Fine tuning. Move the selection bar to Fine tuning and press the “¢∏ ¢∏ VOL¢∫ ¢∫ ” buttons to activate Fine tuning up or down. Fine Tuning Exit Pr Change...

  • Page 31: Selection Of Input Signal

    Selection of Input Signal When watching video, Camcorder, DVD, Cable TV - See 11p for connection method of TV and “Video”. Press the “ (AV)” button. • Screen changes as follows whenever pressing the “ (AV)” button. P R 1 9 M o n o C l o c k 1 2 : 0 0 VIRTUAL...

  • Page 32: Screen Adjustment

    Screen Adjustment When setting up various screen modes - The user may select various screens designed for a good picture without adjusting the brightness, contrast or colour individually. Press the “Picture” button. • The screen adjustment status changes as the following screens are displayed sequentially whenever pressing the “Picture”...
  • Page 33 When adjusting the screen to taste - You can enjoy various screens by adjusting Brightness, Contrast, Colour, Sharpness, etc to the user’s taste. Select “Picture” by pressing the “Menu” button. • The menu screen appears as follows. Mode Normal Brightness Picture Contrast Colour...
  • Page 34 Adjustment of Screen Size - Randomly change the size of the screen. Pleasure for enjoying the TV increases further. - The AUTO screen operates when power is turned on firstly. Press the “Aspect” and “Zoom” button. • The screen changes as below whenever pressing the “Aspect”...

  • Page 35: Adjustment Of Colour Match

    Adjustment of Colour Match Convergence - This function enables you to adjust the colour convergence of the screen during receiving the signals. When the set is first installed or it is relocated, the picture may be unstable with three colour(Red, Green, Blue). This problem can be solved by adjusting the colour convergence.
  • Page 36 Convergence Press the “¢∏ ¢∏ VOL¢∫ ¢∫ , °Â °ÂPR°„ °„” button to superimpose the red display “+” with the Green one. • The display “+” is moved to the Aspect 16 : 9 left, right, up or down by Zoom Picture pressing the “¢∏...
  • Page 37 Setup of Child Lock - This is function to prevent the use of the TV set without the remote control. Press the “Lock” button. • On-Off of the Child Lock Control is repeated whenever pressing the “Lock” button. • If the Child Lock is “On”, then the VIRTUAL SOUND DOLBY...

  • Page 38: Sound Adjustment

    Sound Adjust When selecting various sound modes Press the “Sound Mode” button. • The sound status changes while SOUND the following screens display in MODE turn whenever pressing the Sound Mode button. VIRTUAL SOUND DOLBY MODE PICTURE ASPECT STILL -36-...
  • Page 39 When adjusting sound to taste - The user can enjoy various the sounds by adjusting Sound Mode, Equalizer, Virtual Dolby, Dynamic Bass and Balance What’s equalizer? • High quality sound range adjustment method used Select “Sound” by pressing the “Menu” button. for audio products.
  • Page 40 Select Virtual Dolby Mode • You can perceive, orientation and a cubic effect through the left/right speaker by developing the existing surround system function. • If you select “Virtual Dolby” or, Panorama and 3D Panorama which is repeated whenever you press the “VOL¢º”...
  • Page 41 Multi-Sound and Stereo Press the “ ” button. • The status changes whilst P R 1 9 the following screens VIRTUAL SOUND M o n o DOLBY MODE C l o c k 1 2 : 0 0 sequentially appear when PICTURE ASPECT STILL...

  • Page 42: Adjustment Of Time

    Adjustment of Time Adjustment of Time - You must previously adjust current time in order to reserve Automatic On/Off. Select “Function” by pressing the “Menu” button. • The menu screen appears Language as follows. Timer Picture Childlock Screen Sound Function Install VIRTUAL SOUND...

  • Page 43: Setting The Time

    Adjustment of Time Setting the Time • Place the cursor to Hour / Minute with Time 12 : 00 “¢∏ VOL¢º” buttons. Picture Auto Colck • Set the Hour / Minute with the “°ÂPR¡ã” Auto Colck Pr Screen Wake Up buttons.
  • Page 44 Setup of Off-time The red lamp turns on whether setting up either Off-time/ On-time. This function is very convenient since the TV automatically turns off at the fixed time if reserving the Off-time for sleeping time or at desired time. If adjusted once, this function operates everyday unless you cancel the Off-time setup or switch off the main power button.
  • Page 45 Choosing Set Amounts of Minutes Before Sleep Time - This function is designed to turn off the TV after a fixed amount of time (10min~120min) has passed from the current time. - Adjust sleep time with sleep button on the remote control. Press the “SLEEP”...

  • Page 46: Selection Of Language

    Selection of Language Selection of Language This function enables you to select the language of the on screen menus displayed on the TV screen. Press the menu button and select “Function” Language Timer Picture Childlock Screen Sound Function Install Position Access MENU Exit...

  • Page 47: Teletext

    Teletext Switching Teletext ON/OFF Press the Text button ( The index page or the page viewed last will appear. Press the Text button again to return to the TV mode. Colour buttons in TOP/FLOF Teletext A red, green, yellow and cyan field is shown at the bottom of the screen. If TOP or FLOF Teletext is transmitted by the station, pressing the corresponding colour button on the remote controller, allows you to easily select the desired page easily.

  • Page 48: Troubleshooting

    Troubleshooting Symptoms and Solutions Please check the following list prior to calling Daewoo Electronics Service Centre for assistance WHEN THE TV DOES NOT TURN ON Is the TV power cord plugged Has the "mute" button at the Have you checked the Colour?

  • Page 49: Standard Of Product

    Standard of Product Band I : CH02 ~ CH04 Band II : CH05 ~ CH12 Receipt Channel Cable Band : S1’ ~ S3’, S1 ~ S20 Hyper Band : S21 ~ S41 Band IV, V : CH21 ~ CH69 Screen Size 119cm(47”), 139cm(55”) Signal Method PAL B/G, I/I, SECAM B/G, D/K, L/L’...
