  • Page 2 INSTRUCTION MANUAL...

  • Page 3: Special Features

    CRT type television. •Exceptionally bright engine The LCD Rear Projection Television DSJ-6000LN has improved its light source by using 130W, which makes the images of the screen much clear and much brighter than just a normal LCD Projection Television. •LCD panels of 2.76 million pixels The LCD Rear Projection Television DSJ-6000LN has three separate LCD panels of 2.76 million pixels that help to...
  • Page 4 Table of Contents Installation and Maintenance Connection guide Menu Guide Preference Guide...
  • Page 5 • Both 1080i and 720p HDTV images • VGA, S-VGA, XGA, SXGA and UXGA computer graphics HD Upgradeable With the use of an optional DTV receiver, your DAEWOO big screen can display high definition pictures. Wide Screen Picture Format You will be able to view pictures as the movie directors intended you to see them. Both the DTV and DVD supporting the wide screen format will enable you to enjoy a sensation that can only be experienced in theaters and now in the comfort of your home.

  • Page 6: Note To Catv System Installer

    CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 7: Important Safeguards

    IMPORTANT SAFEGUARDS Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. Read, Retain and Follow All Instructions Read all safety and operating instructions before operating the TV. Retain the safety and operating instructions for future reference.

  • Page 8: Power Lines

    12. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
  • Page 9 Warning This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user's own safety, and the proper operation of the product. To reduce the risk of electric shock, do not Do not put any object that contains remove cover or back.
  • Page 10 Caution Please keep the user's manual in a safe place for future reference. Do not put volatile substance-such as Do not put magnetic related substance, Do not expose the product in a dusty or benzene, naphtha- near the product or telephone near the product since it moisturized place since it may be a since it may cause a change in the may cause distortion of the image...
  • Page 11 Cautions in Installation and Conveyance Caution When Installing the Unit. Please maintain an approximate distance of 4 from the wall when installing. It may be a cause of fire or shutting off of the TV set since the unit may be overheated if it is too close to the wall.

  • Page 12: Maintenance Tips

    Maintenance Tips Air Filter Cleaning Caution Unplug the power cord from the outlet before cleaning. When vacuuming the filter, please do so from the outmost surface. The TV set will not operate if the air filter has not been properly assembled. Change the air filter if damaged or wet.

  • Page 13: Air Filter Change

    Air Filter Change Cautions When changing the air filter, please do so after having brushed away dust on the set. Do not let the dust get into the unit since the product contains "short-out" parts. Do not detach the filter sponge fixed on the filter cover. Do not clean the filter sponge with water since it may be a cause of blocking its holes..

  • Page 14: Lamp Change

    The screen brightness may be reduced or the light bulb may be shattered when the lamp has been used for a long period of time. In this case, you must purchase the lamp DSJ-LF10 from Daewoo Electronics Service Center, and exchange it as the following instruction since its lifetime has been terminated.

  • Page 15: Open The Door

    Detach the Front Controller Panel. Loose three screws at the left-hand side with a (+) driver, and separate the front controller panel from the unit. Open the Door Pull off the door 1, and then, pull up the door 2 to open as below. -13-...
  • Page 16 Loose Two Screws of the Lamp. Use a (-) driver to separate the lamp from the unit. Exchange theLamp Exchange the lamp and re-assemble in the opposite sequence. Reset the Lamp Timer MENU Plug in the power cord into the outlet, and turn on the TV set either using the remote controller or the Power button.
  • Page 17 Glossary -15-...

  • Page 18: Indoor Antenna Connection

    Antenna Connection Indoor Antenna Connection 1. Connect the feeder cable of the antenna to the combining adapter. 2. Connect the combining adapter to the antenna input at the back of the TV set. VIDEO 1 VIDEO 3 MONITOR OUTPUT VIDEO VIDEO VIDEO VIDEO...
  • Page 19 CTV Antenna Connection Such community TV Antenna installation may be found in most of co-op apartments. Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to the right. -17-...

  • Page 20: Outdoor Antenna Connection

    Outdoor Antenna Connection Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses VHF Antenna UHF Antenna VIDEO 1 VIDEO 3 MONITOR OUTPUT VIDEO VIDEO VIDEO VIDEO AUDI O AUDI O SPEAKER OUTPUT 8 SURROUND SURROUND WOOFER VIDEO AUDIO...

  • Page 21: Video Connection

    Video Connection Connecting with an External Source You may connect S-Video input to enjoy a clearer and brighter picture images. You can choose and make the connection with any one of Video 1,2, or 3 inputs. VIDEO 1 VIDEO 3 VIDEO VIDEO AUDI O...

  • Page 22: Camcorder & Play Station Connection

    Camcorder & Play station Connection Watching the Camcorder Recording on TV -Use the input jack provided at the side panel of the TV set -Use the same connection method for playstation Camcorder VIDEO 2 Playstation Playing a Recorded Material and Recording a Video simultaneously -Connect the camcorder and video as follows.

  • Page 23: Dvd Connection

    DVD Connection -480i input signal is possible for DVD input. -DVD screen output is composed of three separate primary color jack(Y/Cb/Cr), resulting in a higher image quality. -Y/Cb/Cr, may also be noted as Y/PB/PR or Y/Pb/Pr in different DVD players. -The DVD player s audio output must be connected to the DVD audio input socket at the back of the TV set.

  • Page 24: Audio Connection

    Audio Connection Surround Speaker Connection Feel the realism with the surround sound effect! SPEAKER OUTPUT SURROUND SURROUND WOOFER Surround Speaker Woofer Speaker Surround Speaker Standard Audio Connection -You may minimize the volume of the TV set, and listen to the sound. -The default status of Dolby sound is in Internal .

  • Page 25: Digital Satellite Receiver Connection

    Digital Satellite Receiver Connection Watching High Definition Digital Broadcasting The signal input of 1080i, 720p, and 480p are available in this product. You may use a general A/V jack for its connection. VIDEO AUDIO DTV INPUT Digital Satellite Receiver -23-...

  • Page 26: Cable Tv Broadcasting Connection

    Cable TV Broadcasting Connection External Input Connection Source Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver. You may make the connection to any of the Video input 1, 2, & 3. Cable TV Broadcasting VIDEO 1 VIDEO 3...

  • Page 27: Personal Computer Connection

    Personal Computer Connection Watching PC on TV No additional appliance is necessary to watch the PC screen on the TV. When connecting with the PC, use the input jacks provided at the side of the TV. PC, audio, and any other related connection cable must be purchased additionally. -25-...

  • Page 28: Resolution Supported

    RESOLUTION SUPPORTED The standard screen is wide. 640 350 37.861 85.1 VESA 24.823 56.4 640 400 37.861 85.1 VESA 66.7 Macintosh 37.861 72.8 VESA 37.5 75.0 VESA 640 480 39.375 75.0 43.269 85.0 VESA 720 400 37.927 85.1 VESA 35.156 56.3 VESA 37.879...

  • Page 29: Name Of Each Part

    Name of Each Part Front Panel Buttons on the TV set have the same function as those of the remote controller. Front Panel Button If you turn the TV set off by pressing the main power button at this panel, it is as unplugging the power cord from the outlet since this will prevent all operation of both the TV set and the remote controller.

  • Page 30: Side And Rear Panel

    Side and Rear Panel Side Panel It is convenient to use the input jacks provided at the side panel when connecting to the camcorder or play station. It is also convenient when connecting a personal computer to the TV set, and when listening to the sound through headphones.

  • Page 31: Parts Of The Remote Controller

    Parts of the remote controller This remote controller is universal; thus, it may be convertible for TV, Video, CTV, etc. POWER CATV Power CATV TV/VCR/CATV Channel number (0-9) Use to select channel directly 0~9 RECALL Confirm It displays currently watching TV channel andl its input signal Use it when selecting a channel number of over 100 PLAY VCR Function...

  • Page 32: Screen Size

    Remote controller Lamp POWER (When the Remote controller lamp is in: CATV green-TV in use orange-VCR in use CATV red-CATV in use. RECALL PLAY STOP PAUSE MENU Dolby Sound Screen Size This button allows you to choose one of the Pro Logic modes. This feature converts the screen size by changing its aspect ratio.

  • Page 33: Remote Controller Setup

    Remote Controller Set-up When Using the Remote Controller for VCR Purpose It is only operated with the VCRs manufactured by DAEWOO. Some products may not be compatible to this TV set, and may not be able to receive the remote controller signals.

  • Page 34: Basic Menu

    Basic Menu Guide Basic Menu When the "menu" button is pressed, the basic menu window will appear on the screen. It contains a list of 5 entries-Picture, Screen, Sound, Input, Utilities. Furthermore, each entry contains its pertinent sub-items, and when an entry is selected, a list of its sub-items will appear at the right. Displaying the main menu When the menu button is MENU...

  • Page 35: Turning On The Tv

    To watching Television Turning on the TV Buttons on the TV set have the same functions as those of the remote controller. Turning on the TV set. Plug the power cord to the outlet and press the main power at the front controller panel. A red lamp will light up.

  • Page 36: Turning Off The Tv

    Turning off the TV The lamp's lifetime may be reduced if the TV set is not turned off properly. Please read the indications carefully, and power it off as instructed in this manual. Turning off the TV set. Press the power button on the remote controller or that of the TV set. POWER Audio and Video will be turned off and the main power lamp will flash in green at this time.
  • Page 37 Channel Auto Search This feature searches and memorizes all the broadcasting channels automatically. It is very convenient if you have this feature programmed since you do not need to press the number buttons one by one; instead, you may search the channel just pressing the “CH( / )”...
  • Page 38 Choosing Auto search MENU Select “Auto search” by pressing the “ CH / ” buttons. Operating Auto search. Press the “Vol button. ” MENU When the “Vol button is ” pressed, the channel auto search will begin, and memorize all currently available broadcastings.

  • Page 39: Adding A Channel

    Adding a Channel An additional channel may also be memorized when it is not added during the initial auto search because of bad broadcasting signal reception during the initial set-up. You may follow this easy step: Menu Input CH Selection Add/Erase Channel Selecting a Channel to be Added.

  • Page 40: Erasing A Channel

    Erasing a Channel This feature allows you to erase an unnecessary channel from the program. You may follow this easy step: Menu Input CH Selection Add/Erase Channel Selecting a Channel to be Erased. POWER CATV Select the channel to erase, pressing the “...

  • Page 41: Fine Tuning

    Fine Tuning This feature provides adjustments and controls the picture when the image of the screen displays dotted lines, distortion, lack of color, etc. It helps the television to output the clearest and highest quality picture. POWER CATV CATV Adjusting a channel. Select the channel to be adjusted MENU RECALL...
  • Page 42 Viewing the Sub-items. Select "Input" by pressing MENU the “ buttons. CH / ” When the “Vol button is ” pressed, an extended menu window will appear. Operating Channel. Select "Fine Tuning" by MENU pressing the “ CH / ” buttons.
  • Page 43 Watching VCR and DVD Watching VCR & DVD Please refer to the connection guide of television to external input provided at the page 15~21. Selecting a channel is undoable when the unit is in Video mode. The input may be selected by pressing Menu Input Input select POWER...
  • Page 44 Watching DTV or PC Watching DTV or PC This feature may be selected by pressing Menu Input Input select POWER CATV CATV Connect Either the DTV or PC with the Television and Press the "PC/DTV" Button on the Remote Controller. Each time the “PC/DTV”...
  • Page 45 Screen Adjustment of DTV or PC This feature is only available when there is a DTV or PC input. It provides information on the resolution and frequency, and helps adjust its positions. POWER CATV CATV Displaying the Menu. Press the “menu” button MENU The following menu will appear on the screen...
  • Page 46 To Watch the Cable TV Adjusting Screen Format. Select "Adjustment with MENU "Vol / " buttons When the "Vol " button is pressed, a gauge menu will be displayed on the screen. Use the "Vol / " buttons to format the screen. The screen's horizontal and vertical sizes can only be adjusted in the "Wide"...

  • Page 47: Screen Size Adjustment

    Screen Size Adjustment You may change the screen size at your preference. It is more entertaining and fun watching TV. You may adjust it by pressing Menu Screen Size. POWER Selecting Screen Size. CATV Open the remote controller's led and press the "Screen Size" button. CATV SCREEN The size and the aspect ratio of the screen that you are currently...
  • Page 48 Screen Mode Adjustment You may select the screen mode already provided by the factory at your preference without going through the adjustments yourself. You may make the selection by pressing Menu Screen Mode. Selecting Screen Mode. POWER CATV Open the remote controller's led and press the "Screen Mode" SCREEN button.
  • Page 49 Making Picture Adjusting You may adjust the brightness, contrast, sharpness, color and tint at your preference. Adjusts the degree of brightness or darkness of the whole screen Adjusts the degree of brightness and darkness of the objects with the background of the picture. Adjusts the shapes of the objects providing a clearer and softer image.
  • Page 50 Viewing the Sub-Menu. Press the “CH( / )” MENU buttons and select “picture” When “Vol button is ” pressed, an extended menu window will appear. Select the sub-item to be adjusted with the “CH( / )” button once again. When “Vol button is ”...

  • Page 51: Sound Adjustment

    Sound Adjustment Adjusting the Sound Mode You may select the sound mode already provided by the factory at your preference without going through the adjustments yourself. You may have this selection by pressing Menu Sound Mode. POWER CATV Selecting Sound Mode. CATV Open the remote controller's led and press the SOUND...
  • Page 52 Using Equalizer You may adjust the equalizer provided and enjoy the sound quality at your preference. Either high or low tone may be diversely adjusted as the way you want it. POWER CATV CATV This feature is a function that provides a range of sound adjustment used on the audio products.
  • Page 53 Making "Sound Adjustment" Select "Sound Adjustment" MENU pressing the “CH / ” button. When the “Vol button is ” pressed, an extended menu will appear. Using Equalizer Select "Equalizer" pressing MENU buttons. “CH / ” When the “Vol button is ”...
  • Page 54 When Adjusting to "500Hz" Select "500Hz" pressing the MENU buttons. “CH / ” Adjusting Sound Range. Select the sound range using MENU the “Vol / buttons. ” Adjust the sound range in the same method. The sound range of the equalizer adjustment is -32~32 Exiting Sound Adjustment.
  • Page 55 Dolby Sound The original sound system has been improved, and you may hear three-dimensional, Dolby Pro Logic sound. You may have this selection by pressing <Menu> <Sound> <Pro-Logic> Dolby Pro Logic is not supported when Mono mode is in use. -53-...
  • Page 56 Choosing Dolby Pro Logic Open the remote controller's lid and press the "Dolby sound" button. DOLBY SOUND Each time you press the button, it will be changed in the following sequence It may be adjusted by pressing Menu Sound Pro-Logic -54-...
  • Page 57 Speaker Sound Adjustment You may adjust the Speaker sound by pressing Menu Sound Dolby Sound(or Sound Balance) Dolby Pro Logic related sound adjustment cannot be done when the "Dolby Off" mode is on. Noise sequencer: When you select Menu Sound External set Nolse sequencer, you will hear "noise tone"...
  • Page 58 Choosing on Entry Select the entry to adjust MENU pressing the “Vol / ” buttons. When adjusting the "Surround Balance" Select "S-Balance" pressing the MENU buttons. “CH / ” When the “Vol button is ” pressed, an extended menu will appear on the screen.
  • Page 59 Receiving Stereo or SAP Mode Programs When transmission signal is weak or broadcasting condition is not good, sound might be cut off temporarily. This type of malfunction is not caused by TV set. In this case, press “MTS” button and shift the mode into “Mono”. The Second Audio Program (SAP) settings offers you the option of listening to either of two separate Audio programs, such as a second language broadcast.

  • Page 60: Using The Memory Feature

    Using the Memory Feature Time Setting This feature makes the TV turn on automatically at a certain time that you set-up. You must set-up the current time before utilizing this memory feature. Displaying the Menu. Press the “menu” button MENU POWER The following menu will CATV...
  • Page 61 Selecting "Current Time" The word "Current Time" will turn into light blue MENU Press the “Vol button and select "hour". The ” word "hour" will turn into yellow. Press the “CH buttons to adjust the time. / ” Press the “Vol button and select "minute"...

  • Page 62: Using Sleep Timer

    Setting "Sleep Timer" This feature permits the unit to turn off automatically after 10 to 120 minutes depending on the time you set-up POWER Using Sleep Timer CATV Open the remote controller's lid, and press the "Sleep" CATV SLEEP button. Each time the "Sleep"...
  • Page 63 Adjusting to "Factory Set" Select Menu Utilities Factory Set POWER CATV CATV Adjusting to the Factory set You may enjoy the optimum picture and sound by MENU selecting Menu Utilities Factory set. RECALL PLAY STOP PAUSE MENU Checking "Lamp Time" Select Menu Utilities Lamp Time...
  • Page 64 Setting up “Parental Set” Function Users can lock channels by them with 4-digit codes. When Child Lock is set up, the channels locked are not available on the screen. POWER CATV CATV RECALL Displaying the “Menu” The following screen will be displayed. PLAY MENU STOP...

  • Page 65: Entering Your Password

    Selecting Parental Set Select "Parental Set" by MENU pressing the “CH / ” buttons. When the “Vol button is ” pressed, an extended menu window will appear. Entering Your Password. Use the “Number” Parental control buttons(0~9) to enter your Enter the password password.

  • Page 66: Adjusting Movie Ratings

    Selecting TV Guidelines . Select TV Guidelines MENU by pressing the CH buttons. When the Vol button is pressed, an extended menu window will appear. Adjusting TV Guidelines . The TV Guidelines set the MENU standard for TV programs excluding sports and news. Adjust the TV Guidelines useing the CH buttons...
  • Page 67 Select No Rating . Select No Rating by MENU pressing the CH buttons. The Vol button to toggle On or Off . This item determines whether or not to block the programs which are not rated by Movie Ratings and TV Guidelines .
  • Page 68 Enter the New Password. The Set Password item let you change the password for entering Parental Controller _ _ _ _ items. You would better change the initial password 2211 Use “Vol / buttons to enter Adjust the password input display, Prev.

  • Page 69: Selecting The On-Screen Language

    Selecting the On-Screen Language The language of the program on the screen can be changed to one of the following On-Screen languages: English, Spanish and Portuguese. Press the Menu button POWER CATV The following screen will be displayed. MENU CATV RECALL PLAY STOP...

  • Page 70: Select Language

    Select Language Select "Language" by pressing MENU English buttons. “CH / ” Spanish When the “Vol button is ” Portuguese pressed, an extended menu window will appear. Select “On-Screen Language” you want to be displayed by pressing the “CH / ” and “Vol buttons.
  • Page 71 Setting up "Caption" Function "Caption" is a display of words that can substitute for the audio of the TV. It provides narration plus a written version of dialogue and sound effects. "Text" is not usually related to the action on-screen, often providing information such as news or weather.

  • Page 72: Symptoms And Solutions

    Troubleshootings Symptoms and Solutions Please check the following list prior to calling Deawoo Electronics Service Center for assistance Is the TV power cord plugged Has the "mute" button at the Have you checked the Color? into the outlet correctly? remote controller been pressed Isn't the program itself accidentally? broadcasting in black and white?

  • Page 73: Specifications

    Specifications Specifications -71-...

  • Page 74: Limited Warranty

    Limited Warranty Daewoo Electronics Corporation of America Inc. (also known as DECA) warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year labor and 1 year parts from the date of original purchase.
