Frigidaire FGBD2431KB1 Factory Parts Catalog

Frigidaire FGBD2431KB1 Factory Parts Catalog

24-inch built-in

Advertisement

Quick Links

Product No.
Series
Color
Owner's Guide English 154768601
Owner's Guide Spanish 154768603
Owner's Guide French
Service Data Sheet
Energy Guide
Installation Instructions 154427301
Market
FGBD2431KB0.eps CFGBD2431KB1.eps BFGBD2432KB1.eps UFGBD2431KB0.eps
MFGBD2431KB0.eps P30F0022.eps RFGBD2431KB0.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FGBD2431KB1 FGBD2431KF1 FGBD2431KQ1 FGBD2431KW1
Built-in 24"
Built-in 24"
Built-in 24"
black
stainless
bisque
154768601
154768601
154768603
154768603
154768602
154768602
154768602
154768301
154768301
154768301
154758430
154758430
154758430
154427301
154427301
North America
North America North America
Publication No.
5995554960
09/10/29
(EN/SERVICE/ECL)
821
Copyright
Built-in 24"
white
154768601
154768603
154768602
154768301
154758430
154427301
North America
24-INCH BUILT-IN
DISHWASHER
Model No.
FGBD2431K
©
