Frigidaire FDB2410HIC Service Data Sheet

Pump Assembly
The drain hose must have a loop at a minimum
The pump assembly is driven by a synchronous
height of 32 inches in order to insure proper
motor. The motor drives a pump which supplies
drainage.
100 percent filtered water
Draining is accomplished by using a small
separate synchronous drain pump mounted to
the side of the sump. The drain pump is
connected to the main pump by a small rubber
hose. The drain check valve is located at the
discharge end of the drain pump. The drain hose
is attached by a clamp to the discharge end of
the drain pump.
Heater
Refer to the cycle chart on the reverse side to
Voltage checks of the heater should be made in
determine when the heater is on during the
the dry portion of the service test mode.
wash cycle. The heater cycles ON and OFF for
brief periods during the drying cycle.
Standard Dry Air Flow
The water on the dishes is evaporated into drier
The heated, moist air leaving the dishwasher
air and the venting process continues. The
through the console vent causes drier air to be
heating element is turned ON and OFF during the
drawn into the unit by way of intake vents located
entire drying cycle.
at the bottom of the door.
Detergent and Rinse Aid Dispenser
The detergent and rinse aid dispenser is a one To replace dispenser:
piece component consisting of a molded
• shut off electricity to dishwasher,
detergent cup and a built-in rinse aid dispenser.
• remove outer door panel assembly,
• disconnect wiring to the actuator,
The detergent cup has a spring loaded cover
• remove the six screws,
and the rinse aid dispenser has a removable
• remove the dispenser,
cover.
• replace and reinstall screws,
Liquid rinse aid is added to the dispenser up to • rewire actuator.
the fill line indicator. The amount of rinse aid
released can be adjusted by turning the arrow
indicator from one, being the least amount, to
four, being the greatest amount.
Product Specifications
Water Supply
Electrical
Suggested minimum incoming water
Rating ................................... 120 Volts, 60Hz
temperature ............................ 120°F (49°C)
Separate Circuit..15 amp min.- 20 amp max.
Pressure (PSI) min./max. .................. 20/120
Motor (Amps) ................................... 0.6 - 0.9
Connection (NPT) .....................................
Heater Wattage .......................... 475 - 630W
Total Amps (load rated) .......................... 7.0 Consumption (Normal Cycle) ......................
TempAssure .............................. 135°F ±5°F
.......................................... 5.2 - 5.6 U.S. gal
(60°C±3°C) [with outer door in place]
Water valve flow rate (U.S. GPM) ............ 0.9
TempBoost ................................ 140°F ±5°F
Water recirculation rate (U.S. GPM) ..............
Heated Wash/Heated Rinse
................................................. approx. 5.28
Hi-Limit Thermostat ............... 200°F (93°C)
Water fill time ................................... 36 sec.
Trouble Shooting Tips
Personal Injury Hazard
3 / "
8
Always disconnect the dishwasher from the electrical power source before adjusting or
replacing components.
Symptom Check the Following
Dishwasher will not operate when 1. Fuse (blown or tripped).
turned on. 2. 120 VAC supply wiring connection
faulty.
3. Electronic control board defective.
4. No 12 VAC power to control.
5. Motor (inoperative).
6. Door switch (open contacts).
7. Door latch not making contact with
door switch.
8. Touch pad circuit defective.
9. No indicator lamps illuminate when
START or OPTIONS are pressed.
Motor hums but will not start or run. 1. Motor (bad bearings).
2. Motor stuck due to prolonged
non-use.
Motor trips out on internal thermal 1. Improper voltage.
overload protector. 2. Motor windings shorted.
3. Glass or foreign items in pump.
Dishwasher runs but will not heat. 1. Heater element (open).
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Hi-Limit thermostat defective.
1. Latch mechanism defective.
Detergent cover will not latch or
2. Electronic control board defective.
open.
3. Wiring or terminal defective.
4. Broken spring(s).
5. Defective actuator.
Dishwasher will not pump out. 1. Drain restricted.
2. Electronic control board defective.
3. Defective drain pump.
4. Blocked impeller.
5. Open windings.
6. Wiring or terminal defective.
1. Water supply turned off.
Dishwasher will not fill with water.
2. Defective water inlet fill valve.
3. Check fill valve screen for
obstructions.
4. Defective float switch.
5. Electronic control board defective.
6. Wiring or terminal defective.
7. Pressure Switch Stuck.
1. Drain hose (high) loop too low.
Dishwasher water siphons out.
2. Drain line connected to a floor drain
not vented.
Detergent left in dispenser. 1. Detergent allowed to stand too long in
dispenser.
2. Dispenser wet when detergent was
added.
3. Detergent cover held closed or blocked
by large dishes.
4. Improper incoming water
temperature to properly dissolve
detergent.
5. See "Detergent cover will not open."
Remedy
1. Replace fuse or reset breaker.
2. Repair or replace wire fasteners at
dishwasher junction box.
3. Replace control board.
4. Replace control board.
5. Replace motor/impeller assembly.
6. Replace latch assembly.
7. Replace latch assembly.
8. Replace console assembly.
9. Replace console assembly.
1. Replace motor assembly.
2. Rotate motor impeller.
1. Check voltage.
2. Replace motor/impeller assembly.
3. Clean and clear blockage.
1. Replace heater element.
2. Replace control board.
3. Repair or replace.
4. Replace thermostat.
1. Replace dispenser.
2. Replace control board.
3. Repair or replace.
4. Replace dispenser.
5. Replace dispenser.
1. Clear restrictions.
2. Replace control board.
3. Replace pump.
4. Check for blockage, clear.
5. Replace pump assembly.
6. Repair or replace.
1. Turn water supply on.
2. Replace water inlet fill valve.
3. Disassemble and clean screen.
4. Repair or replace.
5. Replace control board.
6. Repair or replace.
7. Repair or replace.
1. Repair to proper 32-inch minimum
height .
2. Install air gap at counter top.
1. Instruct customer/user.
2. Instruct customer/user.
3. Instruct customer/user on proper
loading of dishes.
4. Incoming water temperature of
120°F is required to properly
dissolve dishwashing detergents.
020905
