Toshiba TECRA M3-KK301E Specifications

Model (s):
Tecra M 3-KK301E
i
® ®
Intel Pentium M Processor 730-1.6GHz,
14.1"XGATFT, 512MB, 60GB HDD, CDRW/DVD,
Modem, LAN, TPM, Wireless LAN 802.11a/g,
Windows® XP Pro Windows® XP Pro
Processor
® ®
Mobile Intel Pentium M 730-1.6GHz processor, 533MHz
FSB
L1 Cache 32KB/32KB (instruction/data), L2 Cache 2MB
Operating System
® ®
Microsoft Windows XP Pro
HDD Pre-installed Image Recovery
Memory
Standard Memory: 1x512MB DDR2, 533MHz
Maximum Memory: 2GB DDR
Expansion Modules: 128MB, 256MB, 512MB, or 1024MB
Hard Disk Drive
60.0 billion bytes (5,400 rpm). 9.5mm height, Enhanced IDE
2.5" (ATA-6),
Optical Drive
Slim Select Bay Combo (CD-RW/DVD-ROM)
Maximum speed:
Read: CD-ROM (24x), DVD-ROM (8x)
Write: CD-R (24x), CD-RW (10x)
ATAPI Interface
Software Decoder: InterVideo WinDVD
Display System
Type: TFT Active Matrix colour LCD display
Size (diagonal): 14.1"TFT
LCD Panel Resolution: 1024x768x16.7 million colours
External Support and Maximum Colour Support:
640x480x16.7 million colours (clean stretch)
800x600x16.7 million colours (clean stretch)
1024x768x16.7 million colours (native resolution)
1280x1024x16.7 million colours (virtual screen)
1600x1200x16.7 million colours (vitual screen)
1920x1440x16.7 million colours (virtual screen)
2048x1536x16.7 million colours (virtual screen)
Graphics Controller
nVIDIA GeForce Go 6200 TE 64M
Video Memory: 64 MB DDR memory
PCI Express 16
2D and 3D Graphics
Sound System
Software Sound 16bit stereo
Analog Devices AD1981B
Built-in stereo speakers, Direct 3D sound, full duplex support,
Sound volume control dial, external MIC port (monaural),
stereo headphone port.
Communication
ModemV.92 Data/56K Fax Modem, Ring wake up resume.
10/100/1000 Integrated Ethernet LAN, network boot.
Built-in Wireless LAN (802.11a/g)
Built-in Bluetooth Antenna
Expansion
2 memory slots (one filled with 512MB, can be replaced by
256MB, 512MB or 1 GB) other slot empty.
1 PC Card slot supports one Type II PC Card; supports
Cardbus
1ExpressCard Slot
Ports: SD Card Slot, 1 Parallel, 1 RGB, 1 Docking Interface
(for opt. Advanced Port Replicator III), 1 FIR, 2 USB (2.0), 1
Modem (RJ-11), 1 LAN (RJ-45), 1 IEEE 1394, 1 TV Out (S-
Video), External Mic, Stereo Headphone.
Supported via Advanced Port Replicator III: 1 Parallel, 1
Serial, 1 PS/2 Keyboard, 1 PS/2 Mouse, 4 USB (2.0), 1
Modem (RJ-11), 1 LAN (RJ-45 with LED), 1 Line-in, 1 Line-
out, 1 RGB, 1 IEEE, 1 DVI
Keyboard
Full sized 85 keys with 12 function keys
2.7mm keystroke, 6mm height
Dedicated Windows Keys
Pointing Device
Dual Pointing device – Touchpad + Accupoint
Additional Software
Microsoft Office OneNote 2003
Physical Dimensions
Dimensions: 341mm (W) x 259mm (D)x 31.5mm/34.9 (H)
Weight: 4.99lbs/2.26kg
AC Adapter
75W external Universal AC adaptor input voltage (100 –240V
50/60Hz frequency),(15Vx5A)
Battery
Battery Type: Removable, Rechargeable 6-cell Lithium Ion
(Li-ion) 4700mAh
Battery Life: 4 hours
Recharge Time: 3.0 hours off/ 5-13 hours on
BIOS
ACPI v1.0b, DDC, PnP v1.0a,VESA v2.0, DPMS,
SM BIOS v2.3.4, PCI BIOS Support V2.2.
Security
Cable lock slot, power on password, supervisor password,
Toshiba recommends Microsoft
TPM – Trusted Platform Module
Environmental Specifications
Temperature: Operating 5
Non Operating –20
Thermal Gradient: Operating 15
Non Operating 20
Relative Humidity: Operating 20% to 80% non-condensing;
Non-Operating: 10% to 90% non-condensing
Altitude (relative to sea level): Operating: -60 to 3,000m.;
Non-Operating: -60 to 10,000m.
Shock: Operating: 10G; Non-Operating 60G
Vibration: Operating 0.5G; Non-Operating: 1G
Canada and International Limited Warranty
The Tecra M3 notebook comes with a three (3) year parts
and labour Limited International Warranty. Note the original
battery is warranted for one year from date of purchase. Pre-
installed software is excluded form TCL standard limited
warranty. For complete details on this warranty program and
other Warranty Programs such as On-site and Next Business
Day Service visit toshiba.ca
Accessories
PA3314U-1PRP Advanced port Replicator III
ACC021 USB FDD Kit
PA3378C-1ACA Universal AC Adaptor
PA3356U-2BAS 6Cell Li-ion Battery Pack
PA3357U-1BAL 12 cell Li-ion Battery Pack
PA3129U-2BAS Slim Select Bay 2
PA3091U-1CHG Battery Charger
PA3359U-1DV2 Slim Select Bay DVD Super-Multi Drive
PA3204U-1H60 Slim Select Bay 60GB HDD
PA3230U-1H80 Slim Select Bay 80GB HDD
PA3406U-1HA0 Slim Select Bay 100GB HDD
PA3134U-1ETC Slim Select Bay HDD Adaptor
PA3425U-1BTM Bluetooth Module
Kingston Memory Modules:
Part Number/UPC code
PTM30C-KK301E (English)/6-23506-01019-1
PTM30C-KK301EF (French)/ 6-23506-01021-4
Toshiba of Canada Limited Information Systems Group shall
i
not be liable for damages of any kind for use of this
information, which is subject to change without notice.
Central Processing Unit ("CPU" Performance Disclaimer:
CPU performance in your computer product may vary from
specifications under the following conditions:
•
•
•
•
•
Windows XP Professional
® ®
TECRA M3
° ° ° °
to 35 C (41 to 95 F);
° ° ° °
to 65 C (-4 to149 F)
°
C per hr. max;
°
C per hr. max
Battery Pack
nd
• KTT-533D2/128i
•
KTT-533D2/256i
•
KTT-533D2/512i
•
KTT-533D2/1Gi
use of certain external peripheral products
use of battery power instead of AC power
use of certain multimedia games or videos with special
effects
use of standard telephone lines or low speed network
connections
use of complex modeling software, such as high end
computer aided design applications
