7. Maintenance

IMPORTANT: Ensure that the machine is
!
switched off and unplugged from the socket
before carrying out any maintainence.
Cleaning the Pre-Motor Filter.
1. Remove the motor top from the unit, turn on its side
and remove the float housing in an anti-clockwise
direction to unscrew (Fig.7/1).
Fig.7/1
2. Remove the blue filter (Fig.7/2) and wash under a tap.
Allow to dry thoroughly before replacing back into the
machine. Replace with a new filter as necessary.
Fig.7/2
3. Turn the float housing in a clockwise direction until
secure and place the motor top back onto the unit.
Cleaning the Post-Motor Filter
1. Remove the filter housing at the back of the machine
(Fig.7/3).
4/10/07 11:15 Page 7
Fig.7/3
2. Remove the filter (Fig.7/4) and wash under a tap. Allow
to dry thoroughly before replacing back into the machine.
Fig.7/4
3. Once dry, put the filter back into the housing and place
back into the machine.
Vax Careline 0870 606 1248
7
maintenance
