Vax Essentials VEW-01 Instruction Manual page 6

Vax VEW-01 Essentials User Guide.qxd
www.vax.co.uk
B
A
Fig.5/4
5. After wrapping the tube around the hose, affix
Solution Tube (A) to Hose (B) using Clips provided (C) to
hold it in place (Fig.5/5).
B
Fig.5/5
6. Push the other end of the telescopic tube into the
wash head to be used and push the end of the solution
tube onto the connection port on the Wash Head /
Upholstery Tool (Fig.5/6).
Fig.5/6
6
assembly/ usage
4/10/07 11:15
6. Usage
1. Plug in machine to power supply.
2. Press the red button to turn on the power.
3. Press the green button to activate the pump.
Washing Carpets
1. On the Fibreflow wash head ensure that the rocker
switch (A) is towards the back of the head to allow water
to flow through the head (Fig.6/1).
A
A
Fig.6/1
2. In order to help suck up excess water, the rocker switch
C
(A) can be pushed to the front position on the Fibreflow
was head. This will prevent water flow, allowing excess
water to be removed (Fig.6/2).
A
Fig.6/2
Page 6
