Summary of Contents for Vaisala HUMICAP HMM100
- Page 1 USER'S GUIDE Vaisala HUMICAP® Humidity Module HMM100 M211024EN-B...
- Page 2 English versions are applicable, not the translations. The contents of this manual are subject to change without prior notice. This manual does not create any legally binding obligations for Vaisala towards customers or end users. All legally binding obligations and agreements are included exclusively in the applicable supply contract or the General Conditions of Sale and General Conditions of Service of Vaisala.
-
Page 3: Table Of Contents
Installing the Probe ..............23 Wiring ..................24 2-wire Output............... 24 3-wire Output............... 24 Verifying the Installation............25 CHAPTER 4 OPERATION....................27 Using the Service Port ............27 Installing the Driver for the USB Cable ....... 27 VAISALA ________________________________________________________________________ 1... - Page 4 USER'S GUIDE____________________________________________________________________ Terminal Application Settings..........28 List of Serial Commands ............30 Device Information and Status..........31 Show Device Information ............31 Show Quantities ..............32 Show Calibration Info ............32 Show Analog Output Status ..........32 Show Firmware Version ............33 Serial Line Output Commands ..........33 Start Measurement Output ..........33 Stop Measurement Output ..........33 Set Output Interval...............34 Output a Reading Once............34...
- Page 5 Product Returns ..............63 CHAPTER 7 TECHNICAL DATA ..................65 Specifications ................. 65 Performance................ 65 Relative Humidity ............65 Dewpoint Temperature ..........65 Operating Environment ............66 Inputs and Outputs.............. 66 Mechanics ................67 Options and Accessories ............68 VAISALA ________________________________________________________________________ 3...
- Page 6 USER'S GUIDE____________________________________________________________________ List of Figures Figure 1 HMM100 Humidity Module with Probe ........12 Figure 2 Probe Types ................13 Figure 3 Filter Types ................14 Figure 4 Optional Probe Mounting Flange..........16 Figure 5 Mounting Bracket with Lid ............17 Figure 6 Optional Module Housing ............18 Figure 7 Aligning Mounting Clamp Slots..........19 Figure 8...
-
Page 7: Chapter 1 General Information
This chapter provides general notes for the manual and the product. About This Manual This manual provides information for installing, operating, and maintaining Vaisala HUMICAP® Humidity Module HMM100. Contents of This Manual This manual consists of the following chapters: - Chapter 1, General Information, provides general notes for the manual and the product. -
Page 8: Version Information
USER'S GUIDE____________________________________________________________________ Version Information Table 1 Manual Revisions Manual Code Description M211024EN-B October 2012. This manual. Added VHP filter option and new pictures to the installation instructions, edited commands and technical specifications. M211024EN-A Previous version. Related Manuals Table 2 Related Manuals Manual Code Manual Name M211002EN... -
Page 9: Safety
ESD Protection Electrostatic Discharge (ESD) can cause immediate or latent damage to electronic circuits. Vaisala products are adequately protected against ESD for their intended use. However, it is possible to damage the product by delivering electrostatic discharges when touching exposed components. -
Page 10: Regulatory Compliances
United States and/or other countries. License Agreement All rights to any software are held by Vaisala or third parties. The customer is allowed to use the software only to the extent that is provided by the applicable supply contract or Software License Agreement. -
Page 11: Warranty
Please observe that any such warranty may not be valid in case of damage due to normal wear and tear, exceptional operating conditions, negligent handling or installation, or unauthorized modifications. Please see the applicable supply contract or Conditions of Sale for details of the warranty for each product. VAISALA ________________________________________________________________________ 9... - Page 12 USER'S GUIDE____________________________________________________________________ This page intentionally left blank. 10 __________________________________________________________________ M211024EN-B...
-
Page 13: Chapter 2 Product Overview
HMM100 modules do not incorporate probe heating or chemical purge functionality. If the measurement environment is prone to condensation, or likely to cause chemical contamination of the sensor, other Vaisala instruments may be more suitable to the application. The cable and probe of the HMM100 are attached at the factory. They should remain connected to the module at all times;... -
Page 14: Basic Features And Options
0905-042 Figure 1 HMM100 Humidity Module with Probe Basic Features and Options - Vaisala HUMICAP® 180R humidity sensor - Plastic or stainless steel probe - Analog output options: - 4 ... 20 mA loop powered (2-wire output model) - 0 ... 20 mA or 0 ... 1 / 5 / 10 V (3-wire output model,... -
Page 15: Probe Types
Filter Types on page 14. Figure 2 below shows the plastic probe with a membrane filter (top), and the stainless steel probe with a sintered stainless steel filter (bottom). 0909-021 Figure 2 Probe Types VAISALA _______________________________________________________________________ 13... -
Page 16: Filter Types
USER'S GUIDE____________________________________________________________________ Filter Types The available filters for HMM100 are shown in Figure 3 below. All filters are 12 mm in diameter, and can be used in both the plastic and stainless steel probe. Note the operational temperature range of each filter. -
Page 17: Catalytic Vhp Filter
The long term performance is very good at concentrations higher than typically used for sterilization. However, for the applications where full saturation is possible, Vaisala recommends using the catalytic VHP filter to protect the sensor and extend the calibration interval. -
Page 18: Installation Accessories
USER'S GUIDE____________________________________________________________________ Installation Accessories For order codes of the installation accessories, see section Options and Accessories on page 68. Probe Mounting Flange The probe mounting flange is used to seal the cable pass-through in the chamber wall. The flange can also be used to hold the probe itself, in case the probe cannot be mouted on the chamber wall otherwise. -
Page 19: Mounting Bracket With Lid
The optional mounting bracket includes a metal backplate and a plastic lid for the component board. The bracket does not provide IP rated protection. The bracket can be installed on a DIN rail. 0911-105 Figure 5 Mounting Bracket with Lid VAISALA _______________________________________________________________________ 17... -
Page 20: Module Housing (Ip65)
USER'S GUIDE____________________________________________________________________ Module Housing (IP65) The optional module housing is an IP65 rated housing. The module is installed inside the housing in a mounting bracket (provided with the housing). The housing has two cable glands. A coaxial plug is provided for sealing the gland for the probe cable. -
Page 21: Probe Mounting Clamp
Align the slots on the clamp parts as shown in Figure 7 below. 1209-001 Figure 7 Aligning Mounting Clamp Slots Slide the lower clamp part over to the bottom end of the upper part as shown in Figure 8 below. 1209-002 Figure 8 Sliding the Lower Clamp Part VAISALA _______________________________________________________________________ 19... -
Page 22: Figure 9 Securing The Upper Clamp Part
USER'S GUIDE____________________________________________________________________ Place the clamp to the intended location and secure the upper clamp part with a screw. See Figure 9 below. 1209-003 Figure 9 Securing the Upper Clamp Part Place the probe in the clamp. Tighten the lower clamp part with a screw as shown in Figure 10 below. -
Page 23: Chapter 3 Installation
Chapter 3 _______________________________________________________________ Installation CHAPTER 3 INSTALLATION This chapter provides you with information that is intended to help you install the HMM100. Dimensions 0905-044 Figure 11 HMM100 Dimensions VAISALA _______________________________________________________________________ 21... -
Page 24: Installing The Module
See Figure 12 below. NOTE The installation holes on the component board are compatible with Vaisala HMM22 and HMM30 humidity modules. Remember to disable temperature compensation (if any) in the measurement system when replacing an old module with the HMM100. The temperature compensation in the HMM100 is always enabled. -
Page 25: Installing The Probe
Install the probe in the location. Use the probe mounting clamp (Vaisala order code 226067) if needed. Insert enough cable to the same space with the probe in order to prevent heat conduction, and to make it easy to move the probe when performing a calibration. -
Page 26: Wiring
USER'S GUIDE____________________________________________________________________ Wiring 2-wire Output See Figure 13 below. Provide a 24 VDC supply voltage (see Figure 18 on page 67). 0905-047 Figure 13 Wiring for 2-wire Output 3-wire Output See Figure 14 below. Provide the required supply voltage according to the output type: 10 ... -
Page 27: Verifying The Installation
Verify that your measurement system shows the correct reading. See section Select Analog Output Quantity and Scaling on page 44. Note that ATEST is one of the advanced serial commands that must be activated using the PASS command. VAISALA _______________________________________________________________________ 25... - Page 28 USER'S GUIDE____________________________________________________________________ This page intentionally left blank. 26 __________________________________________________________________ M211024EN-B...
-
Page 29: Chapter 4 Operation
The HMM100 has an RS-232 interface on the component board for service use. You can connect to it through the 4-pin M8 service port connector on the module. Vaisala offers an optional USB cable (Vaisala order code 226068) for connecting the module to your PC. -
Page 30: Terminal Application Settings
There is no reason to uninstall the driver for normal use. However, if you wish to remove the driver files and all Vaisala USB cable devices, you can do so by uninstalling the entry for Vaisala USB Instrument Driver from the Add or Remove Programs (Programs and Features in Windows Vista) in the Windows Control Panel. -
Page 31: Figure 15 Putty Terminal Application
To access the configuration screen while a session is running, click the right mouse button over the session window, and select Change Settings... from the pop-up menu. 0807-004 Figure 15 PuTTY Terminal Application VAISALA _______________________________________________________________________ 29... -
Page 32: List Of Serial Commands
USER'S GUIDE____________________________________________________________________ List of Serial Commands All commands can be issued either in uppercase or lowercase. The notation <cr> refers to pressing the carriage return (ENTER) key on your computer keyboard. Enter a <cr> to clear the command buffer before starting to enter commands. Table 6 Basic Serial Commands Command... -
Page 33: Device Information And Status
If the module is in poll mode, but a connection has not been opened using the OPEN command, issue the ?? command. For a description of the serial interface modes, see section Set Serial Interface Mode on page 41. ??<cr> VAISALA _______________________________________________________________________ 31... -
Page 34: Show Quantities
> Show Calibration Info Use the CALINFO command to show or set the calibration info field. CALINFO ["location"] Examples: >calinfo Calibration location: "VAISALA HELSINKI" > >calinfo "Calibration lab 2" Calibration location: "Calibration lab 2" > Show Analog Output Status The STATUS command shows the following information:... -
Page 35: Show Firmware Version
: 0.000000 Show Firmware Version VERS<cr> Example: >vers HMM100 / HM100 / VAISALA / 1.1.10.3031 > Serial Line Output Commands Start Measurement Output Use the R command to start the continuous outputting of measurement values as an ASCII text string to the serial line. The output always includes the readings of the currently selected analog output quantity (RH or Td) and temperature. -
Page 36: Set Output Interval
USER'S GUIDE____________________________________________________________________ Set Output Interval Use the INTV command to show or set the output interval of the serial line measurement messages (applies when R command or RUN mode is used). The shortest output interval is one second. This command has no effect on the operation of the analog output. -
Page 37: Calibration Commands
RH > 50%. Example: one-point calibration >rhcal 11.29915720 Ref1 ? 11.3 Press any key when ready > Example: two-point calibration >rhcal 11.29915720 Ref1 ? 11.3 Press any key when ready 75.04306440 Ref2 ? 75 > VAISALA _______________________________________________________________________ 35... -
Page 38: Calibrate Temperature Measurement
USER'S GUIDE____________________________________________________________________ Calibrate Temperature Measurement Use the CT command to perform a one-point or two-point temperature (T) calibration. CT<cr> When performing a one-point calibration, you need to place the probe in a single temperature reference. Run the command and enter the exact temperature of the reference after the measurement has stabilized. -
Page 39: Calibrate Capacitance Measurement
30 percentage points of difference between the references. Example: one-point calibration >crh 11.29915720 Ref1 ? 11.3 Press any key when ready > Example: two-point calibration >crh 11.29915720 Ref1 ? 11.3 Press any key when ready 75.04306440 Ref2 ? 75 > VAISALA _______________________________________________________________________ 37... -
Page 40: View User Adjustment Parameters
USER'S GUIDE____________________________________________________________________ View User Adjustment Parameters Use the L command to view the current user adjustment parameters and trimmer adjustment. This command is useful for checking the currently applied correction. L<cr> The output values are as follows: - Cp offset and gain: capacitance, calibrated using the CRH command - RH trimmer offset and gain: correction by the trimmers - RH offset and gain: calibrated using the RHCAL command - T offset and gain: calibrated using the CT command... -
Page 41: Zero The Trimmers
I1 (mA) ? 3.981 I2 (mA) ? 20.002 2.00985160E+03 a0 1.12789450E+03 a1 0.00000000E+00 a2 > Example (analog output in 0 ... 1 V mode): >acal V1 (V) V2 (V) ? 0.998 5.45999950E+02 a0 1.64128260E+03 a1 0.00000000E+00 a2 > VAISALA _______________________________________________________________________ 39... -
Page 42: Configuring Serial Line Operation
USER'S GUIDE____________________________________________________________________ Configuring Serial Line Operation Set Serial Line Settings Use the SERI command to show or set the serial line settings. Use the SAVE command after changing the settings to store them. The new settings will be taken into use when the module is reset or powered up. SERI [b p d s]<cr>... -
Page 43: Set Module Address
When set to POLL state, the modules communicate one at a time when the specific module address is called on the serial line. See descriptions of the commands ADDR above and OPEN on page 47. VAISALA _______________________________________________________________________ 41... -
Page 44: Configuring Measurement Parameters
: 1.013 > >env 0.980 Pressure (bar) : 0.98 >save Saving settings...done > You can use the Vaisala Humidity Calculator to simulate the effect of NOTE pressure change to dewpoint. The Humidity Calculator can be found at: www.vaisala.com/humiditycalculator 42 __________________________________________________________________ M211024EN-B... -
Page 45: Set Temporary Pressure Compensation Value
This value is cleared to 0.0 at reset. XPRES [x.xxxx]<cr> where x.xxxx Absolute pressure in the measuring environment. The pressure unit is bar. Example: >xpres Pressure (bar) > >xpres 1.029 Pressure (bar) : 1.029 > VAISALA _______________________________________________________________________ 43... -
Page 46: Configuring Analog Output
USER'S GUIDE____________________________________________________________________ Configuring Analog Output Set Analog Output Mode Use the AMODE command to show or set the operation mode of the analog output. This command is only useful with the 3-wire output module, as the output on the 2-wire model is always 4 ... 20 mA (loop powered). -
Page 47: Test The Analog Output
Before testing, check the currently set analog output mode using the AMODE command. After testing the output, give the ATEST command again to exit the test mode. ATEST [xxx]<cr> where Analog channel output value (V or mA) Example: >atest 2.5 2.500000, 587f > >atest > VAISALA _______________________________________________________________________ 45... -
Page 48: Other Commands
USER'S GUIDE____________________________________________________________________ Other Commands Display Command List Use the HELP command to display a list of the currently available commands. If the PASS command has not been used, only the basic commands are available. HELP<cr> Enable Advanced Commands Use the PASS command to enable the advanced commands. PASS [passcode] <cr>... -
Page 49: Connecting To The Module In Poll Mode
Most settings have to be saved or the changes are lost at the next reset or power down. NOTE The SMODE command saves the new serial mode immediately; a separate SAVE command is not needed. SAVE<cr> Example: >save Saving settings...done > VAISALA _______________________________________________________________________ 47... -
Page 50: Restore Saved Settings
RESET<cr> Example (module set to serial mode STOP, will output module software version at reset): >reset HMM100 / VAISALA / 1.1.10.3031 > Restore Factory Settings Use the FRESTORE command to restore the factory settings to the module. All user settings, including the analog output mode and user- performed calibration corrections, will be lost. -
Page 51: Chapter 5 Maintenance
Install a new filter on the probe, and tighten it so it is finger-tight. Make sure the filter sits straight and meets the threads properly. New filters can be ordered from Vaisala. For available filters, see section Filter Types on page 14. The order codes of the filters are listed in section Options and Accessories on page 68. -
Page 52: Figure 16 Changing The Sensor
USER'S GUIDE____________________________________________________________________ Remove the filter from the probe by turning it counter-clockwise. Remove the damaged sensor and insert a new one. Handle the new sensor by the plastic socket. DO NOT TOUCH THE SENSOR PLATE. Perform a calibration and adjustment using the CRH command as instructed in section Capacitance Calibration (CRH) on page 58. -
Page 53: Calibration
You also need a humidity reference and a Phillips head screwdriver for zeroing the trimmers. As a humidity reference, you can use, for example, the Vaisala Humidity Calibrator HMK15. Installing the probe properly will also help with the calibration. Ideally... -
Page 54: Calibration And Adjustment Using Trimmers
Trimmers for Offset and Gain The procedure on page 53 provides an example adjustment of offset and gain using the Vaisala Humidity Calibrator HMK15, which is a saturated salt calibrator. It is assumed that the module is powered and you can measure the analog output reading. -
Page 55: Calibration And Adjustment Using Serial Line
Note that the USB cable does not supply operation power to the module. You must power it normally through the screw terminals. NOTE For detailed information on using the service port, USB cable, and the serial line commands, see Chapter 4 on page 27. VAISALA _______________________________________________________________________ 53... -
Page 56: Humidity Calibration (Rhcal)
Humidity Calibration (RHCAL) The procedure below describes a humidity measurement calibration using the serial line commands and the Vaisala Humidity Calibrator HMK15. You can use the procedure to do a one-point calibration (offset) or a two-point calibration (offset and gain). - Page 57 The RHCAL command is now finished and both adjustments have been applied. Use the L command to verify that the new user adjustment parameters are in use: >l Measure the value of the analog output to verify that the measurement is OK. VAISALA _______________________________________________________________________ 55...
-
Page 58: Temperature Calibration (Ct)
USER'S GUIDE____________________________________________________________________ Temperature Calibration (CT) The procedure below describes a temperature (T) measurement calibration using serial line commands. You can use the procedure to do a one-point calibration (offset) or a two-point calibration (offset and gain). For two-point calibration, the second reference point must be at least 20 ºC warmer than the first. - Page 59 The CT command is now finished and both adjustments have been applied. Use the L command to verify that the new user adjustment parameters are in use: >l Measure the value of the analog output to verify that the measurement is OK. VAISALA _______________________________________________________________________ 57...
-
Page 60: Capacitance Calibration (Crh)
(visible with the L command) so that you can restore them manually if necessary. The procedure below provides a calibration procedure using the serial line commands and the Vaisala Humidity Calibrator HMK15. You can use the procedure to do a one-point calibration (offset) or a two-point calibration (offset and gain). - Page 61 20 – 40 minutes for the reading to stabilize. Type 75 and press ENTER to apply the correction (assumes you are using the HMK15 and the NaCl salt). 75.00134550 Ref2 ? 75 > The CRH command is now finished and both adjustments have been applied. VAISALA _______________________________________________________________________ 59...
- Page 62 USER'S GUIDE____________________________________________________________________ Use the L command to verify that the new user adjustment parameters are in use: >l Measure the value of the analog output to verify that the measurement is OK. 60 __________________________________________________________________ M211024EN-B...
-
Page 63: Chapter 6 Troubleshooting
As a rule, add one volt to the supply voltage to get one additional volt from the signal. See Table 10 on page For example, for a 0 … 5 V output, a 6 V error state needs an 11 V supply voltage. VAISALA _______________________________________________________________________ 61... -
Page 64: Solving Typical Problems
USER'S GUIDE____________________________________________________________________ Solving Typical Problems You can check the error message via the serial interface by using the ERRS command. In case of constant error, please contact Vaisala technical support. See section Technical Support on page 63. Table 9 Troubleshooting Table... -
Page 65: Technical Support
- Log corrupted - Resistance measurement Technical Support For technical questions, contact the Vaisala technical support by e-mail at helpdesk@vaisala.com. Provide at least the following supporting information: - Name and model of the product in question - Serial number of the product... - Page 66 USER'S GUIDE____________________________________________________________________ This page intentionally left blank. 64 __________________________________________________________________ M211024EN-B...
-
Page 67: Chapter 7 Technical Data
0…90 %RH ±2.5 %RH 90…100 %RH ±3.5 %RH Factory calibration uncertainty (+20 °C) ±1.5 %RH Humidity sensor Vaisala HUMICAP 180R Dewpoint Temperature Measurement range -20 ... +100 ºC (-4 ... +212 ºF) T Accuracy (including non-linearity, hysteresis, and repeatability) when dewpoint depression <20 °C... -
Page 68: Operating Environment
USER'S GUIDE____________________________________________________________________ Operating Environment Operating temperature range Component board -5 ... +55 ºC (+23 ... +131 ºF) Plastic probe -70 ... +180 ºC (-94 ... +356 ºF) Stainless steel probe -70 ... +180 ºC (-94 ... +356 ºF) Plastic grid filter -20 ... -
Page 69: Mechanics
0.65 m, 1.55 m, 2.9 m Stainless steel probe 1.55 m, 2.9 m Materials Plastic probe Stainless steel probe AlSI316/PPS Probe mounting clamp AISI316 Probe mounting flange Silicone/ AISI316 Mounting bracket bottom plate Mounting bracket lid ABS/PC Module housing ABS/PC VAISALA _______________________________________________________________________ 67... -
Page 70: Options And Accessories
USER'S GUIDE____________________________________________________________________ Options and Accessories Description Item code Humidity sensor HUMICAP180R Membrane filter 10159HM Plastic grid filter 6221 Porous PTFE filter 219452SP Stainless steel sintered filter HM47280SP Catalytic VHP filter 231865 Mounting bracket with lid 225979 Module housing (IP65) 226060 Probe mounting flange 226061 Probe mounting clamp set (10 pcs) - Page 71 Chapter 7 ____________________________________________________________ Technical Data VAISALA _______________________________________________________________________ 69...
- Page 72 *M211024EN*...
