Headzone Software Control Panel
8.4.3

Surround channel volumes

The volume faders for all surround channels
and are intended to set up a convenient balance between your virtual surround speakers. When using positive gain, please watch
the level meters to make sure you do not saturate any audio signals (refer to chapter 8.4.2 "Surround channel level meters"). All
channel volume settings will be stored within your hardware and are still available when you use Headzone again, whether a PC is
connected or not.
8.4.4

Muting channels

The "Mute" tick boxes for all surround channels
muting and unmuting of channels without losing the volume fader settings. All mute tick boxes' settings will be stored within the
hardware and are still available when you use Headzone again, whether a PC is connected or not.
8.4.5

LFE filtering

Within Headzone the LFE channel has a cutoff frequency of 120Hz (24dB/Oct.) for playback of low-frequency audio signals. This can
be important for some surround PC games that use a full-range signal on the LFE output, assuming that the connected subwoofer
has an integrated crossover. Nevertheless, if you want to have full control of the frequency range of your LFE channel (e.g. if you set
the corresponding bandwidth limit yourself during mixing) you can enable the "Fullrange" tick box
control panel to set the LFE channel full-range. When doing so, please note that the LFE channel is not incorporated into the
surround processing and full-range signals can therefore impair the surround impression.
Note:
When using Headzone in broadcast vans and having to put up a communication channel from operator to sound engineer, you can
set the LFE to fullrange and use this input for communication purposes.
8.4.6 LFE phase reverse - Ø
For reversing the phase of the LFE channel in Headzone you can activate the "Ø" tick box
come in handy when watching DVDs (e.g. via a software DVD player) as sometimes the LFE channel is not mixed in phase with the
surround channel here. You can figure this out by activating and deactivating the LFE Phase Reverse tick box during playback. If you
feel that the bass response increases when the LFE phase reverse function is activated, then the LFE stream on your DVD is out of
phase.
Ø unchecked = LFE is in phase with the surround channels
Ø checked = LFE is out of phase with the surround channels
8.4.7

Output level meters

The level meters for the output signal
and after the master volume fader (AFL). When the signal strength reaches the upper maximum (e.g. using volumes > 0dB on the
channel volumes or master volume) you are about to saturate the Headzone output section. In this case, please reduce the channel
volumes or the master volume using the corresponding faders.
8.4.8

Master volume

The master volume fader will globally level the audio output of the Headzone surround processing. This volume fader is intended
7
to add global makeup gain when using very low-level input signals, or when using high "Distance" or "Ambience" settings in the
"Room set-up" panel (refer also to chapter 8.3.2 "Room settings"). The master volume fader can be used as master headphone
volume, but for optimum audio performance we recommend using the master volume fader to maximise the output level strength
of your surround signal and use the volume knob
volume.
will level audio signals in your Headzone hardware within a range of -50dB to +10dB
3
have the same function as setting channel volumes to zero, but then allow
4
6 show the signal strength of the audio output after the Headzone surround processing
on the front of the Headzone base station for the desired headphone playback
7
- 21 -
in the Headzone software
5
below the LFE slider. This feature will
8
