- Page 1 BEDIENUNGSANLEITUNG OPERATING INSTRUCTIONS NOTICE D’UTILISATION Opus 100 Drahtloses System Wireless System Système sans fil...
- Page 2 Thank you for selecting the Opus 100 wireless system. Please take some time to read carefully through this manual before setting up the equipment. The Opus 100 system has a single frequency in the VHF frequency range 174 to 236 MHz or in the UHF frequency range 798 to 862 MHz.
- Page 3 Antennae Fully extend the antennae and set them at an angle of 60° between each antenna. The two antennae are positioned this way to achieve the best pick-up reception. Setting up 1. Place the NE 100 diversity receiver in the same room or area as the transmitters. Ensure that the NE 100 is installed as close as possible to the mixing console or amplifier so that all indications can be seen at all times.
-
Page 4: Setting The Gain
Setting the Gain First adjust the gain of your transmitter (only TS 100; refer to chapter 3.3). Once the transmitter gain is optimised, it is necessary to match the receiver’s output gain to your mixing console or PA system. Adjust the gain control (5). Setting the gain too high may cause distor- tion. -
Page 5: Controls And Indicators
SDM 159, SDM 169 and SEM 181 Handheld Transmitters Controls and Indicators On Off On Off Mute Power SEM 181 Setting up 1. Switch on the NE 100 receiver. 2. Rotate the microphone under the microphone head (1) counter clockwise and carefully slide the transmitter shaft down. -
Page 6: Maintenance
7. To avoid popping, try holding the microphone at a slight angle below your mouth. 8. To avoid covering the integrated antenna by your hand, do not hold the microphone at the microphone head as this could reduce the transmission strength. Furthermore, feedback can occur. -
Page 7: Adjusting Input Gain
2. Connect the supplied microphone or instrument cable to the jack socket (4). 3. Switch on the beltpack transmitter by switching the On / Off switch (6) to the “On” position. The power on battery condition LED (5) is illuminated green when the battery has been inserted correctly and has full capacity. -
Page 8: Before The Soundcheck
Before the Soundcheck 1. Make sure that the transmitter and receiver are on the same frequency (refer to type plate). 2. Check the transmitter battery and replace or recharge it if necessary. Use fresh alkaline batteries only. 3. Check the performance area for dropouts (i.e. areas where poor reception is encountered). If you find any dropouts try to eliminate them by repositioning the antennae or the receiver. - Page 9 In most countries around the world, wireless systems must be approved for use by the authorities and it may be necessary to obtain a licence to use it legally. Your local beyerdynamic dealer will be able to give you details on wireless system regulations for your area.
- Page 10 Versions Opus 100 V Set consisting of: NE 100 V VHF diversity receiver, TS 100 V VHF beltpack transmitter, instrument cable and bag Opus 150 V Set consisting of: NE 100 V VHF diversity receiver, TS 100 V VHF beltpack transmitter, MCE 60.100 clip-on microphone and bag...
-
Page 11: Optional Accessories
Optional Accessories NE 100 Diversity Receiver 19"-Option ZTE 100/200 Shelf for 19"-rack mounting of one NE 100 receiver ..Order # 457.051 SDM 159, SDM 169 and SEM 181 Microphones Microphone clamp MKV 11 Microphone clamp . - Page 12 SDM 159 V / U, SDM 169 V / U and SEM 181 V / U Microphones Polar pattern ....Supercardioid (SDM 169) / Supercardioid (SDM 159) Transducer type .
