- Page 1 External 3.5” eSATA + USB 2.0 HDD Enclosure Model: Model: E315SU31 E315SU31 User Manual En En...
-
Page 2: Exterior Layout
Content 1. Package Contents ................2. Hardware and OS Requirements ........3. Exterior Layout ................... 4. Function Description ..............5. Physical Installation ..............A. Taking out the HDD tray..............2 B. HDD installation................2 6. Specifications ..................7. Creating a Partition ................. A. - Page 3 1. Package Contents A complete unit contains the following items: A. USB 2.0 Cable B. eSATA Cable C. External Enclosure D. AC/DC Power Adapter E. Vertical Placement Stand F. User’s Manual 2. Hardware & OS Requirements Hardware Requirements: Available USB or eSATA port. OS Requirements: Windows 2000 / Windows XP* / Vista* / 7*、Mac OS X (*32 &...
- Page 4 5. Physical Installation A. Take out the HDD Tray 1). Push the release switch on the rear panel 2). Carefully slide out the HDD tray. to eject the tray. B. HDD Installation 1). Lift up the mounting brackets as illustrated. 2).
- Page 5 6. Specifications Model: E315SU31 Device Support: 3.5” SATA Hard Drives Internal Interface: SATA External Interface: eSATA & USB 2.0 Material: Aluminum Case Body Dimension: 7.5L x 5.25W x 1.4H (inches) 193L x 128W x 35H (mm) Power Supply: AC Adapter, 12V 2.0A Transfer Rate: eSATA - 3.0 Gbps Max...
- Page 6 B. For Mac Users: 1. Connect the E315SU31 device to the computer and power it on. 2. Start Disk Utility. Disk Utility is in the Utilities folder inside the main Applications folder. Or, use Spotlight and do a search for Disk Utility.
- Page 7 AZiO Corporation warrants this product against defect in material or workmanship for 1 year from the date of purchase. If this product proves to be defective, contact AZiO for repair or replacement. Return units cannot be processed without the proof of original date of purchase.
