HTR15ABM—Hotpoint 14.6 Cu. Ft. Top-Freezer Refrigerator
Front View
B
A
Specification Revised 3/01
Top View
H
G
C
D
Height with hinge (in.) A
Height without hinge (in.) B
Depth without Doors (in.) C
Depth with Doors (in.) D
Depth plus Handle with Doors Closed (in.) E
Depth with Doors open 90° (in.) F
Width with Doors Closed (in.) G
E
Width with Doors open 90° Less Door Handles (in.) H 28-5/8
Each side (in.)
Top (in.)
F
Back (in.)
Note: Before installing, consult installation instructions packed with product
for current dimensional data.
Total volume and shelf
VOLUME and
area are calculated by the
SHELF AREA
Association of Home
Manufacturer Certified to
Appliance Manufacturers'
ASSOCIATION OF HOME
APPLIANCE MANUFACTURERS
ANSI/AHAN HRF-1-1979
standards.
61-3/4
61-1/4
25-7/8
29-1/8
29-1/8
54-7/8
28
3/4
1
1
Listed by
Underwriters
Laboratories
R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hotpoint HTR15ABM
Summary of Contents for Hotpoint HTR15ABM
- Page 1 HTR15ABM—Hotpoint 14.6 Cu. Ft. Top-Freezer Refrigerator Front View Top View Height with hinge (in.) A 61-3/4 Height without hinge (in.) B 61-1/4 Depth without Doors (in.) C 25-7/8 Depth with Doors (in.) D 29-1/8 Depth plus Handle with Doors Closed (in.) E 29-1/8 Depth with Doors open 90°...
- Page 2 HTR15ABM—Hotpoint 14.6 Cu. Ft. Top-Freezer Refrigerator Features and Benefits • 14.6 cu. ft. Capacity (Fresh Food 10.72 cu. ft. / Freezer 3.86 cu. ft.) • Equipped for Optional Automatic Icemaker • 1 Full-Width White Vegetable/Fruit Crisper • 2 Fixed Fresh Food Door Shelves with Tall Bottle Storage •...
