- Page 1 AX-ONE LOUDSPEAKERS OWNERʼS INFORMATION ...
- Page 2 CONTENTS 1) CE DECLARATION OF CONFORMITY DISPOSAL INTRODUCTION 3) OVERVIEW 4) UNPACKING AND INSTALLATION 5) CONNECTION 6) CONNECTION TO AMPLIFIER 7) OPERATION BEDDING IN CLEANING 8) TECHNICAL SPECIFICATIONS 9) WARRANTY INFORMATION 10) CONTACT INFORMATION...
- Page 3 BS EN 60065 in accordance with the regulations 73/23/EEC, 89/336/EEC (from 1 January 1997) CE 94 Peter Qvortrup, Director Audio Note (UK) Limited 25 Montefiore Road Hove East Sussex BN3 1RD United Kingdom...
- Page 4 INTRODUCTION Thank you for purchasing this Audio Note (UK) product. With the correct care it should give you many years of pleasure and enjoyment. Please take the time to read all of the information in this manual before connecting your new component to an electrical supply or your system, to ensure both your safety and satisfaction.
- Page 5 AX-ONE LOUDSPEAKERS The AX-ONE is a compact ʻbook shelfʼ design, using two drive units per cabinet to cover a very wide frequency response, given its modest dimensions. Unlike many ʻbook shelfʼ designs, the AX-ONE is relatively efficient and offers the amplifier an easy ʻloadʼ, making it highly suitable for our range of superior quality, low...
- Page 6 The ported enclosure of the AX-ONE has been designed to be placed close to room boundaries (where the bass performance is augmented significantly by the additional reinforcement from the nearby walls), whether standing on a high mass stand (available separately) or lying on its side on a rigid shelf.
- Page 7 ENSURE THAT IT IS DISCONNECTED FROM THE MAINS SUPPLY! Choose loudspeaker cables that are long enough to comfortably reach from your amplifier to the AX-ONE without stretching or pulling tightly; it is always better to have a loudspeaker cable that is too long rather than too short! On the rear of each speaker are two pairs of binding posts;...
- Page 8 If your amplifier is equipped with multiple loudspeaker output terminals, consult the manual for the unit to ascertain the appropriate connection regime. The facility to split the crossover of the AX-ONE allows the speakers to be operated in a bi-wired or bi-amplified mode. The crossovers are split by removing the connecting links between the HF and LF terminals on the rear of the speaker.
- Page 9 BEFORE the amplifier; to protect your AX-ONE loudspeakers from damage, always make sure the amplifier is the LAST piece of equipment to be switched on and the FIRST to be switched off.
- Page 10 UNIT DIMENSIONS per loudspeaker 490mm (h) x 260mm (w) x 360mm (d) SHIPPING DIMENSIONS 2 loudspeakers packed together (ORIGINAL PACKAGING) Due to Audio Note (UK)ʼs ongoing research and NOTE development program, specifications are subject to change without notice. ...
- Page 11 Audio Note (UK) warrants this product to be free from defects in materials and workmanship for two years from the original date of purchase from an appointed Audio Note (UK) dealer, and agrees to covers the cost of parts and associated labour required to correct such defects, subject to terms & conditions.
- Page 12 CONTACT INFORMATION If in the future your Audio Note (UK) product requires servicing, or if you require technical support or have any questions regarding this or any of our other products, please contact your local Audio Note (UK) dealer. ...
