PYLE Audio PYM1578 Test Instructions

Part Number
Comments
Re
Le
QM
QE
QT
Xmax
Pmax
Bl
Coil Diameter
Gap Height
Efficiency
*Please note : Customer assumes responsibility for power testing each design per application. Eminence Speaker LLC does not power test samples. The ratings above
are a general guideline based upon known thermal capacity of voice coil diameters/materials. True power handling depends on many driver and system factors, thus
our guidelines are conservative in nature.
Parameter Date 8/3/2004 2:57:56 PM
PYM1578BLK
0431E PRODUCTION RUN
6.13 Ohms
0.44 mH
8.06
0.72
0.66
1.59 mm
225 Watts
11.21 Tm
2.50 Inches
0.375 Inches
2.74 %
Reference Number
151669B
fs
Mms
Mmd
Cms
Rms
Vas
SD
VD
EBP
Magnet Weight
Winding Width
SPL
42.0 Hz
55.7 grams
41.1 grams
0.257 mm/N
1.824
N*sec/m
273.2 liters
864.6 cm^2
137.3 cm^3
58.6
56 ounces
0.500 inches
96.4
dB 1W-1m
