PYLE Audio PYM1278 Owner's Manual

Part Number
Comments
Re
Le
QM
QE
QT
Xmax
Pmax
Bl
Coil Diameter
Gap Height
Efficiency
*Please note : Customer assumes responsibility for power testing each design per application. Eminence Speaker LLC does not power test samples. The ratings above
are a general guideline based upon known thermal capacity of voice coil diameters/materials. True power handling depends on many driver and system factors, thus
our guidelines are conservative in nature.
Parameter Date 8/3/2004 2:29:49 PM
PYM1278BLK
0431E PRODUCTION RUN
6.28 Ohms
0.47 mH
7.19
0.62
0.57
1.59 mm
225 Watts
12.19 Tm
2.50 Inches
0.375 Inches
2.47 %
Reference Number
121982
fs
Mms
Mmd
Cms
Rms
Vas
SD
VD
EBP
Magnet Weight
Winding Width
SPL
62.4 Hz
37.1 grams
30.5 grams
0.175 mm/N
2.024
N*sec/m
64.7 liters
509.9 cm^2
80.9 cm^3
101.5
56 ounces
0.500 inches
95.9
dB 1W-1m
