Summary of Contents for AMC CD8b
- Page 3 WARNING! INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM. VORSICHT! UNSICHTBARE LASERSTRAHLEN TRITT AUS, WENN DECKEL GE FFNET UND WENN SICHERHEITSVERRIEGELUNG BERBR CKT IST. NICHT DEM STRAHL AUSSETZEN. ADVARSEL- USYNLIG LASERSTR LING VED BNING, N R SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION.
- Page 4 * EIA calibrated audio outputs ensure a proper match with preamplifiers and receivers. * Provide digital output allow the CD8b to be used as a high-quality transport and provide for future upgrades.
-
Page 5: Rear Panel
REAR PANEL 1. AUDIO OUTPUT 2. DIGITAL OUTPUT 1. POWER SWITCH AND POWER INDICATOR 2. OPEN/CLOSE 3. PLAY 4. PAUSE 5. STOP 3. AC LINE CORD 6. PROGRAM 7. REPEAT 8. TIME 9. SEARCH 10. TRACK 11. DISPLAY... -
Page 6: Audio Output
1. AUDIO OUTPUT Connect the left and right channel unbalanced (RCA) audio outputs to any input on your preamplifier or receiver except "Phono" or "Turntable". High- quality interconnection cables are recommended. 2. DIGITAL OUTPUT Co-axial cable digital output. 3. AC LINE CORD Plug the AC line cord into a switched outlet on your amplifier or into any AC wall outlet that provides the correct line voltage. - Page 7 6. PROGRAMMING The CD8b can be programmed to play up to 21 tracks in any desired order. To program playback, start by pressing the PROGRAM button.
- Page 8 h) To clear the program memory, press OPEN/CLOSE to open the drawer or simply switch off the power. 7. REPEAT This button will allow two different types of endless play modes. Press the REPEAT button once, the word REPEAT 1 will appear on the display and the selected track will be repeated endlessly until the...
-
Page 9: Remote Control
"4" button ( +10, +10, 4 ). RANDOM Pressing the RANDOM button before or during play will cause the CD8b to play all tracks on the disc in a random order until all tracks have been played. To cancel random play,... -
Page 10: S/Pdif Digital Output
AUDIO OUTPUT (Ref. 1KHz/0dB, unless otherwise stated): Disc capacity...Single disc, 120 or 80mm Programming capability...21 Tracks Digital to analogue convertion...Enhanced multilevel Delta-Sigma DAC Digital filter...8X over-sampling at a 96Khz sampling rate Analogue filter...5-Pole active Frequency response 5Hz-20KHz...<+/-0.3 dB De-Emphasis error...<+/-0.3 dB Linearity...+/-0.5 dB: 0 to -90 dB Channel separation (20Hz to 20KHz)...>90 dB Channel imbalance...<+/-0.2 dB... - Page 11 National Fire Protection Association (Batterymarch Park, Quincy. MA 02269). Antenna Lead In Wire Antenna Ground Discharge Clamp Unit (NEC Section 810.20) Grounding Conductors (NEC Section 810.21) Ground Clamps Power Service Grounding Electrode System (NEC Art 250 Part H) AMC 21-3004...
- Page 12 PN: 21-4136...
