Traynor DynaBlock400 Service Manual page 13

YS # Description
6385 JEWELED PILOT LAMP CLEAR ROHS
6398 RED 5MM LED 1V5 20MA HIGH EFF
6399 YEL 5MM LED 1V5 20MA HIGH EFF
6425 BAV21 200V 0A25 DIODE T&R
6825 1N4148 75V 0A45 DIODE T&R
6438 1N4007 1000V 1A0 DIODE
6827 1N5402 200V 3A0 DIODE
6934 MR854 400V 3A0 DIODE FASREC
6434 6A2 200V 6A0 DIODE
6426 1N5254B 27V0 0W5 ZENER 5% T&R
6439 1N5225B 3V0 0W5 ZENER 5% T&R
6454 1N5231BRL 5V1 0W5 ZENER 5% T&R
6459 1N4732A 4V7 1W0 ZENER 5% T&R
6822 1N4745A 16V0 1W0 ZENER 5% T&R
6875 1N5359B 24V0 5W0 ZENER 5% T&R
6871 MC7915CT TO220 N 15V0 REG
6872 MC7815CT TO220 P 15V0 REG
5101 BC550C TO92 NPN TRAN T&R TB
5102 BC560C TO92 PNP TRAN T&R TB
5103 MPSA06 TO92 NPN TRAN T&R TA
5104 MPSA56 TO92 PNP TRAN T&R TA
5113 MPSA42 TO92 NPN TRAN T&R TA
5105 MPSA13 TO92 NPN DARL T&R TA
5106 MPSA63 TO92 PNP DARL T&R TA
5119 J111 TO92 NCH JFET T&R TC
5122 J109 TO92 NCH JFET T&R TC
6815 MJF6388 T221D NPN TRAN DARL TJ
6805 2SD2560 TO3P NPN TRAN DARL
6812 2SB1647 TO3P PNP TRAN DARL
6953 IRF4905 TO220 PCH MFET
6966 IRL2910 NCH MFET 100V TN
6804 MC33079P IC QUAD OP AMP
6840 MC33078P IC DUAL OP AMP
6882 TL072CP IC FET DUAL OP AMP
6884 NE5532N IC DUAL OP AMP
6889 TL074CN IC QUAD O/A T.I ONLY
6745 LM13600N IC XCONDUCTANCE AMP
5190 MBS4992 TO92 8V5 DIAC
6517 BTB24-600 TO220AB 25A TRIAC 600V
6880 4N35 OPTO-COUPLER
6619 _10K 3% THERMISTOR VISH NTC
5400 _10P 100V 10%CAP T&R BEAD
5406 _33P 50V 10%CAP BLK BEAD
5408 _47P 100V 10%CAP T&R BEAD
5410 100P 100V 10%CAP T&R BEAD
5197 220P 100V 2%CAP T&R RAD CER.2NPO
5412 220P 100V 10%CAP T&R BEAD
5416 470P 50V 10%CAP T&R BEAD
5816 680P 100V 5%CAP T&R RAD CER.2NPO
5423 __1N2 50V 10%CAP T&R BEAD
5208 __2N2 400V 5%CAP T&R RAD
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC
5272 __6N8 100V 5%CAP T&R RAD
5204 _10N 100V 10%CAP T&R RAD
5301 _12N 50V 10%CAP T&R BEAD
5207 _18N 100V 5%CAP T&R RAD
5210 _22N 100V 10%CAP T&R RAD
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC
5222 _33N 100V 10%CAP T&R RAD
5224 _47N 100V 10%CAP T&R RAD
5212 100N 63V 5%CAP T&R RAD .2FLM
5229 150N 63V 10%CAP T&R RAD
5231 220N 63V 5%CAP T&R RAD .2FLM
5233 330N 63V 5%CAP T&R RAD .2FLM
5256 __1U 63V 5%CAP T&R RAD .2FLM
5257 __2U2 63V 20%CAP T&R RAD
5258 __4U7 63V 20%CAP T&R 8X7MM .2EL
5282 _10U 16V 20%CAP T&R 5X7MM .2NP
5629 _10U 160V 20%CAP BLK 10X13MM EL
5631 _22U 50V 20%CAP T&R 6X7MM .2EL
5961 _33U 16V 20%CAP T&R RAD .2IN NP
5267 100U 25V 20%CAP T&R RAD
5630 330U 25V 20%CAP BLK 10X13MM EL
5896 4700U 80V 20%CAP BLK 25X50MM ELS
5890 5600U 100V 20%CAP RAD 35X50MM ELS
4417 _10K 5B LIN 9MM HORIZONTAL P28
4452 _10K 5C R/A 12MM 4PIN HORZ
4455 _10K 5B R/A 12MM 4PIN HORZ
4453 _50K B LIN 12MM 4PIN HORZ DT P40
4520 _10K TRIM POT
DynaBlock400 Parts List 8/13/2012
Qty. YS # Description
1 714 1.5 MIL X 36" CLEAR POLY SHEETING
2 3820 ___4UH COIL 14AWG ZOBEL HORIZONTAL
1 8521 RUBBER BUMPER WITH WASHER VERYSMALL
6 3489 CLIP 250X032 18-22AWG DISCO/INSL
26 3601 RING TERMINAL 16AWG WIRE & #8 SCREW
T&R 2 3450 1/4" JCK PCB MT ALL-GOLD SKT
2 3498 1/4" JCK PCB MT HORZ
4 4106 1/4" JCK PCB MT HORZ
8 6973 NEUTRIK SPKON 1/4" JACK COMBO GRN
3 3923 XLR MALE PCB MT HORZ MTHOLE-V SNAP
3 3414 INTERNATIONAL PC MOUNT FUSEHOLDER
1 4061 FAN 80MM X 80MM 43.9CFM 12VDC 300MA
2 9032 FAN VIBRATION ISOLATORS
6 2427 _5.0 AMP SLO-BLO .25X1.25 FUSE
2 2463 T6,3A
V2 1 9996 3/8" DIA,BARE STEEL 6" TUBE HANDLE
V1 1 3719 DUAL XSISTOR SPRING, ZINC CLEAR
3 3977 QUAD XSISTOR SPRING, ZINC YELLOW
3 8889 RUBBER GROMMET #2183-034-BLK
1 3645 AC SOCKET RECEPTACLE WITH 0.250 TAB
4 3803 NYLON SECUR-A-TACH MINI PLASTIC TIE
2 3810 4" NYLON CABLE TIE
1 4162 2 PIN POWER PIN HEADER MALE POLZED
1 4146 3 PIN POWER PIN HEADER MALE POLZED
2 4147 6 PIN POWER PIN HEADER MALE POLZED
1 8636 BUTTON 230X465 RND FLAT BLK (3425)
1 9923 BLACK KNOB WITH POINTER
2 3428 8' 3/18 SJT AC LINE CORD REMOVABLE
2 8701 4-40 KEPS NUT ZINC
2 8800 6-32 KEPS NUT ZINC
2 8841 10-32 KEPS NUT TIN PLATED
2 8797 5/16-18 KEPS NUT JS500
4 4022 ELASTOMER PAD - 4-TO220 1X1.850
2 4125 ELASTOMER PAD - 2-TO218 1X2.050
1 8581 CUSTOM PBL TRANSISTOR SPACER
1 4599 22AWG SOLID SC WIR
1 5299 24AWG SOLID SC WIR
T&R 1 4749 5.0W 0R15 5%
1 2006 1.0W 1R
1 4703 2.0W 2R
4 2008 1.0W 10R
NPO 1 2009 1/4W 10R
NPO 2 2038 1/4W 11R
NPO 1 2011 1/4W 11R3 1%FLAME PROOF T&R RES
NPO 9 2013 1/6W 22R1 1%FLAME PROOF T&R RES
2 2040 1/4W 33R
NPO 1 4617 1/2W 47R
NPO 2 6134 1/4W 47R
2 2019 1/8W 100R0 1%FLAME PROOF T&R RES
X7R 1 4852 1/4W 100R
.2FLM 1 4987 1/4W 120R
1 4859 1/4W 150R
.2FLM 1 4909 1/4W 200R
.2FLM 5 4857 1/4W 220R
X7R 1 4770 1/4W 249R
.2FLM 1 4986 1/4W 270R
.2FLM 2 4789 1/4W 324R0
1 4736 5.0W 390R
.2FLM 1 4872 1/4W 390R
.2FLM 3 4821 1/4W 470R
20 2030 1/6W 681R
.2FLM 2 6110 1/4W 1K0 1%MINI MF
1 4889 1/4W 1K3 5%
1 4825 1/4W 1K8 5%
5 4808 1/4W 2K
.2EL 4 4883 1/4W 2K49 1%
1 4864 1/4W 2K7 5%
6 4805 1/4W 2K87 1%
1 4992 1/4W 3K16 1%
2 4826 1/4W 3K3 5%
2 5030 1.0W 3K9 2%
.2EL 1 4774 1/4W 4K12 1%
2 4681 1.0W 4K7 5%
2 4827 1/4W 4K7 5%
2 4639 1/4W 4K99 1%
1 4778 1/4W 5K36 1%
P40 1 5001 1/4W 6K04 1%
P40 1 4828 1/4W 6K8 5%
4 4800 1/4W 10K0 1%
1 4775 1/4W 14K0 1%
5X20MM FUSE
T&R JMP
RAD JMP
BLK RES
5%FLAME PROOF T&R RES
5% T&R RES
5%FLAME PROOF T&R RES
2%FLAME PROOF T&R RES
FUSIBLE T&R RES
FUSIBLE T&R RES
5% T&R RES
5%MINI T&R RES
5% T&R RES
5%MINI T&R RES
5% T&R RES
5% T&R RES
5% T&R RES
1% T&R RES
5%MINI T&R RES
0.1% *** T&R RES
5% BLK RES
5% T&R RES
5% T&R RES
1%FLAME PROOF T&R RES
T&R RES
T&R RES
T&R RES
5% T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
T&R RES
Qty. YS # Description
3 4630 1/2W 15K 5% T&R RES
1 4830 1/4W 15K 5% T&R RES
8 4771 1/4W 17K8 1% T&R RES
7 6123 1/4W 20K0 1%MINI MF
3 4832 1/4W 22K 5% T&R RES
2 4840 1/4W 33K 5% T&R RES
2 4853 1/4W 39K 5% T&R RES
2 4908 1/4W 45K3 1% T&R RES
2 4834 1/4W 47K 5% T&R RES
1 4803 1/4W 49K9 1% T&R RES
6 4836 1/4W 68K 5% T&R RES
1 5007 1/4W 78K7 1% T&R RES
4 4772 1/4W 82K5 1% T&R RES
1 4838 1/4W 100K 5% T&R RES
2 4886 1/4W 200K 5% T&R RES
1 4879 1/4W 270K 5% T&R RES
2 4865 1/4W 390K 5% T&R RES
2 4843 1/4W 470K 5% T&R RES
1 4844 1/4W 1M 5% T&R RES
1 8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK
1 8799 #6 X 1/4 PAN PH TYPE B JS500
8 8902 4-40 X 3/4 PAN PHIL MS B/O & WAX
2 8807 6-32 X 5/16 PAN PH MS JS500
1 8801 6-32 X 3/8 PAN PH TAPTITE JS500
1 8829 6-32 X 3/8 FLAT PH TAPTITE BO#C HEA
2 8828 6-32 X 3/4 PAN PH TAPTITE JS500
7 8803 8-32 X 3/8 PAN PHIL TAPTITE JS500
1 8624 10-32 X 1/2 HEX HD MS JS500 BLK
2 8833 10-32 X 7/8 IND HEX M/S BLACK OXIDE
11 8736 5/16-18X2-3/4 GRD 5 HEX BOLT JS500
4 8656 .171 X 1/4 NYLON SPACER #SP42
1 3739 CUSTOM .4 LED SPACER
2 8652 SHOULDER WASHER .483" X .125" BLACK
2 8818 3/4 OD X 3/8 ID X .080 THICK WASHER
4 8817 #10 FLAT WASHER FOR 3/16" BOLT
2 3425 DPDT PUSH SW PCMT BREAK B4 MAKE
2 4119 DPDT PCB MNT SW 5A AC/PWR ON-ON
4 4123 SPST TOGGLE SW QUICK .250" 2 TERM
2 3392 250 MALE TAB .2IN
2 CH1413U XFMR:DNB SERIES
2
2 DNB112
2 7435 _8R 50W TWEETER PIEZO S
2 7547 12" 8R 300WPGM CER SPEAKER
2
4 DNB115
2 7435 _8R 50W TWEETER PIEZO S
2 7521 CELESTION 8OHM/15"/300WATT
4
5 DNB208
1 7435 _8R 50W TWEETER PIEZO S
4 7538 8"16R 150WPGM CER SPEAKER
1
4 DNB210
1 7435 _8R 50W TWEETER PIEZO S
2 7473 10" 16R 150WPG CER SPEAKER
2
1
1
3
4
15
2
1
5
3
1
1
1
4
1
3
4
6
7
1
1
4
25
3
Qty.
4
1
1
T&R RES 6
1
8
1
1
5
1
2
1
1
7
2
1
1
2
3
6
1
2
1
17
18
6
12
2
4
1
6
1
1
1
2
2
1
1
T&R 2
1
1
1
1
1
1
2
1
2
