Summary of Contents for EAW N T L 7 2 0

  • Page 1 N T L 7 2 0 L O U D S P E A K E R O W N E R ’ S M A N U A L...
  • Page 3: Safety Precautions - Read This First

    NTL720 Loudspeaker Owner’s Manual Congratulations on the purchase of your new EAW loudspeaker. You now own one of the finest professional audio products available - the result of exceptional engineering and meticulous craftsmanship. Please read these instructions to get the maximum performance from your new loudspeaker.
  • Page 4: Precauciones De Seguridad - Lea Esto Primero

    Lea y observe todos los avisos e instrucciones de seguridad que aparecen en el "Manual de altavoces EAW" adjunto antes de usar este aparato. El no observar esta precaución puede dar lugar a averías en el aparato, daños en las personas o incluso la muerte.
  • Page 5: Ec Declaration Of Conformity

    Tel: +1 866 858 5832 Director of Compliance Fax: +1 425 487 4337 LOUD Technologies Inc. e-mail: info@eaw.com Issued: February, 2008 1 . 3 F C C C o m p l i a n c e This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 6: Table Of Contents

    Contacting EAW ........
  • Page 7: Contents

    Power Cord AC Loop (Neutrik PowerCon to Neutrik PowerCon) USB cable 6 ft / 2 m NTL720 Owner’s Manual (this document) EAW Loudspeaker Owner’s Manual Warranty card RJ45 Ethernet Cable 2 ft / 0.6 m (Neutrik ® EtherCon ® )
  • Page 8: Quick Start

    NTL720 STANDBY DESIGNED IN WHITINSVILLE, MA, USA. MANUFACTURED N484 IN CHINA. ©2007 LOUD TECHNOLOGIES, INC. “EAW” IS A REGISTERED TRADEMARK OF LOUD TECHNOLOGIES, INC. THIS EQUIPMENT COMPLIES WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE AS DESCRIBED BY FCC RULES, AND THE CANADIAN DEPARTMENT OF COMMUNICATIONS, ICES-003.
  • Page 9: Initial Control Settings

    3 . 2 I n i t i a l C o n t r o l S e t t i n g s Use these nominal settings for the rear panel switches. These are multi-state “soft” switches that control software functions.
  • Page 10: Overview

    NTL720s are normally connected to the computer as a complete array. This is done by connecting the computer to one NTL720 via its USB port, or via the U-Net connection on an EAW UX8800 processor. The other NTL720s are connected to this one and each other using EAW’s U-Net network. The NTL720 connected to the computer (or UX8800) functions as a gateway to the U-Net network allowing EAWPilot to control individual elements within the array and the entire array as a whole.
  • Page 11: Amplification

    Note: EAWPilot and the NTL720 Array Wizard can be found in the Downloads/Software section of the EAW website (www.eaw.com). It’s a good idea to check the website periodically for updates to these software applications.
  • Page 12: Fill Coverage

    Automatic Mode: The interface will calculate the optimum number of enclosures, enclosure splays, array aiming angle, fly-bar pick point and user-control settings. This can also be done for a given inventory of NTL720s. Additional, user-variable criteria are provided for application-specific output levels and for level consistency for near-to-far listeners. Manual Mode: This provides complete control over the array’s configuration.
  • Page 13: Subwoofers

    Model Subwoofer Qty NTL720 5.4.2 RECOMMENDED SUBWOOFERS NTS22 Several of EAW’s SB Series of subwoofers are recommended as SBX220 complements to NTL720 line arrays in addition to the NTS22. These SB250z/SB600z include: SBX220, SB250z, SB600z, SB850z, SB1000z, SB1002, or BH760. Please contact the Application Support Group (ASG) for current SB850z subwoofer recommendations.
  • Page 14: Electrical Installation

    6.2.1 AC MAINS SUPPLY WARNING: Read all instruction and cautionary notes concerning electrical power in the “EAW Loudspeaker Owner’s Manual”. DANGER: Ensure that the AC mains voltage matches the voltage rating listed on the loudspeaker next to the AC Mains connector. DO NOT APPLY 230 V MAINS POWER IF THE VOLTAGE RATING ON THE LOUDSPEAKER IS 115 V.
  • Page 15: Ac Mains Cable

    6.2.1 NETZSTROMVERSORGUNG WARNUNG: Lesen Sie alle Anweisungen und Sicherheitshinweise bezüglich der Netzspannung in der EAW Lautsprecher Bedienungsanleitung. GEFAHR: Versichern Sie sch, dass die zur Verfügung stehende Netzspannung mit der auf der Rückseite des Lautsprechers angegebenen Spannung übereinstimmt. SCHLIESSEN SIE KEINE 230 V NETZSPANNUNG AN, WENN DER LAUTSPRECHER FÜR 115 V KONFIGURIERT...
  • Page 16: Cable De Alimentación

    6 . 3 C a b l e d e a l i m e n t a c i ó n El enchufe Neutrik PowerCon NAC3FCA incluido en el cable encaja en la toma de entrada Neutrik PowerCon NAC3MPA AC MAINS del altavoz. PRECAUCION: El enchufe que viene en el cable de alimentación incluido puede que no encaje en las salidas de corriente de su zona.
  • Page 17: Power Cord Receptacle

    CAUTION: To maintain all compliance ratings, keep AC input voltage between 100 V to 120 V or 220 V to 240 V. Replacement 115 V AC mains cord part number: 0021435 AC MAINS AC MAINS Replacement 230 V AC mains cord part number: 0015224 ~100 -20VAC ~220-240VAC 50-60Hz 350 W...
  • Page 18: Operating Temperature

    6 . 9 O p e r a t i n g Te m p e r a t u r e The operating temperature range is 32° F to 131° F / 0°C to 55° C. 6 . 1 0 I n p u t C o n n e c t i o n s 6.10.1 ANALOG SIGNAL INPUT CONNECTION The two XLR-type connectors on the rear of each NTL720, one female and one male, are designed for...
  • Page 19: 6 . 11 U - N E T C O N F I G U R A T I O N S

    The two, identical, locking Neutrik EtherCon connectors on the rear of each NTL720 combine an RJ45 PUSH connector with a locking shell. They are designed for connecting EAW’s audio and control signals between additional NTL720s and other U-Net enabled devices. Either connector may be used as the ports are bi-directional.
  • Page 20 6.11.2 CONNECTING ONE OR MORE NTL720s TO A COMPUTER USING A UX8800 Use the UX8800’s front panel Ethernet port and the supplied Ethernet crossover cable to connect directly to a computer’s 10, 10/100, or 100 Mbps Ethernet port. A user-supplied, shorter or longer cable may be substituted.
  • Page 21: Array Operation

    7.2.2 GUNNESS FOCUSING™ Developed by the EAW engineering team (and named after its inventor, David Gunness), Gunness Focusing uses DSP technology to eliminate the traditional characteristics of “honk” and “splashiness” that can plague horn-loaded loudspeaker designs. The honk of a horn is normally heard in the lower frequencies of its band pass, while splashiness (an attribute of compression drivers) is usually heard in the highest frequencies and obscures the fine detail in instruments, such as cymbals.
  • Page 22: Operating Controls

    7 . 3 O p e r a t i n g C o n t r o l s The operating controls on the NTL720 rear panel are momentary contact, “soft” switches. This means that they control software that does the actual switching with status lights indicating the switch “position.”...
  • Page 23: Signal Processing

    7.5.2 ARRAY MEASUREMENTS Smaart - The EAW Smaart program is an ideal tool to use to measure and optimize a NTL720 array for a particular venue. This is a fast, yet sophisticated, process that will indicate problem areas due to particular venue characteristics.
  • Page 24: Physical Installation

    PHYSICAL INSTALLATION NTL720 Series arrays are intended to be suspended or ground-stacked. This chapter details how to physically configure NTL720 Series arrays. The following are the recommended methods for most situations. Specific situations may require other methods. It is the user’s responsibility to determine the viability and safety for alternate methods and implement them accordingly.
  • Page 25: Service, Inspection, And Maintenance

    G e n e r a l S e r v i c e For any faults that cannot be field-repaired as noted below, contact the EAW Service Department listed in Section 9.6.2 to determine the appropriate action. This applies to both warranty and non-warranty faults.
  • Page 26 1. On each side of the loudspeaker, release the four panel screws that attach the enclosure to the rigging assembly. FULLY DISENGAGE THE PANEL’S 4X MOUNTING SCREWS FROM THE ENCLOSURE LEFT PANEL ASSEMBLY ENCLOSURE (MOUNTING POINTS INDICATED BY ARROWS) THE ENCLOSURE IS HELD IN THE ARRAY BY 8 SPRING LOADED SCREWS. 4 FROM THE LEFT PANEL AND 4 FROM THE RIGHT PANEL.
  • Page 27 If the fault is isolated to the internal electronics or wiring, repair of such faults must be done by the EAW factory service or by an authorized EAW distributor. Field Repair: The entire electronics assembly is replaceable with a factory-supplied assembly.
  • Page 28: Inspection And Maintenance

    I n s p e c t i o n a n d M a i n t e n a n c e Refer to Section 11 in the EAW Loudspeaker Owner’s Manual (included) for complete information on inspecting and maintaining EAW loudspeakers and rigging systems.
  • Page 29 Position Torque Requirement 81 kg-cm (70.3 lb-in) 75 kg-cm (65.1 lb-in) 36 kg-cm (31.3 lb-in) + Loctite 222 10 kg-cm (8.7 lb-in) Table 1 Page...
  • Page 30 (4) Panel screws on each side, accessible through holes in side panels, are to be fully engaged and secure. If loose, they should be fully released, apply Loctite® 222 to the threads, then re-assembled and set to 46 kg-cm (39.9 lb-in). Page...
  • Page 31: Contacting Eaw

    EAWPilot/NTL720 Array Wizard help files. Should you need further assistance, please do not hesitate to contact us. You can contact us in several different ways. 9.6.1 OPERATING QUESTIONS For questions about configuring or operating the loudspeakers, contact: EAW Applications Support Group 508-234-6158 800-992-5013 (USA only) 508-234-6479 e-mail asg@eaw.com...
  • Page 32: Signal Flow And Block Diagram

    SIGNAL FLOW AND BLOCK DIAGRAM 1 0 . 1 S i g n a l F l o w D i a g r a m The signal flow diagram shows the signal flow for two NTL720s. As can be seen, the audio input signal, AC mains, and the U-Net signal can be looped from one NTL720 to additional NTL720s.
  • Page 33: Ntl720 Block Diagram

    1 0 . 2 B l o c k D i a g r a m The block diagram shows the DSP blocks for the NTL720. The user DSP is configurable using the EAWPilot software application. The preset DSP is not user-configurable and is designed to optimize the performance of the NTL720s.
  • Page 34 Page...
  • Page 35 Page...
  • Page 36 One Main Street, Whitinsville, MA USA 01588 TEL 508-234-6158 FAX 508-234-6479 © 2008 LOUD Technologies Inc. All rights reserved. P/N 0025248 Rev. A 03/18/08...
