EAW DC6i 2D Dimensional Drawing

NOTES:

1. SYMBOL INDICATES MOUNTING POINT, 3/8-16 THREADED HOLE (PI ANGLE).
2. SYMBOL INDICATES MOUNTING POINT, 3/8-16 THREADED HOLE (NUT PLATE).
3. SYMBOL INDICATES CENTER OF BALANCE.

4. WEIGHT APPROX. 56 LBS.

5. SHIPPING WEIGHT APPROX. 64 LBS.

5.38
[136.7]
TOP
30.00
[762.0]
13.35
[339.2]
5.59
[142.0]
10.62
[269.6]
FRONT
GRILL PARTIALLY SHOWN
26.07
[662.2]
L C
3.00
[76.2]
9.53
[242.1]
5.62
[142.6]
A
3.90
[99.0]
2.28
[58.1]
4.34
[110.1]
6.28
[159.5]
LEFT SIDE
DIMENSIONS APPLY
TO BOTH SIDES
1.63
[41.3]
6.00
[152.4]
VIEW A-A
3.63
[92.2]
A
1.91
[48.5]

PRODUCTION

DC6i
6.63
[168.4]
L C
BACK
INPUT
EASTERN ACOUSTIC WORKS
