After clicking Next, you can see the following page which will vary according to the IPv4
protocol type selected in Step 1.
For Static type, the page will be displayed as follows:
Available settings are explained as follows:
Item
IP Address
Subnet Mask
Gateway IP Address
DNS Server IP
Address
Description
Type the IP address of the router for the WAN profile.
Choose the static mask from the drop down list.
Type a public gateway address for such WAN profile.
- click it to remove the IP address if you are not
satisfied with it.
Type a public IP address as the primary DNS (Domain Name
Server). To add a new IP address, simply Add. Four boxes
will appear for you to type the IP address. When you finish
the settings, click Save.
19
Vigor300B Quick Start Guide
