Page 1: Quick Start Guide
VigorIPPBX 2820 Series Quick Start Guide Version: 1.0 Date: 2009/1/12... -
Page 2: Copyright Information
Web registration is preferred. You can register your Vigor router via Owner http://www.draytek.com. Firmware & Tools Due to the continuous evolution of DrayTek technology, all routers will be Updates regularly upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and documents. -
Page 3: European Community Declarations
No. 26, Fu Shing Road, HuKou, HsinChu Industrial Park, Hsin-Chu County, Taiwan 303 Product: VigorIPPBX 2820 DrayTek Corp. declares that VigorIPPBX 2820 is in compliance with the following essential requirements and other relevant provisions of R&TTE Directive 1999/5/EEC. The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by complying with the requirements set forth in EN55022/Class B and EN55024/Class B. -
Page 4: Table Of Contents
1. Introduction......................1 1.1 Panel Explanation ........................2 1.2 Package Content........................4 2. Installing Your Router................... 5 2.1 Hardware Installation........................5 2.2 ISDN Phone Adapter Installation....................6 2.3 Printer Installation........................8 3. Configuring Web Pages ..................13 4. Trouble Shooting ....................17 4.1 Checking If the Hardware Status Is OK or Not................. -
Page 5: Introduction
The VigorIPPBX 2820 is an ADSL2+ router with IP PBX function and 2 Ethernet WAN. This 2 WAN can connect to DSL/Cable modem or fiber media converter for policy-based load-balance, fail-over and BoD (Bandwidth on Demand); it also features advanced bandwidth control mechanism such as IP-layer QoS, NAT Session Limitation, Bandwidth Borrowed, etc., to allow easy, flexible, reliable access control and bandwidth management. -
Page 6: Panel Explanation
Status Explanation ACT (Activity) Blinking The router is powered on and running normally. The router is powered off. A USB device is connected and active. Blinking The data is transmitting. The profile of CSM (Content Security Management) for IM/P2P application is enabled from Firewall >> General Setup. - Page 7 Right LED A phone adapter with phone set has been connected (Green) (ISDN-S0) or ISDN line has been connected (ISDN-TE). Blinking ISDN-S0 (ISDN-NT) mode, it means an ISDN phone is off-hook or a phone call comes. In ISDN-TE mode, it means data, fax or voice (phone call) is transmitting.
-
Page 8: Package Content
Quick Start Guide RJ-45 Cable (Ethernet) RJ-11 to RJ-11 Cable for Annex A RJ-45 to RJ-45 Cable for Annex B RJ-45 to RJ-11 Cable for Annex B ISDN Phone Adapter Antenna (n models) The type of the power adapter depends on the country that the router will be installed. * The maximum power consumption is 17-23 Watt. -
Page 9: Installing Your Router
This section will guide you to install the router through hardware connection and configure the router’s settings through web browser. Before starting to configure the router, you have to connect your devices correctly. Connect the ADSL interface to the external ADSL splitter with an ADSL line cable. Also, connect Line interface to an external ADSL splitter. -
Page 10: Isdn Phone Adapter Installation
Caution: Each of the Phone ports can be connected to an analog phone only. Do not connect the phone ports to the telephone wall jack. Such connection might damage your router. ISDN1/2 port is configurable as NT or TE mode. When the user configures ISDN port as NT mode in IP PBX>>PBX System>>Phone Settings, the orange LED will light on to indicate ISDN-NT is selected. - Page 11 Yet, if the user configures ISDN port as TE Mode in IP PBX>>PBX System>>Phone Settings, the green LED will light on to indicate ISDN-TE is selected. Then, the port is specified for ISDN line only. Refer to the following figure for reference.
-
Page 12: Printer Installation
You can install a printer onto the router for sharing printing. All the PCs connected this router can print documents via the router. The example provided here is made based on Windows XP/2000. For Windows 98/SE, please visit www.draytek.com. Before using it, please follow the steps below to configure settings for connected computers (or wireless clients). - Page 13 Open File->Add a New Computer. A welcome dialog will appear. Please click Next. Click Local printer attached to this computer and click Next. In this dialog, choose Create a new port Type of port and use the drop down list to select Standard TCP/IP Port.
- Page 14 In the following dialog, type 192.168.1.1 (router’s LAN IP) in the field of Printer Name or IP Address and type IP_192.168.1.1 as the port name. Then, click Next. Click Standard and choose Generic Network Card. Then, in the following dialog, click Finish.
- Page 15 Now, your system will ask you to choose right name of the printer that you installed onto the router. Such step can make correct driver loaded onto your PC. When you finish the selection, click Next. 10. For the final stage, you need to go back to Control Panel-> Printers and edit the property of the new printer you have added.
- Page 16 If you do not know whether your printer is supported or not, please visit www.draytek.com to find out the printer list. Open Support Center->FAQ; find out the link of Printer Server FAQ; finally click the link of “What types of printers are compatible with Vigor router?”.
-
Page 17: Configuring Web
To access Internet, please finish basic configuration after completing the hardware installation. The Quick Start Wizard is designed for you to easily set up your router for Internet access. You can directly access the Quick Start Wizard via Web Configurator. Make sure your PC connects to the router correctly. - Page 18 Enter the login password on the field of New Password and retype it on the field of Retype New Password. Then click Next to continue. On the next page as shown below, please select the WAN interface (WAN 1 or WAN2) that you use.
- Page 19 On the next page as shown below, please select the appropriate Internet access type according to the information from your ISP. For example, you should select PPPoE mode if the ISP provides you PPPoE interface. Then click Next for next step. PPPoE/PPPoA: if you click PPPoE or PPPoA as the protocol, please manually enter the Username/Password provided by your ISP.
- Page 20 1483 Bridged IP /1483 Routed IP: if you choose 1483 Bridged IP / 1483 Routed IP as the protocol, you will get the following page. Please type in the IP address information originally provided by your ISP. Then click Next for next step. Now you can see the following screen.
-
Page 21: Trouble Shooting
This section will guide you to solve abnormal situations if you cannot access into the Internet after installing the router and finishing the web configuration. Please follow sections below to check your basic installation status stage by stage. Checking if the hardware status is OK or not. Checking if the network connection settings on your computer are OK or not. - Page 22 The example is based on Windows XP. As to the examples for other operation systems, please refer to the similar steps or find support notes in www.draytek.com. Go to Control Panel and then double-click on Network Connections. Right-click on Local Area Connection and click on Properties.
- Page 23 Select Obtain an IP address automatically and Obtain DNS server address automatically. Double click on the current used MacOs on the desktop. Open the Application folder and get into Network. On the Network screen, select Using DHCP from the drop down list of Configure IPv4.
-
Page 24: Pinging The Router From Your Computer
The default gateway IP address of the router is 192.168.1.1. For some reason, you might need to use “ping” command to check the link status of the router. The most important thing is that the computer will receive a reply from 192.168.1.1. If not, please check the IP address of your computer. -
Page 25: Checking If The Isp Settings Are Ok Or Not
Open WAN >> Internet Access page and then check whether the ISP settings are set correctly. Click WAN1 or WAN2 link to review the settings that you configured previously. Check if the Enable option is selected. Check if Username and Password are entered with correct values that you got from your ISP. - Page 26 Check if the Enable option is selected. Check if IP address, Subnet Mask and Gateway are entered with correct values that you got from your ISP.
- Page 27 Check if the Enable option is selected. Check if DSL Modem Settings is set appropriately. Check if IP Address, Subnet Mask and Gateway are set correctly (must identify with the values from your ISP) if you choose Specify an IP address. Check if the Enable option for PPTP Link is selected.
-
Page 28: Backing To Factory Default Setting If Necessary
Check if PPTP Server, Username, Password and WAN IP address are set correctly (must identify with the values from your ISP). Sometimes, a wrong connection can be improved by returning to the default settings. Try to reset the router by software or hardware. Warning: After pressing factory default setting, you will loose all settings you did before. -
Page 29: Contacting Your Dealer
After restore the factory default setting, you can configure the settings for the router again to fit your personal request. If the router still cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@draytek.com.
