1995-96 ACCESSORIES & EQUIPMENT

Volvo Power Sun Roofs

850

DESCRIPTION & OPERATION

Vehicles may be equipped with a manual or power-operated sun

roof. If battery voltage is lost or interrupted, power sun roof can be

operated manually.

DIAGNOSIS & TESTING

NOTE:

Power sun roof diagnosis and testing is not supplied by

manufacturer.

ADJUSTMENTS

Sun roof should be level with roof line, but about .04" (1.0

mm) lower at forward edge. Adjusting screw No. 1 adjusts forward edge

lengthwise and up and down. Screw No. 2 is used for lengthwise

adjustment. Screw No. 3 adjusts height of rear edge. Ensure sun roof

adjustment on each side is equal. After adjustment, ensure sun roof is

operating by opening and closing it as far as it will go.

REMOVAL & INSTALLATION

CONTROL MODULE

Removal & Installation

Close sun roof. Remove roof light panel, consisting of light

glass, retaining screws and connector. Remove control module screw.

See Fig. 1. Pry control module straight down and forward. Disconnect

inner connector and remove control module. To install, reverse removal

procedure. Ensure 2 White markings are correctly positioned.

See Fig. 1.

Fig. 1:

Removing & Installing Control Module

Courtesy of Volvo Cars of North America.

SUN ROOF

SUN ROOF - POWER

1995 Volvo 850

Page 1 See Fig. 1. Pry control module straight down and forward. Disconnect inner connector and remove control module. To install, reverse removal procedure. Ensure 2 White markings are correctly positioned. See Fig. 1. Fig. 1: Removing & Installing Control Module Courtesy of Volvo Cars of North America. SUN ROOF...
Page 2 2) New motors are supplied calibrated, and require no adjustment when installing. Move emergency release screw back and forth slightly with a screwdriver to ensure gear and cable engage each other securely in cable housing. Fig. 2: Removing Sun Roof Motor Courtesy of Volvo Cars of North America.
Page 3 Fig. 3: Positioning Sun Roof Hatch Mechanism Courtesy of Volvo Cars of North America. WIRING DIAGRAMS Fig. 4: Power Sun Roof System Wiring Diagram (1995-96)
