VOLVO XC60

OWNERS MANUAL

Web Edition

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the XC60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Volvo XC60

Page 1: Owners Manual
VOLVO XC60 OWNERS MANUAL Web Edition...
Page 3 DEAR VOLVO OWNER THANK YOU FOR CHOOSING VOLVO We hope you will enjoy many years of driving pleasure in your Volvo. In order to increase your enjoyment of the car, we recommend that The car has been designed for the safety and comfort of you and your you familiarise yourself with the equipment, instructions and mainte- passengers.
Page 4: Table Of Contents
00 Introduction 01 Safety 02 Locks and alarm Important information......... 8 Seatbelts ..........18 Remote control key/key blade....46 Volvo and the environment....... 12 Airbags............21 Battery replacement, remote control key/ PCC*............51 Activating/deactivating the airbag*... 24 Keyless drive*..........53 Side airbags (SIPS bags) ......
Page 5 Table of contents 03 Your driving environment 04 Comfort and driving pleasure 05 Infotainment system Instruments and controls......66 Menus and messages......128 General information on infotainment..202 Key positions..........74 Menu source MY CAR......130 Quick start..........204 Seats............76 Climate control........
Page 6 Table of contents 06 During your journey 07 Wheels and tyres 08 Maintenance and service Recommendations during driving... 252 General ........... 274 Engine compartment....... 290 Refuelling..........255 Changing wheels ........278 Lamps............. 297 Fuel............256 Tyre pressure ......... 281 Wiper blades and washer fluid....303 Loading...........
Page 7 Table of contents 09 Specifications 10 Alphabetical Index Type designations........324 Alphabetical Index........354 Dimensions and weights......326 Engine specifications......330 Engine oil..........331 Fluids and lubricants....... 333 Fuel............335 Wheel and tyres, dimensions and pres- sure ............336 Electrical system........337 Type approval.........
Page 8: Introduction
Important information Reading the Owner's Manual In the event of uncertainty over what is stand- lighted in the owner's manual by means of the ard or an option/accessory, contact a Volvo text being slightly larger and printed in grey. Introduction dealer.
Page 9 Introduction Important information warning is ignored, may result in serious per- Information Procedure lists sonal injury or fatality. Procedures where action must be taken in a certain sequence are numbered in the owner's Risk of property damage manual. When there is a series of illustrations for step-by-step instructions each step is numbered in the same way as the corres- ponding illustration.
Page 10 This symbol is located furthest down to the function when their associated software is laser product. right when a section continues on the following installed in the car's computer system. Volvo The lower label in the figure describes the laser page. therefore recommends that you always con-...
Page 11 For more information on the laser sensor, see sor's spare parts must only be carried page 169. out by a qualified workshop - we rec- ommend an authorised Volvo work- shop. Information on the Internet • To avoid exposure to harmful radiation, At www.volvocars.com there is further infor-...
Page 12: Volvo And The Environment
Introduction Volvo and the environment Volvo Cars' environmental philosophy Environmental care is one of Volvo Car Corpo- fuel consumption many cases the exhaust emissions are well ration's core values which influence all opera- below the applicable standards. Volvo cars have competitive fuel consumption tions.
Page 13 Textile standard impact - here are a few tips: durability is extended. For more information The interior of a Volvo is designed to be plea- and further advice, see page 252. • sant and comfortable, even for people with Avoid letting the engine idle - switch off the engine when stationary for longer periods.
Page 14 Introduction Volvo and the environment...
Page 15 Introduction...
Page 16 Seatbelts ....................18 Airbags....................21 Activating/deactivating the airbag*............24 Side airbags (SIPS bags) ............... 26 Inflatable Curtain (IC) ................28 WHIPS ....................29 Roll-Over Protection System - ROPS............. 31 When the systems deploy ..............32 Safety mode.................... 33 Child safety..................... 34 Option/accessory, for more information, see Introduction.
Page 17 S A F E T Y...
Page 18: 01 Safety
WARNING The seatbelt locks and cannot be with- drawn: Never modify or repair the seatbelts your- self. Volvo recommends that you contact an • if it is pulled out too quickly authorised Volvo workshop. • during braking and acceleration If a seatbelt has been subjected to a major •...
Page 19 01 Safety Seatbelts Seatbelts and pregnancy and steering wheel). The aim should be to posi- Rear seat tion the seat with as large a distance as possi- The seatbelt reminder in the rear seat has two ble between abdomen and steering wheel. subfunctions: •...
Page 20 01 Safety Seatbelts Certain markets An acoustic signal and indicator lamp remind the driver and front seat passenger to use a seatbelt if either of them is not wearing one. At low speed, the audio reminder will sound for the first 6 seconds. Seatbelt tensioner All the seatbelts are equipped with belt ten- sioners.
Page 21: Airbags
Defective work in the airbag system could tem, SIPS, the IC system or some other fault cause malfunction and result in serious per- in the system. Volvo recommends that you sonal injury. contact an authorised Volvo workshop immediately.
Page 22 01 Safety Airbags Passenger airbag NOTE The car has an airbag to supplement the pro- The sensors react differently depending on tection afforded by the seatbelt on the passen- the course of the collision and whether or ger side. It is folded up into a compartment not the seatbelts on the driver and passen- above the glovebox.
Page 23 01 Safety Airbags WARNING Never place a child in a child seat or on a booster cushion in the front seat if the airbag is activated. Never allow anybody to stand or sit in front of the front passenger seat. No one shorter than 140 cm should ever sit in the front passenger seat if the airbag is activated.
Page 24: Activating/Deactivating The Airbag
Visit a workshop as soon as possible. Volvo WARNING passenger seat, but never persons taller recommends that you contact an author- than 140 cm.
Page 25 01 Safety Activating/deactivating the airbag* A text message and a symbol in the roof panel WARNING NOTE indicate that the airbag for the front passenger Activated airbag (passenger seat): When the remote control key is turned to seat is deactivated (see preceding illustration). key position II or III the warning symbol for Never place a child in a child seat or on a the airbag is displayed on the combined...
Page 26: Side Airbags (Sips Bags)
• Volvo recommends the use only of car seat covers approved by Volvo. Other seat covers may impede the operation Driver's seat, left-hand drive.
Page 27 01 Safety Side airbags (SIPS bags) the sensors and the side airbags are inflated. The airbag inflates between the occupant and the door panel and thereby cushions the initial impact. The airbag deflates when compressed by the collision. The side airbag is normally only deployed on the side of the collision.
Page 28: Inflatable Curtain (Ic)
This could compromise the intended pro- tection. Volvo recommends that you only ever use Volvo genuine parts that are approved for placement in these areas. WARNING The inflatable curtain IC (Inflatable Curtain) is a Do not load the car higher than 50 mm under part of SIPS and the airbags.
Page 29: Whips
Never modify or repair the seat or WHIPS system yourself. Volvo recommends that WARNING you contact an authorised Volvo workshop. Do not squeeze rigid objects between the rear seat cushion and the front seat back- WHIPS system and child seats/booster rest.
Page 30 WARNING If a seat has been subjected to extreme forces, such as due to a rear-end collision, the WHIPS system must be checked. Volvo recommends that it is checked by an authorised Volvo workshop. Part of the WHIPS system's protective capacity may have been lost even if the seats appear to be undamaged.
Page 31: Roll-Over Protection System - Rops
01 Safety Roll-Over Protection System - ROPS Function Volvo's Roll-Over Protection System (ROPS) has been designed to reduce the risk of the car overturning and to provide the best possible protection in the event of such an accident. The system consists of a stabiliser system,...
Page 32: When The Systems Deploy
Recovering the car. Volvo recommends that Whiplash protection In a rear-end colli- you have it conveyed to an authorised Volvo WHIPS sion workshop. The bodywork of the car could be greatly deformed in a col- lision without airbag deployment.
Page 33: Safety Mode
Even if the car appears to be towed. It must be transported from its loca- driveable, hidden damage may make the car tion. Volvo recommends that it is transpor- impossible to control once moving. ted to an authorised Volvo workshop.
Page 34: Child Safety
In the event of questions when fitting child Volvo recommends that children travel in rear- Look in the installation instructions for the child safety products, contact the manufacturer facing child seats until as late an age as pos- for clearer instructions.
Page 35 01 Safety Child safety Label Airbag WARNING WARNING Never place a child in a child seat or on a Booster cushions/child seats with steel booster cushion in the front seat if the airbag braces or some other design that could rest (SRS) is activated.
Page 36 Front seat (with deactivated air- Outer rear seat Centre rear seat bag) Group 0 Volvo infant seat (Volvo Infant Seat) - Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, secured with the rear-facing child seat, secured with the max 10 kg ISOFIX fixture system.
Page 37 Centre rear seat bag) Group 1 Volvo rear-facing/turnable child seat Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear- (Volvo Convertible Child Seat) - rear- 9-18 kg facing child seat, secured with the facing child seat, secured with the car's seatbelt and straps.
Page 38 Group 2 Volvo rear-facing/turnable child seat Volvo rear-facing/turnable child seat Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear- (Volvo Convertible Child Seat) - rear- (Volvo Convertible Child Seat) - rear- 15-25 kg facing child seat, secured with the...
Page 39 01 Safety Child safety Integrated two-stage booster The booster cushions are specially designed to Raising the two-stage booster cushion provide optimum safety. In combination with cushions* Stage 1 the seatbelt they are approved for children who weigh between 15 and 36 kg and who are at least 95 cm in height.
Page 40 WARNING Volvo recommends that repair or replace- ment is only carried out by an authorised Volvo workshop. Do not make any modifi- cations or additions to the booster cushion. If an integrated booster cushion has been subjected to a major load, such as in con- junction with a collision, the entire booster cushion must be replaced.
Page 41 01 Safety Child safety ISOFIX fixture system for child seats Size classes Press down with your hand in the centre of Child seats are in different sizes – cars are in the cushion in order to lock it. different sizes. This means that not all child seats are suitable for all seats in all car models.
Page 42 Never place a child in the passenger seat if Volvo recommends that you contact an the car is equipped with an activated airbag. authorised Volvo dealer for recommenda- Transverse infant seat, left- tions about which ISOFIX child seats Volvo hand recommends. NOTE Transverse infant seat, right-...
Page 43 Front seat Outer rear seat Front-facing child seat 9-18 kg Volvo recommends rear-facing child seats for this group. Upper mounting points for child seats Volvo recommends that small children should points, see the seat manufacturer's instruc- sit in rear-facing child seats to as late an age tions.
Page 44 Remote control key/key blade..............46 Battery replacement, remote control key/PCC*........51 Keyless drive*..................53 Locking/unlocking................... 56 Child safety locks..................61 Alarm*...................... 62 Option/accessory, for more information, see Introduction.
Page 45 L O C K S A N D A L A R M...
Page 46: 02 Locks And Alarm
- an authorised confirm that locking/unlocking was correctly Volvo workshop is recommended. The remain- ing remote control keys must then be taken to performed. the workshop. The code of the missing remote •...
Page 47 Panic function dation is to contact WARNING an authorised Volvo If the sunroof and windows are closed using workshop. the remote control key, check that no one is in danger of getting hands caught.
Page 48 02 Locks and alarm Remote control key/key blade Press and hold (at least 4 seconds) to open all 5 seconds. Otherwise the function switches off Unique functions PCC* windows simultaneously. automatically after 2 minutes and 45 seconds. The function can be changed from unlocking Range all doors simultaneously, to unlocking the driv- The remote key's functions have a range of...
Page 49 PCC and the car was elled around on the PCC), contact a work- disrupted by surrounding radio waves, Range PCC shop - an authorised Volvo workshop is rec- buildings, topographical conditions etc. The PCC's range for locking, unlocking and ommended.
Page 50 02 Locks and alarm Remote control key/key blade • access to the glovebox can be blocked. 2. Lightly press the key blade. You should hear a "click" when the key blade is locked • the airbag for front passenger seat (PACOS)* can be activated/deactivated, see page 24.
Page 51: Battery Replacement, Remote Control Key/Pcc
02 Locks and alarm Battery replacement, remote control key/PCC* Replacing the battery Battery replacement Closely study how the battery/batteries are The batteries should be replaced if: secured on the inside of the cover, with • the information symbol is illuminated and regard to their (+) and (–) sides.
Page 52 02 Locks and alarm Battery replacement, remote control key/PCC* IMPORTANT Make sure that you dispose of old batteries in an environmentally-friendly way. Option/accessory, for more information, see Introduction.
Page 53: Keyless Drive
02 Locks and alarm Keyless drive* Keyless lock and ignition system (only the car door handle or tailgate. This means that reactivated. It is therefore important to handle the person who wishes to lock or unlock a door all PCCs with great care. must have the PCC with him or her.
Page 54 02 Locks and alarm Keyless drive* Locking Unlocking 2. Insert the key blade in the lock cylinder and unlock the door. Unlocking takes place when a hand grasps a door handle or the tailgate's rubberised pres- 3. Refit the plastic cover after unlocking. sure plate is actuated - open the door or tail- gate as normal.
Page 55 02 Locks and alarm Keyless drive* presses their PCC's unlock button, see The keyless system has a number of integrated page 47. antennae located around the car: • Select one of three possible memories for Tailgate, by wiper motor seat adjustment with seat button 1-3, see Door handle, left rear page 77.
Page 56: Locking/Unlocking
02 Locks and alarm Locking/unlocking • From the outside From the inside Pull the door handle once and release - the door is unlocked. Pull the door handle The remote control key can lock/unlock all Central locking again to open the door. doors and the tailgate simultaneously.
Page 57 02 Locks and alarm Locking/unlocking Glovebox Tailgate IMPORTANT • Manual opening Minimal force is required to release the rear hatch lock - just gently press the rubberised panel. • Do not place the lift force on the rubber panel when opening the rear hatch - lift the handle.
Page 58 02 Locks and alarm Locking/unlocking armed. The alarm's level and movement sen- Locking with the remote control key IMPORTANT ± sors and the sensors for opening the tailgate Press the remote control key's button for Bear in mind roof height during electrical are disconnected.
Page 59 02 Locks and alarm Locking/unlocking • Pinch protection Push down gently on the rubberised pres- Deadlocks* sure plate under the outer handle. If something with sufficient resistance prevents Deadlocks means that all lock buttons and the tailgate from opening/closing then the door handles are mechanically disengaged, Closing the tailgate pinch protection is activated.
Page 60 02 Locks and alarm Locking/unlocking Temporary deactivation > The instrument panel display shows the NOTE Reduced guard See message • Remember that the car's alarm is armed manual and the deadlocks function is when the car is locked. switched off when the car is locked. •...
Page 61: Child Safety Locks
02 Locks and alarm Child safety locks Manual blocking of the rear doors The child safety locks are activated/deacti- NOTE vated in all key positions (see page 74 and up The child safety locks prevent children from • A door's knob control only blocks that to 2 minutes after the remote control key has opening a rear door from the inside.
Page 62: Alarm
Press the remote control key unlock but- mation display shows a message. In which could affect the terms of insurance. ton. case, contact a workshop - an authorised Volvo workshop is recommended. Deactivating a triggered alarm Alarm indicator ± NOTE...
Page 63 02 Locks and alarm Alarm* Alarm signals Reduced alarm level When the alarm is triggered, the following hap- To avoid accidental triggering of the alarm - pens: e.g. if a dog is left in the car or during transport on a car train or a car ferry - the movement and •...
Page 64 Instruments and controls................ 66 Key positions..................74 Seats....................... 76 Steering wheel..................81 Lighting....................82 Wipers and washing................91 Windows, rearview and door mirrors............94 Compass*....................99 Power panorama roof* ................. 100 Alcoguard*.................... 103 Starting the engine................107 Starting the engine – external battery........... 109 Gearboxes.....................
Page 65 Y O U R D R I V I N G E N V I R O N M E N T...
Page 66: 03 Your Driving Environment
03 Your driving environment Instruments and controls Instrument overview Left-hand drive.
Page 67 03 Your driving environment Instruments and controls Function Page Function Page Menus and messages, Control for infotainment 130, 245 direction indicators, 85, 128, and menu control main/dipped beam, trip Control panel for climate computer control Cruise control 155, 157 Gear selector Horn, airbags 22, 81 Controls for active chas-...
Page 68 03 Your driving environment Instruments and controls Right-hand drive.
Page 69 03 Your driving environment Instruments and controls Information displays Function Page Function Page Display for infotainment 130, Bonnet opener and menus 205, 245 Steering wheel adjust- Ignition switch ment Start/stop button Menus and messages, direction indicators, 85, 128, Cruise control 155, 157 main/dipped beam, trip computer...
Page 70 03 Your driving environment Instruments and controls Meters Indicator, information and warning symbols go out after 5 seconds except the symbol for faults in the car's emissions system symbols and the symbol for low oil pressure. Indicator and information symbols Sym- Specification ABL fault...
Page 71 03 Your driving environment Instruments and controls seek assistance from an authorised Volvo NOTE Sym- Specification workshop. When a service message is shown, the sym- Rear fog lamp on bol and message are cleared using the Left-hand direction indicators This symbol illuminates when the rear fog lamp READ button, or clear automatically after a is on.
Page 72 03 Your driving environment Instruments and controls to have the system checked. Volvo recom- page 295. If the brake fluid level is nor- Symbol Specification mal but the symbols are still illuminated, mends that you seek assistance from an the car can be driven, with great care, to authorised Volvo workshop.
Page 73 03 Your driving environment Instruments and controls also illuminate in conjunction with other sym- Trip meter Clock bols. Action: 1. Stop in a safe place. Do not drive the car further. 2. Read the information on the information display. Implement the action in accord- ance with the message in the display.
Page 74: Key Positions
03 Your driving environment Key positions Insert and remove the remote control Key position I IMPORTANT With the remote control key fully inserted into Foreign objects in the ignition switch may the ignition switch - Briefly press START/ jeopardise the function or destroy the lock. STOP ENGINE.
Page 75 03 Your driving environment Key positions Posi- Function tion Odometer, clock and tempera- ture gauge are illuminated. The steering lock is deactivated. The audio system can be used. Panorama roof*, power windows, 12 V socket in the passenger compartment, RTI*, phone*, ven- tilation fan, ECC and windscreen wipers can be used.
Page 76: Seats
03 Your driving environment Seats Front seats Lift the catches on the rear of the backrest WARNING and fold it forward. Adjust the position of the driver's seat 4. Push the seat forward so that the head before setting off, never while driving. Make sure that the seat is in locked position in restraint "locks"...
Page 77 03 Your driving environment Seats Power seat* trol key without the key in the ignition switch. 2. Hold the button depressed to store set- Seat adjustment is normally made in key posi- tings while depressing one of the memory buttons. tion I and can always be made when the engine is running.
Page 78 03 Your driving environment Seats door is opened, the driver's seat and also the unlock button on the remote control key. The Adjust the head restraint according to passen- door mirrors automatically adopt the positions driver's door must then be open. ger height so that the whole of the back of the stored in the key memory.
Page 79 03 Your driving environment Seats Lowering the rear seat backrest Raising takes place in reverse order. NOTE IMPORTANT When the backrest has been raised, the red There must be no objects on the rear seat indicator should no longer be showing. If it when the backrest is to be folded down.
Page 80 03 Your driving environment Seats 1. The remote control key must be in position I or II. 2. Press the button to lower the rear outer head restraints to improve rearward visi- bility. WARNING Do not lower the outer head restraints if there are any passengers using of the outer seats.
Page 81: Steering Wheel
03 Your driving environment Steering wheel Adjusting Horn WARNING Adjust and secure the steering wheel before driving. With speed related power steering* the level of steering force can be adjusted, see page 154. Keypads* Adjusting the steering wheel. Horn. Lever - releasing the steering wheel Press the centre of the steering wheel to signal.
Page 82: Lighting
03 Your driving environment Lighting Light switches The intensity of the instrument lighting is Main/dipped beam adjusted with the thumbwheel. Headlamp levelling The load in the car changes the vertical align- ment of the headlamp beam, which could daz- zle oncoming motorists. Avoid this by adjusting the height of the beam.
Page 83 03 Your driving environment Lighting deactivated by a workshop. Volvo recom- Active Xenon headlamps - ABL* Posi- Specification mends that you contact an authorised Volvo tion workshop. Automatic /deactivated dipped In position dipped beam is always acti- beam. Only main beam flash.
Page 84 The function can be deactivated/activated in behind. The rear fog lamp consists of one rear lamp and the menu system MY CAR under My XC60 can only be switched on in combination with Active bending lights or under Settings main/dipped beam.
Page 85 03 Your driving environment Lighting The rear fog lamp is switched off automatically automatically when the car is driven off again Continuous flash sequence when the engine is switched off. or the button is depressed. For more informa- Move the stalk switch up or down to the tion on Emergency brake lights and automatic outer position.
Page 86 03 Your driving environment Lighting All lighting in the passenger compartment can Lighting, cargo area be switched on and off manually within The lighting in the cargo area is switched on 30 minutes from when: and off respectively when the tailgate is opened or closed.
Page 87 03 Your driving environment Lighting • the engine is started Adjusting headlamp pattern settings Light settings Home safe light • duration. For a description of the menu sys- the car is locked. tem, see page 130. The passenger compartment lighting comes on and remains on for two minutes if one of the doors is open.
Page 88 03 Your driving environment Lighting Active Xenon headlamps* 3. Position the self-adhesive templates at the right distance from the edge of the head- The car must be stationary with the engine run- lamp lens using the illustration, see ning when the headlamp pattern is shifted page 89, and the dimensions in the fol- between right and left-hand traffic.
Page 89 03 Your driving environment Lighting Aligning the templates Upper row: masking left-hand drive cars, templates A and B. Lower row: masking right-hand drive cars, templates C and D.
Page 90 03 Your driving environment Lighting Templates for halogen headlamps...
Page 91: Wipers And Washing
03 Your driving environment Wipers and washing Continuous wiping the rain sensor can be adjusted using the Windscreen wipers thumbwheel. The wipers sweep at normal speed. When the rain sensor is activated a light in the The wipers sweep at high speed. button the rain sensor symbol is shown in the right-hand display in the combined...
Page 92 03 Your driving environment Wipers and washing The rain sensor is automatically deactivated Washing the windscreen Wiper and washer, rear window when the remote control key is removed from Move the stalk switch toward the steering the ignition switch or five minutes after the wheel to start the windscreen and headlamp engine has been switched off.
Page 93 On cars with rain sensor, the rear window wiper is activated with reversing, if the sen- sor is activated and it is raining. This function (intermittent wiping when reversing) can be deactivated. Visit a workshop. Volvo recommends that you contact an authorised Volvo workshop.
Page 94: Windows, Rearview And Door Mirrors
03 Your driving environment Windows, rearview and door mirrors General Heat-reflecting windscreen* windscreen with no heat-reflecting film (see the highlighted area in the above illustration). Laminated glass The windscreen and panorama roof Power windows have laminated glass. It is reinforced which provides better protection against break-ins and improved sound insulation in the passenger compart-...
Page 95 03 Your driving environment Windows, rearview and door mirrors All power windows can be operated using the Operating with auto WARNING control panel in the driver's door. Each control Move one of the controls up/down to the end Make sure that children or other passengers panel in the other doors can only control its position and release it.
Page 96 03 Your driving environment Windows, rearview and door mirrors Door mirrors Retractable power door mirrors* Angling the door mirror when parking The mirrors can be retracted for parking/driving The door mirror can be angled down for the in narrow spaces: driver to view the side of the road when parking for example.
Page 97 03 Your driving environment Windows, rearview and door mirrors Automatic retraction when locking Rear window and door mirror . For a description of the menu sys- defrosters tem, see page 130. When the car is locked/unlocked with the remote control key the door mirrors are auto- matically retracted/extended.
Page 98 03 Your driving environment Windows, rearview and door mirrors Automatic dimming* Bright light from behind is automatically dimmed by the rearview mirror. The control is not available in mirrors with automatic dim- ming. The compass* can only be specified for rear- view mirrors with automatic dimming, see page 99.
Page 99: Compass
03 Your driving environment Compass* Operation should be calibrated if the car is moved across 4. Hold the button on the underside of the several magnetic zones. rearview mirror depressed approx. 3 seconds. The number of the cur- 1. Stop the car in a large open area free from rent magnetic zone is shown.
Page 100: Power Panorama Roof
03 Your driving environment Power panorama roof* General Closing, manual WARNING The panorama roof is divided into two sections. Closing, automatic Children, other passengers or objects can Only the front section can be opened - hori- be trapped by the panorama roof's moving The panorama roof and curtain can be oper- zontally or vertically at the rear edge (ventilation parts.
Page 101 03 Your driving environment Power panorama roof* Manual operation Ventilation position Closing using the remote control key or 1. To open the curtain - press the control central locking button rearward to the point of resistance for man- ual opening. The curtain moves towards maximum opening as long as the button is depressed.
Page 102 03 Your driving environment Power panorama roof* Wind deflector The panorama roof has a wind deflector that is folded up when the panorama roof is in the open position. Option/accessory, for more information, see Introduction.
Page 103: Alcoguard
03 Your driving environment Alcoguard* General information on the Alcolock 1. Nozzle for breath test. NOTE The function of the Alcolock is to prevent the 2. Switch. Store the Alcolock in its holder. This will car from being driven by individuals under the 3.
Page 104 - only starting with the Bypass func- until indicator lamp (6) is green. An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 105 Bypass or Emergency function is selected as blow for longer. longer the bypassing option. This setting can be Alcoguard Blow Blowing too hard - changed afterwards at a workshop blow more gently. softer An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 106 03 Your driving environment Alcoguard* Display text Meaning/Action Alcoguard Blow Blowing too weak - blow harder. harder Alcoguard wait Heating not finished Alco- Preheating - wait for text guard Blow 5 sec- onds Option/accessory, for more information, see Introduction.
Page 107: Starting The Engine
03 Your driving environment Starting the engine Petrol and diesel engines 2. Hold the clutch pedal fully depressed Keyless drive . (For cars with automatic gearbox - Depress the Follow steps 2–3 for starting petrol and diesel brake pedal.) engines. For more information on Keyless drive, see page 53.
Page 108 03 Your driving environment Starting the engine remote control key has been pressed into the ignition switch. The steering lock is activated when the driver's door is opened after the engine has been switched off. Key positions For information on the remote control key's dif- ferent key positions, see page 74...
Page 109: Starting The Engine - External Battery
03 Your driving environment Starting the engine – external battery Jump starting 5. Open the clips on the front cover of the 11. Remove the jump leads, first the black and battery in your car and remove the cover, then the red. see page 306.
Page 110: Gearboxes
03 Your driving environment Gearboxes Manual gearbox depressed to disengage the gear selector from NOTE the P position. With the upper variant of the shifting pattern The gearbox is mechanically blocked when the for 6-speed gearbox (see previous illustra- tion) - first press down the gear lever in the P position is engaged.
Page 111 03 Your driving environment Gearboxes Manual gearshift mode is obtained by moving play shifts the indication from to the fig- NOTE the lever to the side from position D to the end f the gearbox has a Sport programme then position at +/–.
Page 112 03 Your driving environment Gearboxes Geartronic does not permit downshifting/kick- With the inhibitor button depressed the lever Deactivating the automatic gear selector down which would result in an engine speed can be moved forwards or backwards between inhibitor high enough to damage the engine. Nothing P, R, N and D.
Page 113 03 Your driving environment Gearboxes the Geartronic automatic transmission, descri- during slow driving in queues (10 km/h or Automatic gearbox, Powershift* bed in the previous section. slower) on an uphill gradient, or with a trailer hitched. The transmission cools down when the car is stationary, with foot brake depressed The HSA (Hill Start Assist) function means that and the engine running at idling speed.
Page 114 03 Your driving environment Gearboxes Symbol Display Driving characteristics Action Transm. overheat brake to hold Difficulty in maintaining even speed at con- Transmission overheated. Keep the car stant engine speed. stationary using the foot brake. Transm. overheat park safely Significant pulling in the car's traction. Transmission overheated.
Page 115: All-Wheel Drive - Awd
03 Your driving environment All-wheel drive – AWD* All Wheel Drive is always available All Wheel Drive means that the car is driving all four wheels at the same time. The power is automatically distributed between the front and rear wheels. An elec- tronically controlled clutch system distributes the power to the wheels that have the best grip on the current road surface.
Page 116: Foot Brake
03 Your driving environment Foot brake General may be felt in the brake pedal when this is Cleaning the brake discs engaged and this is normal. Coatings of dirt and water on the brake discs The car is equipped with two brake circuits. If may result in delayed brake function.
Page 117 If the level in the brake fluid reservoir is nor- mal at this stage, drive carefully to the near- est workshop and have the brake system checked - an authorised Volvo workshop is recommended. If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid.
Page 118: Hill Descent Control (Hdc)
03 Your driving environment Hill Descent Control (HDC) General gear position 1 must be selected, which is WARNING shown with the figure in the trip computer HDC can be compared to an automatic engine HDC does not work in all situations, but is display, see page 110.
Page 119 03 Your driving environment Hill Descent Control (HDC) • with the on/off button on the centre con- sole • if a gear higher than 1 is selected on a manual gearbox • if a gear higher than 1 is selected on an automatic gearbox, or if the gear selector is moved to position D.
Page 120: Parking Brake
03 Your driving environment Parking brake Parking brake, electric Applying the parking brake the accelerator pedal is depressed the braking is interrupted. Function A faint electric motor noise can be heard when NOTE the parking brake is being applied. The noise In the event of emergency braking at speeds can also be heard during the automatic func- above 10 km/h a signal sounds during the...
Page 121 D or R. The parking brake can also be released manually by depressing the clutch pedal instead of the brake pedal. Volvo recom- Heavy load uphill mends the use of the brake pedal. A heavy load, such as a trailer, can cause the car to roll backward when the parking brake is released automatically on a steep incline.
Page 122 Park brake not fully released - A fault is pre- venting the parking brake from being released. Visit a workshop - an authorised Volvo work- shop is recommended. A warning signal sounds if you pull away with this error mes- sage.
Page 123: Homelink
03 Your driving environment HomeLink * General NOTE WARNING HomeLink is designed not to work if the car If HomeLink is used to operate a garage is locked from the outside. door or gate, ensure that nobody is in the vicinity of the door or gate while it is in Save the original remote controls for future motion.
Page 124 03 Your driving environment HomeLink * The particular distance that is required ess is repeated for approx. 20 seconds Programming individual buttons and indicates that the device has a "roll- between the original remote control and To reprogram an individual button, proceed in ing code".
Page 125 03 Your driving environment HomeLink * • Constant glow: The indicator lamp illu- 7. Depress the programmed button on minates with a constant glow when the HomeLink , while the "programming but- button is kept depressed, this indicates ton" is still flashing, keep it depressed for that the programming is complete.
Page 126 Menus and messages................128 Menu source MY CAR................130 Climate control..................136 Fuel-driven engine block heater and passenger compartment heater*........... 146 Additional heater*.................. 149 Trip computer..................150 DSTC – Stability and traction control system........152 Adapting driving characteristics............154 Cruise control*..................155 Adaptive cruise control*................
Page 127 C O M F O R T A N D D R I V I N G P L E A S U R E...
Page 128: 04 Comfort And Driving Pleasure
04 Comfort and driving pleasure Menus and messages Combined instrument panel Menu overview Message Some of the following menu options require the function and hardware to be installed in the car. To empty fuel tank Average Instantaneous Average speed Current speed Engine oil level* Tyre pressure Calibration* Information display and controls for menus.
Page 129 Drive carefully until the workshop Part of message, shown together with information on where message clears the problem has arisen. An authorised Volvo workshop is recommended. If shown repeatedly - For more messages concerning automatic transmission, see page 113. contact a workshop...
Page 130: Menu Source My Car
04 Comfort and driving pleasure Menu source MY CAR General information about MY CAR Operation to the menu system's main menu - Parent view, from where all the car's functions/ Many of the car's features are handled Centre console controls menu sources can be accessed, see in this menu source, such as setting the page 206.
Page 131 Automatic door locking 4. Scroll to Lock settings and press the Doors unlock thumbwheel - a new submenu opens. • My XC60 All doors • 5. Scroll to Doors unlock and press the Support systems (Support systems) thumbwheel - a submenu of selectable •...
Page 132 04 Comfort and driving pleasure Menu source MY CAR Reduced Guard 60 sec Reset car settings Activate once 90 sec This option resets the menu system to the orig- inal factory settings in Car settings. Ask when exiting For more information, see page 87. For more information, see page 59 and 63.
Page 133 Settings Voice settings rent content is shown if this option is selected. For more information, see page 166. Only in combination with Volvo's navigation system RTI Distance and fuel units Driver alert (Road and Traffic Information) and/or Bluetooth -enabled mobile phone MPG (UK) For more information, see page 180.
Page 134 Automatic rear defroster 2. Test-listen using OK ble voice commands - only with Volvo's navi- gation system RTI* installed. 3. Store the settings menu and back out from Interior air quality system the menu with EXIT.
Page 135 04 Comfort and driving pleasure Menu source MY CAR VIN number For more information, see page 324. DivX® VOD code For more information, see page 221. Bluetooth software version in car For more information, see page 227. Map and software version See also separate manual on RTI and GPS navigation.
Page 136: Climate Control
Volvo recommends that you con- The system includes a sun sensor which Misting windows tact an authorised Volvo workshop.
Page 137 04 Comfort and driving pleasure Climate control the work. Volvo recommends that you contact the remote control key. The fan fills the and easy to remove and clean. Use cleaning passenger compartment with fresh air. The an authorised Volvo workshop.
Page 138 04 Comfort and driving pleasure Climate control Air distribution Air vents in the dashboard Air vents in the door pillars Open Closed The incoming air is divided between 20 different vents in the passenger compart- Closed Open ment. Lateral airflow Lateral airflow Air distribution is fully automatic in AUTO mode*.
Page 139 04 Comfort and driving pleasure Climate control Electronic climate control, ECC* Temperature control, left-hand side Temperature control, right-hand side Heated front seats, left-hand side Recirculation Max. defroster AUTO AC – – Air conditioning on/off Air distribution - ventilation floor Air distribution - air vent instrument panel Air distribution - defroster windscreen Rear window and door mirror defrosters, see page 97...
Page 140 04 Comfort and driving pleasure Climate control Electronic Temperature Control, ETC Heated front seats, right-hand side Heated front seats, left-hand side Temperature control AC – – Air conditioning on/off Max. defroster Air distribution - ventilation floor Air distribution - air vent instrument panel Air distribution - defroster windscreen Rear window and door mirror defrosters, see page 97...
Page 141 04 Comfort and driving pleasure Climate control Operating the controls Press the button three times for the lowest heat Press the button once for the highest heat level level – one orange lamp illuminates in the TV – three lamps illuminate. Heated seats* screen.
Page 142 04 Comfort and driving pleasure Climate control Fan knob for ETC figure shows the air distribution that is when AUTO is pressed. The TV screen shows selected. For more information on air distribu- AUTO CLIMATE Turn the knob to increase or tion, see page 144.
Page 143 04 Comfort and driving pleasure Climate control The following also takes place in order to pro- NOTE IMPORTANT vide maximum dehumidification in the passen- Heating or cooling cannot be hastened by If the air in the car recirculates for too long, ger compartment: selecting a higher/lower temperature than there is a risk of misting on the insides of the...
Page 144 04 Comfort and driving pleasure Climate control settings Interior air quality system. For a NOTE description of the menu system, see The air quality sensor should always be page 130. engaged in order to obtain the best air in the passenger compartment.
Page 145 04 Comfort and driving pleasure Climate control Air distribution Air distribution Airflow to windows and to ensure good comfort in Air to floor. Some air to direct heat or cold to from dashboard air vents. warm, dry weather. flows to the dashboard the floor air vents and windows.
Page 146: Fuel-Driven Engine Block Heater And Passenger Compartment Heater
04 Comfort and driving pleasure Fuel-driven engine block heater and passenger compartment heater* Fuel-driven heater Refuelling Battery and fuel If the battery has insufficient charge or the fuel General information about the parking level is too low, the parking heater will be heater switched off automatically and a message The parking heater heats the engine and pas-...
Page 147 Symbols and display messages workshop for Service leaving the car - When one of the timer's settings or repair. Volvo rec- required the engine and Direct start is activated, the infor- ommends that you passenger com-...
Page 148 04 Comfort and driving pleasure Fuel-driven engine block heater and passenger compartment heater* A display text clears automatically after a time Setting the timer Set the alternative time in the same way as or after one press on the indicator stalk Park heat timer 1 The time when the car shall be used and heated READ button.
Page 149: Additional Heater
I - any adjustments must therefore short distances if required. be made before starting the engine. An authorised Volvo dealer has information regarding the geographical areas concerned. An authorised Volvo dealer has information regarding the engines concerned. Option/accessory, for more information, see Introduction.
Page 150: Trip Computer
04 Comfort and driving pleasure Trip computer General Functions NOTE There may be a slight error in the reading if NOTE a fuel-driven supplementary and/or parking heater* has been used. If a warning message appears when the trip computer is used then the message must first be acknowledged before the trip com- Km to empty tank puter can be reactivated.
Page 151 04 Comfort and driving pleasure Trip computer 2. Press and hold RESET for approx. 1 second to reset the selected function. If RESET is kept depressed for at least 3 three seconds then Average speed and Average are reset simultaneously. Current speed* The instrument panel display shows current speed in mph if the speedometer is graduated...
Page 152: Dstc - Stability And Traction Control System
04 Comfort and driving pleasure DSTC – Stability and traction control system General information on DSTC Involuntary wheel locking while driving can, With Sport mode, maximum traction is amongst other things, impair the driver's ability obtained if the car has become stuck, or when The stability and traction control system, DSTC to steer the car.
Page 153 04 Comfort and driving pleasure DSTC – Stability and traction control system > If the message remains when the engine is restarted, drive to a workshop. An authorised Volvo workshop is recom- mended. Symbols in the combined instrument panel If the symbols...
Page 154: Adapting Driving Characteristics
04 Comfort and driving pleasure Adapting driving characteristics Active chassis (Four-C)* Operation Steering wheel force and select Medium High Active chassis, Four-C (Continously Controlled Chassis Concept), regulates the characteris- For a description of the menu system, see tics of the shock absorbers so that the car's page 130.
Page 155: Cruise Control
04 Comfort and driving pleasure Cruise control* Operation Temporary deactivation - standby mode The cruise control is then activated with Press to temporarily disengage the cruise , after which the current speed is stored in control and set it in standby mode - set speed the memory - the display text (---) km/h is shown in brackets in the display (5), e.g.
Page 156 04 Comfort and driving pleasure Cruise control* Deactivate The cruise control is switched off with the steering wheel button CRUISE or by switching off the engine - the set speed is deleted from the memory and cannot be resumed with the button.
Page 157: Adaptive Cruise Control
Adaptive cruise control consists of a cruise Maintenance of adaptive cruise control control system and a coordinated spacing sys- components must only be performed at a workshop - an authorised Volvo workshop tem. is recommended. Automatic gearbox The adaptive cruise control has enhanced functionality (Queue Assist) on cars with auto- matic gearbox, see page 161.
Page 158 04 Comfort and driving pleasure Adaptive cruise control* The adaptive cruise control aims to follow the If the car needs to be braked more heavily than WARNING vehicle ahead in the same lane at a time interval cruise control capacity and the driver does not Adaptive cruise control is not a collision set by the driver.
Page 159 04 Comfort and driving pleasure Adaptive cruise control* Operation (---) mean that cruise control is set in standby NOTE mode. If any cruise control button is held The cruise control is then activated with depressed for more than approx. 1 minute then cruise control is disengaged.
Page 160 04 Comfort and driving pleasure Adaptive cruise control* Note that a short time interval only allows the standby mode - set speed is shown in brackets In the event of automatic deactivation a signal driver a short time to react and take action if (100) Cruise control in the display, e.g.
Page 161 04 Comfort and driving pleasure Adaptive cruise control* with one long press in active mode. The set Change of target NOTE speed is cleared and cannot be resumed with Activation of the cruise control below button. 30 km/h requires a vehicle in front within a reasonable distance.
Page 162 04 Comfort and driving pleasure Adaptive cruise control* Automatic standby mode with change of Automatic activation parking brake WARNING target In some situations the cruise control applies The driver must always be observant with the parking brake in order to keep a stationary Cruise control is disengaged and set in regard to the traffic conditions and intervene car remaining stationary.
Page 163 04 Comfort and driving pleasure Adaptive cruise control* • if the speed of vehicles in front is signifi- Sometimes the radar sensor is late at WARNING cantly different from your own speed. detecting vehicles at close distances, e.g. Adaptive cruise control is not a collision a vehicle that drives in between the car and avoidance system.
Page 164 04 Comfort and driving pleasure Adaptive cruise control* Cause Action The radar surface in the grille is dirty or covered with ice or snow. Clean the radar surface in the grille from dirt, ice and snow. Heavy rain or snow blocking the radar signals. No action.
Page 165 Cruise control Service Cruise control not working. required • Contact a workshop - an authorised Volvo workshop is recommended. Press Brake To hold (Only cars with automatic gearbox - "Queue Assist") acoustic alarm The car is stationary and the cruise control will release the foot brake to allow the parking brake to take over and hold the car, but a fault in the parking brake means the car will shortly begin to roll.
Page 166: Distance Alert
04 Comfort and driving pleasure Distance Alert* General console - in which case the function is handled NOTE by the car's menu system MY CAR under Distance Alert is a function that informs the Distance Alert is deactivated during the time SETUP Car settings Distance Alert...
Page 167 04 Comfort and driving pleasure Distance Alert* Different time intervals to the ing system. For more information on the radar NOTE vehicle in front can be sensor and its limitations, see page 162. The higher the speed, the longer the calcu- selected and shown in the lated distance in metres for a specific time display as 1-5 horizontal lines...
Page 168 Read about the limitations of the radar sensor, see page 162. Collision warn. Service Distance Alert and Collision Warning with Auto Brake are fully or partially disengaged. required Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 169: City Safety
30 km/h and it helps the driver by automatically Safety™ components must only be per- braking the car in the event of imminent risk of formed by a workshop - an authorised Volvo collision with vehicles in front, should the driver workshop is recommended.
Page 170 04 Comfort and driving pleasure City Safety™ If the difference in speed between the vehicles Using MY CAR on the centre console display Low-hanging objects, e.g. a flag/pennant for is 15-30 km/h, City Safety™ may not prevent screen with its menu system, search and locate projecting load, or accessories such as auxili- the collision on its own.
Page 171 (see the illustration for sensor location, page when City Safety™ has stopped the car, unless gestions for appropriate action. 169) - an authorised Volvo workshop is rec- the driver manages to depress the clutch pedal ommended. beforehand.
Page 172 Remove the object blocking the sensor and/or clean the windscreen in front of the sensor. Read about the limitations of the laser sensor, see page 170. City Safety Service City Safety™ is not operational. required • Visit a workshop if the message remains - an authorised Volvo workshop is recommended.
Page 173: Collision Warning & Pedestrian Detection With Auto Brake
Collision Warning – Warns the driver of a components must only be performed at a potentially imminent collision. Warnings and brake interventions for workshop - an authorised Volvo workshop pedestrians are switched off at vehicle • Brake Support – Assists the driver to is recommended.
Page 174 04 Comfort and driving pleasure Collision Warning & Pedestrian Detection with Auto Brake* Function Brake support Operation If the risk of collision still increases after the Settings are made from MY CAR via the centre collision warning then the brake support is acti- console display screen and menu system.
Page 175 04 Comfort and driving pleasure Collision Warning & Pedestrian Detection with Auto Brake* Activating/deactivating warning signals Limitations NOTE The warning lamp is activated automatically The collision warning system is active from and When the adaptive cruise control is in use when the engine is started if the system is including approx.
Page 176 04 Comfort and driving pleasure Collision Warning & Pedestrian Detection with Auto Brake* why the system does not intervene in situations WARNING NOTE where the car is approaching a vehicle in front Warnings and brake interventions could be Keep the windscreen surface in front of the very slowly, e.g.
Page 177 04 Comfort and driving pleasure Collision Warning & Pedestrian Detection with Auto Brake* • Detection of pedestrians (Pedestrian In order for a pedestrian to be detected he/ pedestrians, vehicles or road markings in front she must appear full-length and have a of the car.
Page 178 - an authorised Volvo workshop is recom- mended. Symbols and messages in the display Symbol Message Specification Collision warning system switched off.
Page 179 Read about the limitations of the radar sensor, see page 162. Collision Collision Warning with Auto Brake is fully or partially disengaged. warn. • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Service required Option/accessory, for more information, see Introduction.
Page 180: Driver Alert System - Dac
04 Comfort and driving pleasure Driver Alert System – DAC* General information on Driver Alert General information on Driver Alert The objective for DAC is to detect slowly dete- riorating driving ability and it is primarily System Control - DAC intended for major roads.
Page 181 04 Comfort and driving pleasure Driver Alert System – DAC* Operation Thumbwheel. Turn until the display shows The display shows a level mark with 1-5 bars, Driver where a low number of bars indicates incon- Some settings are made from the centre con- sistent driving style.
Page 182 Read about the limitations of the camera sensor, see page 176. The system is disengaged. Driver Alert Sys Service required • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 183: Driver Alert System - Ldw
04 Comfort and driving pleasure Driver Alert System - LDW* General information on Lane Departure Operation and function If the camera can no longer detect the carria- geway's side markings the display shows Warning - LDW Lane Depart Warn Unavailable If speed decreases to below 60 km/h then the function resumes standby mode and the dis- play shows...
Page 184 04 Comfort and driving pleasure Driver Alert System - LDW* NOTE The driver is only warned once each time the wheels cross a line. So there is no acoustic alarm when there is a line between the car's wheels. Symbols and messages in the display Symbol Message Specification...
Page 185 Read about the limitations of the camera sensor, see page 176. Driver Alert Sys Service The system is disengaged. required • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Personal preferences Increased sensitivity – This option increases sensitivity, an alarm is triggered earlier and Settings are made from the centre console's fewer limitations apply.
Page 186: Park Assist Syst
04 Comfort and driving pleasure Park assist syst* General Function Parking assistance is used as an aid to parking. An acoustic signal as well as symbols on the centre console's display screen indicate the distance to the detected obstacle. Parking assistance sound level can be adjusted during the ongoing acoustic signal using the centre console's VOL knob or in the car's menu system MY CAR - see page 130.
Page 187 NOTE sounds alternately from the loudspeakers. Rear parking assistance is deactivated Front parking assistance is deactivated automatically when towing a trailer if Volvo when the parking brake is applied or P mode Rear parking assistance genuine trailer wiring is used.
Page 188 04 Comfort and driving pleasure Park assist syst* Cleaning the sensors NOTE Dirt, ice and snow covering the sensors may cause incorrect warning signals. Sensor location, front. Sensor location, rear. The sensors must be cleaned regularly to ensure that they work properly. Clean them with water and car shampoo.
Page 189: Park Assist Camera
04 Comfort and driving pleasure Park assist camera* General When reverse gear is engaged two unbroken lines are shown graphically which illustrate The parking camera is an assist system and is where the car's rear wheels will roll with the activated when reverse gear is engaged (can current steering wheel angle, this facilitates be changed in the settings menu, see...
Page 190 • The parking camera is deactivated Park assist lines automatically when towing a trailer if a The system's lines. Volvo genuine trailer cable is used. Boundary line, 30 cm zone backwards from the car IMPORTANT Boundary line, free reversing zone Bear in mind that the screen only shows the "Wheel tracks"...
Page 191 04 Comfort and driving pleasure Park assist camera* Cars with reversing sensors* Limitations Colour / paint Distance (metres) NOTE Yellow 1.5– A bike carrier or other accessory mounted on the rear of the car could obscure the Orange 0.3–1.5 camera's view. 0–0.3 Pay attention to the possibility that, even if it Settings...
Page 192: Blis* - Blind Spot Information System
04 Comfort and driving pleasure BLIS* – Blind Spot Information System General information on BLIS Blind spots WARNING The system is a supplement to, not a replacement for, a safe driving style and use of the rearview mirrors. It can never replace the driver's attention and responsibility.
Page 193 04 Comfort and driving pleasure BLIS* – Blind Spot Information System BLIS is activated when the engine is started. When BLIS operates cles. This means for example that the system The indicator lamps in the door panels flash does not react to a trailer without headlamps The system operates when the car is driven at three times when BLIS is activated.
Page 194 OFF deactivated. IMPORTANT Repair of the BLIS system components must only be performed by a workshop - an authorised Volvo workshop is recom- mended. Reflection from shiny wet road surface. Option/accessory, for more information, see Introduction.
Page 195 04 Comfort and driving pleasure BLIS* – Blind Spot Information System Own shadow on large light smooth surface, e.g. noise barrier or concrete road surface. Low stationary sunlight shining into the camera. Option/accessory, for more information, see Introduction.
Page 196: Comfort Inside The Passenger Compartment
04 Comfort and driving pleasure Comfort inside the passenger compartment Storage spaces...
Page 197 Otherwise they may injure peo- Inlaid mats* objects in the cup holder as such objects could ple in the car in the event of sudden braking Volvo supplies specially manufactured inlay or a collision. accidentally trigger the alarm*, see page 62. mats.
Page 198 04 Comfort and driving pleasure Comfort inside the passenger compartment 12 V socket socket to supply current, the remote control WARNING key must be in at least key position I, see Before setting off check that the inlaid mat page 74. in the driver area is firmly affixed and secured in the pins in order to avoid getting IMPORTANT...
Page 199 04 Comfort and driving pleasure Comfort inside the passenger compartment Electrical socket in cargo area* For more information, see page 260. Option/accessory, for more information, see Introduction.
Page 200 General information on infotainment............. 202 Quick start..................... 204 General infotainment functions............. 208 Radio..................... 211 Media player..................218 External audio source via AUX/USB* input........... 222 Media Bluetooth * ................225 TV*......................228 Remote control* ................... 231 Bluetooth handsfree*................233 Voice recognition* mobile phone............241 Menu navigation, Infotainment..............
Page 201 I N F O T A I N M E N T S Y S T E M...
Page 202: 05 Infotainment System
05 Infotainment system General information on infotainment • General AM/FM radio Made under license from Dolby Laboratories. Dolby, Pro Logic and the double-D symbol are • The infotainment system in your car has one of CD/DVD trademarks of Dolby Laboratories. the following four levels: •...
Page 203 05 Infotainment system General information on infotainment key being in the ignition switch by pressing the On/Off button. When the car is being started the infotainment system is switched off temporarily and contin- ues when the engine has started. NOTE Remove the remote control key from the ignition switch if the infotainment system is used when the engine is switched off.
Page 204: Quick Start
05 Infotainment system Quick start Overview, Infotainment Operating the system Source buttons Control panel with buttons for source selection. Short press starts the system and long AUX and USB inputs for external audio RADIO - Select, for example, AM, FM1, press switches off.
Page 205 05 Infotainment system Quick start Basic functions, Infotainment OK/MENU - accepts selections in menus. The views have different appearances depend- Lead to submenus in selected source (e.g. ing on the source, in-car equipment, settings, etc. RADIO or MEDIA). EXIT - leads up in the menu system, inter- rupts the current function, rejects calls and deletes input characters.
Page 206 Parent view thumbwheel to confirm the selection. This then leads to the desired source (e.g. RADIO A long press on EXIT leads back. NAV - Volvo's navigation system (RTI)* RADIO – Radio MEDIA – Media Short presses scroll between disc tracks Example of parent view (Radio).
Page 207 05 Infotainment system Quick start Steering wheel keypad with thumbwheel tion (OK) in the menu system, and accepts press leads to the highest menu level phone calls. (parent view), see page 206. MUTE - switches off the sound Thumbwheel - turn up/down to scroll up and down in the menu system.
Page 208: General Infotainment Functions
05 Infotainment system General infotainment functions • FAV - store a preset Bluetooth* INFO - shows additional information • • It is also possible to select and store a favourite for TEL*, MY CAR, CAM* and NAV*. Favour- ites can also be selected and stored under MY CAR.
Page 209 05 Infotainment system General infotainment functions • Surround - Can be set to the On/Off posi- Advanced audio settings For general information on menu navigation tion. When On is selected, the system and menu structures, see page 245. Equalizer selects the setting for optimal sound repro- Audio volume and automatic volume The volume level can be adjusted separately duction.
Page 210 05 Infotainment system General infotainment functions 2. Press OK/MENU and then turn TUNE to able to adapt the sound reproduction accord- AUX input volume ing to personal taste. . Confirm with OK/ MENU. 3. Turn TUNE to adjust the volume for the AUX input.
Page 211: Radio
05 Infotainment system Radio Radio functions, general Station list NOTE The radio automatically compiles a list of the If the car is equipped with a steering wheel strongest FM stations whose signals it is cur- keypad* and/or remote control* then in rently receiving.
Page 212 05 Infotainment system Radio in the area when you turn TUNE (see the sec- NOTE NOTE tion "Station list", page 211). When the station • The preset from the factory is that the radio The list only shows the frequencies of list is shown, press the button in the cen- automatically searches for the stations in...
Page 213 05 Infotainment system Radio • time and returns when the station is stored. Automatically switches to a stronger trans- rupted audio source, press the OK/MENU to mitter if reception in the area is poor. The preset button can now be used. clear the message.
Page 214 05 Infotainment system Radio ± ± Activate/deactivate in FM mode by select- Resetting and removing PTY are performed Go in FM mode to FM menu News ing one of the options under FM menu under FM menu Advanced settings settings Set news favourite to change.
Page 215 05 Infotainment system Radio ± Radio text The reset is carried out in FM mode under Service and Ensemble • Service Some RDS stations transmit information on FM menu Advanced settings - Channel, radio channel (only audio services are supported by the sys- programme content, artists, etc.
Page 216 05 Infotainment system Radio Navigation in channel group list Scanning can also be selected in DAB-PTY A preset contains one channel but no sub- mode. In which case only channels of the pre- channels. If a subchannel is being played and (Ensemble) selected programme type are played.
Page 217 05 Infotainment system Radio quickly than if both Band III LBand have gory. This information is shown on the TV NOTE screen. been selected. It is not certain that all channel Show radio Only one of the functions " groups will be found. Wavelength selection The function is activated/deactivated in DAB text Show presets...
Page 218: Media Player
05 Infotainment system Media player The media player supports and can play the Starting playback of a disc CD/DVD functions following main types of discs and files: Repeatedly press on the MEDIA button until Disc is shown, release and wait a second or •...
Page 219 05 Infotainment system Media player the selection of the disc track and start play- setting when a disc containing only audio files Fast forward/reverse back. Press EXIT to cancel and exit the playlist. or only video files is loaded into the media Hold in the buttons to fast forward/ player and then plays back these files.
Page 220 05 Infotainment system Media player 2. Turn TUNE to Scan 3. Press OK/MENU to activate/deactivate Navigation in the DVD video disc's menu the function. > The first 10 seconds of each disc track or audio file are played. Playback of DVD video discs 3.
Page 221 05 Infotainment system Media player Press OK/MENU to activate the selection and Picture settings CD audio, mp3, Audio format return to the start position. Use EXIT to cancel You can adjust the settings (when the car is the selection and this leads back to the original stationary) for brightness and contrast.
Page 222: External Audio Source Via Aux/Usb* Input
05 Infotainment system External audio source via AUX/USB* input media's file structure. Depending on the file AUX, USB and external audio source NOTE structure and number of files there may be If the car is equipped with a steering wheel General some delay before loading is finished.
Page 223 05 Infotainment system External audio source via AUX/USB* input or start of playback of the selected audio/video Scan NOTE file. Press EXIT to either stop and exit the play- See page 219. When using a longer model USB memory list or go up (back) in the folder structure. stick the use of the enclosed USB adapter Random Audio/video files can also be changed by...
Page 224 05 Infotainment system External audio source via AUX/USB* input NOTE The system only supports the playback of audio files from iPod . NOTE When an iPod is used as audio source, the car's infotainment system has a menu structure that is similar to the iPod player's own menu structure.
Page 225: Media Bluetooth
Volvo recommends that from the device. you contact an authorised Volvo dealer or visit www.volvocars.com for information on To play back the audio the car's media player compatible phones and external media Centre console control panel.
Page 226 05 Infotainment system Media Bluetooth * 4. Check that the external device is searcha- nect a new external device, see "Change to NOTE another external device" below. ble/visible via Bluetooth , see the manual If the car is equipped with a steering wheel for the external device.
Page 227 05 Infotainment system Media Bluetooth * Remove the connected device tion in Bluetooth mode under Bluetooth menu 1. Press Bluetooth mode on OK/MENU. Scan. 2. Turn TUNE to Remove Bluetooth Cancel scanning with EXIT. device and confirm with OK/MENU. Version information Bluetooth 3.
Page 228 05 Infotainment system IMPORTANT NOTE A TV licence is required for this product in If the car is equipped with a steering wheel General some countries. keypad* and/or remote control* then in many cases these can be used instead of NOTE the buttons in the centre console.
Page 229 05 Infotainment system • Turn TUNE, a list of all available channels Searching TV channels/Preset list NOTE in the area is shown. If any of these chan- 1. Press TV mode on OK/MENU. If the country of residence has changed, a nels is already saved as a preset then its 2.
Page 230 05 Infotainment system Save the available TV channels as EXIT, then the channel that you just watched can sometimes be displayed, such as start and continues to be shown. Scanning does not end times and a brief description of the current presets programme.
Page 231: Remote Control
05 Infotainment system Remote control* Remote control* The remote control can be used for all func- Function tions in the infotainment system. The remote control's buttons have the same functions as F = Front TV screen the buttons in the centre console or steering wheel keypad*.
Page 232 05 Infotainment system Remote control* Replacing the battery in the remote 3. Refit the cover. Function control NOTE Navigate right/left, change track/ song. NOTE Be sure to dispose of the exhausted batter- ies in an environmentally safe manner. Confirm selection or go to the Battery life is normally 1-4 years and depends on how much the remote control menu system for the selected...
Page 233: Bluetooth Handsfree
NOTE Only a selection of mobile phones are fully compatible with the handsfree function. Volvo recommends that you seek assis- tance from an authorised Volvo dealer or visit www.volvocars.com for information on compatible phones. Menus The menus in TEL are controlled from the cen- System overview.
Page 234 05 Infotainment system Bluetooth handsfree* 2. Activate the vehicle's handsfree function Alternative 2 - via the mobile phone's menu NOTE by pressing TEL. Continue by pressing system If the car is equipped with a steering wheel OK/MENU. 1. Activate the handsfree function by press- keypad* and/or remote control* then in many cases these can be used instead of 3.
Page 235 05 Infotainment system Bluetooth handsfree* screen. Now the mobile phone can be con- When the mobile phone has been discon- In call menu trolled from the audio system. nected an ongoing call can be continued by Press OK/MENU during an ongoing call to using the mobile phone's built-in microphone access the following functions: To call...
Page 236 05 Infotainment system Bluetooth handsfree* vate/deactivate in phone mode under Phone More on pairing and connecting NOTE main menu Phone settings Sounds A maximum of ten mobile phones can be Certain mobile phones show a list of the last paired (registered). Pairing is performed once and volume Mute radio/media.
Page 237 05 Infotainment system Bluetooth handsfree* Quick search for contacts Version information Bluetooth NOTE In normal view turn TUNE to the right to obtain The car's current Bluetooth version can be Changes made from the car to a record in a list of contacts. Turn TUNE to select and seen in phone mode under Phone main menu the mobile phone's telephone book will...
Page 238 05 Infotainment system Bluetooth handsfree* Character table keypad in centre NOTE Function console There is no text wheel for High Performance, + 0 p w Function so TUNE cannot be used there to input characters: only the digit and letter buttons Space .
Page 239 05 Infotainment system Bluetooth handsfree* New contact 1. When the Name row is selected, press 123/ Change between letters and OK/MENU to reach the input mode (illus- numbers with OK/MENU. tration above). More Change to special characters 2. Turn TUNE to the desired letter, press with OK/MENU.
Page 240 05 Infotainment system Bluetooth handsfree* speed dial number then an option is shown to 123/ Change between letters and save a contact to the selected speed dial num- numbers with OK/MENU. ber. More Change to special characters Receiving a vCard with OK/MENU.
Page 241: Voice Recognition* Mobile Phone
The sys- tem will then display commonly used com- Only applies to vehicles equipped with Volvo's navigation system - RTI (Road and Traffic Information System). Option/accessory, for more information, see Introduction.
Page 242 05 Infotainment system Voice recognition* mobile phone mands in the TV screen in the centre con- Help functions for voice recognition To skip a lesson and go to the next one, press sole. • the button for voice recognition and say Instructions: A function that helps you get "Next".
Page 243 05 Infotainment system Voice recognition* mobile phone Using voice commands commands . For a description of the menu the last spoken group of numbers) or "Delete" (which deletes the whole spoken system, see page 130. The driver initiates a dialogue with the voice phone number).
Page 244 05 Infotainment system Voice recognition* mobile phone play in the numbered rows and the system prompts you to select a row number. • If there are more rows in the list than can be displayed simultaneously, saying "Down" allows you to scroll down in the list (and saying "Up"...
Page 245: Menu Navigation, Infotainment
05 Infotainment system Menu navigation, Infotainment To navigate in the menus Controls in the centre console Audio settings Equalizer, which requires that the following is carried out beforehand: The infotainment system's functions are con- trolled via the system's menus. Each source in 1.
Page 246 05 Infotainment system Menu navigation, Infotainment Reset all FM settings Menus MEDIA Audio settings Audio settings Sound stage Main menu CD Audio Disc menu Equalizer Main menu DAB1*/DAB2* Random Volume compensation DAB menu Scan Reset all audio settings Ensemble learn Audio settings PTY filtering Main menu FM1/FM2...
Page 247 05 Infotainment system Menu navigation, Infotainment Main menu DVD Video Main menu USB Audio settings Disc menu USB menu Main menu AUX DVD disc menu Play/Pause AUX menu Play/Pause/Continue Stop AUX input volume Stop Random Audio settings Subtitles Repeat folder Audio tracks Select USB device Main menu TV*...
Page 248 05 Infotainment system Menu navigation, Infotainment Change phone Source menu Remove Bluetooth device DVD root menu Phone settings DVD title menu Discoverable Sounds and volume Menus TEL Download phone book Main menu Bluetooth handsfree Bluetooth software version in Phone main menu Call list Call options All calls...
Page 249 05 Infotainment system...
Page 250 Recommendations during driving............252 Refuelling....................255 Fuel....................... 256 Loading....................259 Cargo area.................... 261 Driving with a trailer................264 Towing and recovery................270...
Page 251 D U R I N G Y O U R J O U R N E Y...
Page 252: 06 During Your Journey
- tow the car from the water consumption. Driving in water to a workshop - an authorised Volvo work- • Avoid driving with open windows. The car can be driven through water at a maxi- shop is recommended.
Page 253 06 During your journey Recommendations during driving • If the text message High engine temp Open tailgate least 15 minutes - battery charging is more Stop engine Coolant level low, Stop effective during driving than running the engine is shown then the engine must be engine at idling speed while stationary.
Page 254 • Use washer fluid to avoid ice forming in the washer fluid reservoir. To achieve optimum roadholding Volvo rec- ommends using winter tyres on all four wheels if there is a risk of snow or ice. NOTE The use of winter tyres is a legal requirement in certain countries.
Page 255: Refuelling
06 During your journey Refuelling Refuelling Opening the fuel filler flap manually Opening/closing the fuel cap Opening/closing the fuel filler flap The fuel filler flap can be opened manually A certain overpressure may arise in the tank in when electric opening from the passenger the event of high outside temperatures.
Page 256: Fuel
Fuel of a lower quality than that recommended Mixing different types of fuel or the use of intended to reduce emissions and improve fuel by Volvo must not be used as engine power fuel not recommended invalidates Volvo's economy. and fuel consumption is negatively affected.
Page 257 The fuel filter must be drained at the intervals fuel designed for low temperatures around damage that is not covered by the Volvo specified in the Service and Warranty Booklet freezing point is available from the major oil warranty.
Page 258 06 During your journey Fuel Diesel particle filter (DPF) way. The car should then be driven for approx- Consumption is higher and power output lower imately 20 minutes more. for fuel with an octane rating of 91 RON. Diesel cars are equipped with a particle filter, which results in more efficient emission con- NOTE trol.
Page 259: Loading
57. mised or eliminated by high loads. designed by Volvo are recommended. • Never load cargo above the backrest. WARNING Carefully follow the installation instructions supplied with the carriers.
Page 260 06 During your journey Loading Lowering the rear seat backrest Bag holder* 12 V electrical socket* To simplify loading in the cargo area, the rear seat backrest can be folded down, see page 78. Load retaining eyelets Bag holder under folding hatch in the floor. Lower the cover to access the electrical 1.
Page 261: Cargo Area
06 During your journey Cargo area Safety net Take care to press forward the rod's retain- WARNING ing hooks for each respective roof moun- Loads in the cargo area must be firmly ting's front end position. secured, even if the safety net is correctly fitted.
Page 262 06 During your journey Cargo area Break the rod in the centre, fold it together IMPORTANT and roll up the net. If the seat/backrest is pressed hard back- The folded safety net can be stored under the wards against the safety net then the net and/or its roof mountings could be dam- cargo compartment floor.
Page 263 06 During your journey Cargo area ± Fitting/removal Pull the cargo cover over the load and hook it Pull the sealing disc back gently, free from into the recesses at the cargo area's rear posts. its support shelves, and lower. The safety grille is normally permanently instal- led in the car because it can easily be folded up in the roof and so be out of the way if a...
Page 264: Driving With A Trailer
326. NOTE • Avoid driving with a trailer on inclines of If the towing bracket is mounted by Volvo, then more than 12%. The stated maximum permitted trailer the car is delivered with the necessary equip- weights are those permitted by Volvo.
Page 265 WARNING • In the event of a risk of overheating the 1. Depress the foot brake. If the car is fitted with a Volvo detachable optimal speed for the engine is 2300-3000 2. Activate the parking brake. towbar: rpm for optimal circulation of the coolant.
Page 266 06 During your journey Driving with a trailer Storing the detachable towbar Specifications Towbar storage space. Dimensions, mounting points (mm) 1013 IMPORTANT Always remove the towbar after use and store it in the appointed location in the car, firmly fastened with its strap. Side member Ball centre...
Page 267 06 During your journey Driving with a trailer Attaching the towbar The indicator window must show red. The indicator window must show green. Remove the protective cover by first press- ing in the catch and then pulling the cover straight back Insert the towbar until you hear a click.
Page 268 06 During your journey Driving with a trailer Check that the towbar is secure by pulling Safety cable. Push in the locking wheel and turn it it up, down and back. anticlockwise until you hear a click. WARNING WARNING Be sure to attach the trailer's safety cable to If the towbar is not fitted correctly then it the correct place.
Page 269 06 During your journey Driving with a trailer • Car with trailer subjected to a sudden and NOTE powerful side wind. If the driver selects to switch off (reduce) the • Car with trailer drives on an uneven road DSTC system, then the TSA system is also surface or in a pothole.
Page 270: Towing And Recovery
06 During your journey Towing and recovery Towing WARNING IMPORTANT Find out the highest legal speed for towing The brake servo and power steering do not Avoid towing. before towing the car. work when the engine is switched off. The •...
Page 271 06 During your journey Towing and recovery Towing eye Take out the towing eye that is located IMPORTANT under the floor hatch in the cargo area - in The towing eye is screwed into a threaded The towing eye is only designed for towing some cases it may be hidden under the sill.
Page 272 General ....................274 Changing wheels .................. 278 Tyre pressure ..................281 Warning triangle and first-aid kit*............282 Emergency puncture repair (TMK)* ............283 Option/accessory, for more information, see Introduction.
Page 273 W H E E L S A N D T Y R E S...
Page 274: 07 Wheels And Tyres
07 Wheels and tyres General Driving characteristics Tyres with the greatest tread depth should New tyres always be fitted to the rear of the car (to Tyres greatly affect the car's driving characte- decrease the risk of skidding). ristics. The type of tyre, dimensions, tyre pres- sure and speed rating are important for how the NOTE car performs.
Page 275 A suitable dis- able wheel bolts. tance for the first change is approx. 5000 km and then at 10 000 km intervals. Volvo recom- Tools mends that you contact an authorised Volvo workshop for checking if you are uncertain about tread depth.
Page 276 Only single-sided snow chains are permit- Note that there is an arrow on the upper foam ted. Use Volvo genuine snow chains or sim- NOTE block. It must point forwards in the car.
Page 277 07 Wheels and tyres General the load capacity required of the tyres. Mini- Rim diameter in 240 km/h mum permitted index is specified in the table, inches see page 336. 270 km/h Off-set in mm (dis- Speed ratings 300 km/h tance from wheel Each tyre can withstand a certain maximum centre to wheel con-...
Page 278: Changing Wheels
4. Place chocks in front of and behind the wheels which will remain on the ground. Volvo recommends only using the jack* that belongs to the car model in question, which 6. Loosen the wheel bolts ½-1 turn anticlock- Use heavy wooden blocks or large stones is indicated on the jack's label.
Page 279 07 Wheels and tyres Changing wheels jack down so it is pressed squarely on the 2. Put on the wheel. Tighten the wheel bolts ground. thoroughly. 3. Lower the car so that the wheels cannot rotate. Check that the jack sits in the anchorage as illustrated and that the foot is positioned vertically under the anchorage.
Page 280 07 Wheels and tyres Changing wheels WARNING IMPORTANT Never crawl under the car when it is raised Never drive faster than 80 km/h with a spare on the jack. wheel on the car. Passengers must leave the car when it is raised on the jack.
Page 281: Tyre Pressure
07 Wheels and tyres Tyre pressure Tyre pressure Fuel economy, ECO pressure At speeds under 160 km/h, the general tyre pressure is recommended (applies for both full load and light load) in order to obtain optimum fuel economy. Checking the tyre pressure The tyre pressures must be checked every month.
Page 282: Warning Triangle And First-Aid Kit
07 Wheels and tyres Warning triangle and first-aid kit* Warning triangle Lift the floor hatch and take out the warning triangle. Take the warning triangle from the case, fold out and assemble the two loose sides. Fold out the warning triangle's support legs.
Page 283: Emergency Puncture Repair (Tmk)
Bottle holder (orange cap) after the emergency tyre repair kit has been fluid bottle must be replaced before its expira- used. Volvo recommends that you visit an tion date and after use. Protective cap authorised Volvo workshop for inspection of...
Page 284 07 Wheels and tyres Emergency puncture repair (TMK)* Sealing punctured tyres WARNING WARNING The sealing fluid can irritate the skin. In the Do not leave children in the car without case of contact with skin, wash away the supervision when the engine is running. fluid with soap and water.
Page 285 Inhaling car exhaust fumes can result in • If it is below 1.3 bar then the tyre is Volvo recommends that you drive to the near- danger to life. Never leave the engine run- insufficiently sealed. The journey should ning in sealed areas or areas that lack suf- est authorised Volvo workshop for the replace- not be continued.
Page 286 07 Wheels and tyres Emergency puncture repair (TMK)* Replacing the sealing fluid canister WARNING Replace the bottle when the expiration date Do not leave children in the car without has passed. Treat the old bottle as environ- supervision when the engine is running. mentally hazardous waste.
Page 287 07 Wheels and tyres...
Page 288 Engine compartment................290 Lamps....................297 Wiper blades and washer fluid.............. 303 Battery....................305 Fuses..................... 308 Car care....................317...
Page 289 M A I N T E N A N C E A N D S E R V I C E...
Page 290: 08 Maintenance And Service
NOTE illustration. IMPORTANT Volvo recommends only using the jack that For the Volvo warranty to apply, check and belongs to the car model in question. If a Opening and closing the bonnet follow the instructions in the Service and jack is selected other than the one recom- Warranty Booklet.
Page 291 Check that the bonnet locks properly when Radiator closed. Filler opening for engine oil Brake and clutch fluid reservoir (left-hand drive) Battery Relay and fuse box, engine compartment Volvo recommends Castrol oil products. Engines with electronic oil level sensor have no dipstick (5-cyl. diesel).
Page 292 If the car is driven in adverse con- into the oil sump. engine oil at the factory. The choice of oil ditions, Volvo recommends using an oil of a has been made very carefully with regard to higher grade than that specified on the decal, service life, starting characteristics, fuel see page 332.
Page 293 08 Maintenance and service Engine compartment 3. Re-insert the dipstick. Engine with electronic oil level sensor 4. Pull it out and check the level. 5. If the level is close to MIN then 0.5 litres should be added. If the level is significantly below, then an additional amount is required.
Page 294 08 Maintenance and service Engine compartment > You will then see information displayed Coolant NOTE about the engine oil level. The oil level is only detected by the system Checking the level and topping up during driving. The system cannot directly detect changes when the oil is filled or drained.
Page 295 WARNING before topping up the brake fluid. Volvo rec- the cooling system. ommends that the reason for the loss of Coolant can be very hot. If the coolant •...
Page 296 08 Maintenance and service Engine compartment 2. Unscrew the reservoir cap and fill the fluid. between the MIN and MAX marks. For capaci- The level must be between the MIN and ties and recommended fluid grade, see MAX marks, which are located on the page 333.
Page 297: Lamps
Detach the headlamp connector by lamp replacement must be performed at a pressing down the clip with your thumb. workshop - an authorised Volvo workshop is recommended. The lamp must be han- At the same time, guide out the con- dled with extreme caution because it is equipped with a high voltage unit.
Page 298 08 Maintenance and service Lamps Securing the headlamp Removing the cover Dipped beam, halogen When securing, check that the long lock pin is Before starting to replace a bulb, see 1. Detach the headlamp, see page 297. engaged - it should be engaged in both eyes. page 297.
Page 299 08 Maintenance and service Lamps Main beam, Halogen Extra main beam, Xenon* Direction indicators/flashers 1. Detach the headlamp. 1. Detach the headlamp. 1. Detach the headlamp. 2. Remove the cover, see page 298 2. Remove the cover, see page 298. 2.
Page 300 08 Maintenance and service Lamps Side marker lamps Rear fog lamp Location of rear bulbs Lamp lens, right-hand side Before starting to replace a bulb, see The rear fog lamp is accessed behind the Position (LED)/side marker lamps page 297. bumper Side reflector, rear 1.
Page 301 08 Maintenance and service Lamps Brake light and reversing lamp Number plate lighting Lighting, cargo area Both the brake light and the reversing lamp 1. Remove the screws with a screwdriver. 1. Insert a screwdriver and gently prize so bulbs are replaced from inside the cargo area. that the lamp housing comes loose.
Page 302 08 Maintenance and service Lamps Vanity mirror lighting 2. Then press the three lower lugs back into position. Removing the mirror glass Specification, bulbs Lighting Type Extra main beam, Xenon, ABL Dipped beam, hal- H7 LL ogen Main beam, Halo- Front direction PY21W 1.
Page 303: Wiper Blades And Washer Fluid
08 Maintenance and service Wiper blades and washer fluid Wiper blades 5. Move the right-hand stalk switch up for about 1 second. The wipers then move to Service position standing straight up. The wipers return to the starting position when the car is started.
Page 304 08 Maintenance and service Wiper blades and washer fluid Cleaning NOTE IMPORTANT For cleaning wiper blades and windscreen, see The wiper blades are different lengths. The Add washer antifreeze during the winter so page 317 and onwards. blade on the driver's side is longer than the that the fluid does not freeze in the pump, blade on the passenger side.
Page 305: Battery
08 Maintenance and service Battery Warning symbols on the battery Operation Avoid sparks and naked • Check that the cables to the battery are flames. Use protective goggles. correctly connected and properly tight- ened. • Never disconnect the battery when the engine is running.
Page 306 08 Maintenance and service Battery Changing NOTE The life of the battery is shortened if it Removal becomes discharged repeatedly. The life of the battery is affected by several factors, including driving conditions and cli- mate. Battery starting capacity decreases gradually with time and therefore needs to be recharged if the car is not used for a longer time or when it is only driven short...
Page 307 08 Maintenance and service Battery 3. Secure the battery using the battery clamp. WARNING 4. Connect the ventilation hose. Connect and disconnect the positive and negative cables in the correct sequence. 5. Connect the red positive cable. 6. Connect the black negative cable. 7.
Page 308: Fuses
If the same fuse fails repeatedly then there is a fault in the circuit. Volvo recommends that you visit an authorised Volvo workshop for checking. Changing 1. Look in the fuse diagram to locate the fuse.
Page 309 08 Maintenance and service Fuses Engine compartment...
Page 310 A under the glovebox Speed related power PTC element air pre- steering* heater* Engine control module, Headlamp washers* Transmission control module, Airbags An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 311 08 Maintenance and service Fuses Function Function Function Heated washer nozzles* Relay coil, relay, compres- Engine valves, Engine sor A/C control module (6-cyl.) Relay coil, relay, vacuum Solenoids, cam profile (6- Actuator solenoid, starter pump (5-cyl. petrol and cyl.) Actuator motors, motor 2.0T) intake manifold (6-cyl.)
Page 312 08 Maintenance and service Fuses Function Cooling fan (4-cyl., 5-cyl. petrol) Cooling fan (6-cyl. petrol, 5-cyl. diesel) Electro-hydraulic power steering...
Page 313 08 Maintenance and service Fuses Under the glovebox Positions Function Function Function Control panel, rear pas- senger door, right Primary fuse for audio 12 V socket, cargo area* control module* Control panel, rear pas- senger door, left Control panel, driver's door Keyless* Control panel, front pas-...
Page 314 08 Maintenance and service Fuses Function Function Function Power seat passenger Seat heating (driver's side) Interior lighting, Driver's side* door control panel, power windows, Power seats, Folding head restraint* front*, Remote controlled garage door opener* Seat heating, rear passen- Infotainment control mod- ger side right* Information display (DIM) Seat heating, rear passen-...
Page 315 08 Maintenance and service Fuses Function Remote control key receiver, Movement detec- tor alarm*, Climate panel Steering lock Siren alarm*, Data link con- nector OBDII Airbags Collision warning system Accelerator pedal, PTC element air preheater*, Dimming, interior rearview mirror*, Seat heating, rear* Brake light Sunroof* Immobiliser...
Page 316 08 Maintenance and service Fuses Cargo area The fuse box is located behind the upholstery on the left-hand side. Positions Function Function Electric parking brake, left Electric parking brake, right Rear window defroster Trailer socket 2* Trailer socket 1* Power operated tailgate* Option/accessory, for more information, see Introduction.
Page 317: Car Care
Outside lighting such as headlamps, fog During the first few months a new car must lamps and rear lamps may temporarily have Volvo workshop is recommended for the only be handwashed. This is because the condensation on the inside of the lens. This removal of any discoloration.
Page 318 However, the car can be A special cleaning agent available from Volvo waxed during this time. Do not polish or wax Take care when cleaning so as not to damage dealers is recommended for the cleaning and the car in direct sunlight.
Page 319 (or more if authorised Volvo dealers, is recommended to ucts recommended by Volvo. Clean regularly necessary). The Volvo Leather Care kit is avail- avoid impairing the fire retardant qualities of and follow the instructions included with the able from your Volvo dealer.
Page 320 Do not scrape or rub stains. Never use strong tened sponge and neutral soap. stain removers. A special cleaning agent avail- • able from Volvo dealers can be used for more Leather needs to breathe. Never cover the leather steering wheel with protective plas- difficult cleaning.
Page 321 08 Maintenance and service Car care Colour code Before work is begun, the car must be clean and dry and at a temperature above 15 °C. 1. Apply a piece of masking tape over the damaged surface. Then remove the tape to remove any loose paint.
Page 322 Type designations................. 324 Dimensions and weights............... 326 Engine specifications................330 Engine oil....................331 Fluids and lubricants................333 Fuel....................... 335 Wheel and tyres, dimensions and pressure ......... 336 Electrical system................... 337 Type approval..................338 Symbols in the display................350...
Page 323 S P E C I F I C A T I O N S...
Page 324: 09 Specifications
09 Specifications Type designations Label location...
Page 325 NOTE identification and engine numbers can facili- The labels shown in the owner's manual are tate all contact with an authorised Volvo dealer not provided as exact reproductions of regarding the car and when ordering spare those in the car. The purpose is to show parts and accessories.
Page 326: Dimensions And Weights
09 Specifications Dimensions and weights Dimensions Weights Dimensions Dimensions Kerb weight includes the driver, the fuel tank Wheelbase 2774 Rear track 1586 90% full and all fluids. The weight of passengers and accessories, Length 4627 Load width, floor 1090 and towball load (when a trailer is hitched, see Load length, floor, folded rear Width 1891...
Page 327 09 Specifications Dimensions and weights Max. load: See registration document. NOTE WARNING Max. roof load: 100 kg. The documented kerb weight applies to The car's driving characteristics change cars in the standard version - i.e. a car with- depending on how heavily it is loaded and out extra equipment or accessories.
Page 328 09 Specifications Dimensions and weights Towing capacity and towball load Engine Gearbox Max. weight braked trailer (kg) Max. towball load (kg) 0–1200 2.0T Automatic, MPS6 1800 Automatic, MPS6 1800 3.2 AWD Automatic, TF-80SC 1800 T6 AWD Automatic, TF-80SC 2000 Automatic, TF-80SC 1600 DRIVe Manual, M66...
Page 329 09 Specifications Dimensions and weights NOTE The use of a stabiliser hitch on the towing bracket is recommended for trailers heavier than 1800 kg.
Page 330: Engine Specifications
09 Specifications Engine specifications Engine specifications Model Engine Output Output Torque (Nm/ No. of Bore Stroke Swept Com- code (kW/rpm) (hp/rpm) rpm) cylin- (mm) (mm) volume pression ders (litres) ratio 2.0T B4204T6 149/6000 203/6000 300/1750–4000 87,5 83.1 1.999 10.0:1 B4204T7 177/5500 240/5500 320/1800-5000...
Page 331: Engine Oil
Choose a fully synthetic engine oil for adverse Volvo Car Corporation disclaims all war- driving conditions. It provides extra protection ranty liability if engine oil of the prescribed for the engine.
Page 332 09 Specifications Engine oil Engine oil grade Engine variant Engine code Volume, incl. oil filter (litres) B6304T4 Oil grade: ACEA A5/B5 Viscosity: SAE 0W–30 B6324S5 D3 AWD D5244T16 D3 / DRIVe D5204T2 D5244T10 2.0T B4204T6 Oil grade: ACEA A5/B5 Viscosity: SAE 5W–30 B4204T7 When driving under adverse conditions, use ACEA A5/B5 SAE 0W-30.
Page 333: Fluids And Lubricants
DOT 4+ Power steering fluid Power steering – WSS M2C204-A2 or equivalent product. Washer fluid Cars with headlamp Use a washer antifreeze recommended by Volvo, mixed with water. washing Cars without headlamp washing Fuel Petrol engine approx. 70 Petrol, see page 256 Diesel engine approx.
Page 334 09 Specifications Fluids and lubricants NOTE Under normal driving conditions, the gear- box oil does not need to be changed during its service life. However, this may be nec- essary under adverse driving conditions, see page 333.
Page 335: Fuel
09 Specifications Fuel See further information and more advice on pages 13 and 252. See page 256 for general information on fuel. Fuel consumption There are several causes that can affect fuel consumption negatively. Examples of this are: • The driver's driving style. •...
Page 336: Wheel And Tyres, Dimensions And Pressure
09 Specifications Wheel and tyres, dimensions and pressure Approved tyre pressures Variant Tyre size Speed Load, 1 - 3 persons Max. load ECO pres- sure (km/h) Front Rear Front Rear Front/rear (kPa) (kPa) (kPa) (kPa) (kPa) 235/65 R 17 0 - 160 235/60 R 18 All engines 235/55 R 19...
Page 337: Electrical System
09 Specifications Electrical system Electrical system The battery capacity is dependent upon the IMPORTANT equipment level in the vehicle. The car has a voltage-regulated AC alternator. If the battery is replaced, replace it with a The electrical system is single-pole and uses battery of the same cold start capacity and the chassis and engine casing as a conductor.
Page 338: Type Approval
09 Specifications Type approval Remote control system Radar system Country Country Country A, B, CY, Singapore CZ, D, DK, Delphi hereby certifies E, EST, F, that this remote control key FIN, GB, system conforms to the IDA: Infocomm Development GR, H, I, essential characteristic Authority of Singapore.
Page 339 09 Specifications Type approval Bluetooth Declaration of Conformity (Declaration of Conformity) Country Countries in the EU Exporting country: Japan Manufacturer: Alpine Electronics Inc. Type of equipment: Bluetooth device For further information visit http://ec.europa.eu/enterprise/rtte/faq.htm #informing...
Page 340 09 Specifications Type approval Country Czech Alpine Electronics, Inc. tímto prohlašuje, že tento Bluetooth Module je ve shodě se základními požadavky a dalšími příslušnými Republic: ustanoveními směrnice 1999/5/ES. Denmark: Undertegnede Alpine Electronics, Inc. erklærer herved, at følgende udstyr Bluetooth Module overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Page 341 09 Specifications Type approval Country Estonia: Käesolevaga kinnitab Alpine Electronics, Inc. seadme Bluetooth Module vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. Hereby, Alpine Electronics, Inc., declares that this Bluetooth Module is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Page 342 09 Specifications Type approval Country Poland: Niniejszym Alpine Electronics, Inc. oświadcza, że Bluetooth Module jest zgodny z zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Portugal: Alpine Electronics, Inc. declara que este Bluetooth Module está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Page 343 09 Specifications Type approval Country China: • • • • •...
Page 344 09 Specifications Type approval Country Taiwan: CCAB10LP0230T7...
Page 345 09 Specifications Type approval Country South Korea: Volvo Car Korea Alpine Electronics, Inc Made in Japan Volvo Car Korea http://www.volvocars.com/kr...
Page 346 09 Specifications Type approval Country Singa- pore: The Uni- ted Arab Emirates Jordan: The product that contains the Bluetooth module is approved with the following certification number. BT module certification number: TRC/LPD/2010/4. BT module name: IAM2.1BT PWB EU...
Page 347 09 Specifications Type approval Country South Africa Uruguay This product contains URSEC approved transmitter [module name and model name (IAM2.1 BT PWB EU + BVJG905A, BVVE905A, BVLV905A)]...
Page 348 09 Specifications Type approval Country Jamaica Approved for use in Jamaica SMA EI: IAM2.1 Thailand This telecommunication equipment conforms to NTC technical requirement. Nigeria Mexico Warning "Este equipo opera a titulo secundario, consecuentemente, debe aceptar interferencias perjudiciales incluyendo equipos de la misma clase y puede no causar interferencias a sistemas operando a titulo primario."...
Page 349 09 Specifications Type approval Country Botswana Croatia...
Page 350: Symbols In The Display
09 Specifications Symbols in the display General Symbols in the display Indicator and information symbols in the combined instrument panel There are a variety of different symbols in the Indicator and warning symbols in the display in the car. The symbols are divided into Symbol Meaning Page...
Page 351 09 Specifications Symbols in the display Symbol Meaning Page Symbol Meaning Page Symbol Meaning Page Left-hand Adaptive cruise 159, 166 ABL system* direction indi- control*, Distance cators Alert* Right-hand Adaptive cruise 159, 166 Fuel filler flap, right- direction indi- control*, Distance hand side cators Alert*...
Page 352 09 Specifications Symbols in the display Information symbols in the roof console display Symbol Meaning Page Seatbelt reminder Airbag, passenger 24, 25 seat, activated Airbag, passenger seat, deactivated...
Page 353 09 Specifications...
Page 354: 10 Alphabetical Index
10 Alphabetical Index Air distribution........138, 144 Audio volume .......... 205 phone..........236 Air quality system IAQS ......143 ACC – Adaptive cruise control....157 phone/media player......236 Air vents........... 138 ring signal, phone....... 236 Active Bending Lights (ABL)...... 83 Alarm............
Page 355 10 Alphabetical Index Battery..........305, 337 filling brake fluid........295 CD ............218 maintenance........305 symbols in the combined instrument Centre console........130 Remote control ........232 panel........... 117 Chassis settings........154 remote control key/PCC....... 51 Bulbs, see Lighting........297 Checking and topping up the coolant..
Page 356 10 Alphabetical Index seatbelts..........320 Cooling system........252 Driver Alert Control........180 upholstery........... 319 Crash, see Collision........33 Driver Alert System........180 Clean Zone Interior Package (CZIP)..137 Cruise control.......... 155 Driving............252 Climate control........136 cooling system........252 Curtain general..........
Page 357 10 Alphabetical Index Emergency equipment Error messages FSC, environmental labelling..... 13 warning triangle........282 Driver Alert Control......181 Fuel............256 Lane Departure Warning..... 184 Emergency puncture repair..... 283 fuel consumption........ 335 see Messages and symbols....164 fuel economy........281 Engine Error messages in BLIS......
Page 358 10 Alphabetical Index Glass Heat-reflecting windscreen......94 overview ..........204 laminated/reinforced......94 source buttons ........204 High engine temperature......264 voice control........241 Global opening........137 High-pressure headlamp washing..... 92 Inlaid mats..........197 Glovebox..........197 Hill Descent Control......... 118 locking..........57 Instrument lighting, see Lighting....
Page 359 10 Alphabetical Index Key blade........... 49 instrument lighting........ 82 Lubricants..........333 main/dipped beam....... 82 Keyless drive........53, 107 Lubricants, capacities......333 position/parking lamps......84 Keyless start (keyless drive)....53, 107 rear fog lamp........84 Keypad in the steering Lighting, bulb replacement...... 297 wheel.........
Page 360 10 Alphabetical Index Messages and symbols MY CAR........... 130 Parking assistance........186 Collision Warning with Auto parking assistance sensors....188 Brake.......... 172, 178 Parking brake........... 120 Distance Alert........167 Parking heater.......... 146 Driver Alert Control......181 battery and fuel........146 Lane Departure Warning.....
Page 361 10 Alphabetical Index Polishing..........318 Rear window, defrosting......97 Retractable power door mirrors....96 Position/parking lamps......84 Recirculation..........143 Reverse gear inhibitor......110 Power panorama roof......100 Recommendations during driving.... 252 Rims cleaning..........318 Power seat..........77 Recommended child seats, table....36 Roll-over protection........
Page 362 10 Alphabetical Index heating..........141 Steering wheel........... 81 lowering the front backrest....76 keypad......81, 130, 155, 206 lowering the rear backrest....79 keypad, adaptive cruise control..159 Tailgate............58 power seats.......... 77 steering wheel adjustment....81 locking/unlocking........57 open............59 Securing loads (Loading)......
Page 363 10 Alphabetical Index Trailer stability assist ......152 parking brake applied......71 seatbelt reminder........71 Trailer Stability Assist......269 Unlocking warning..........71 Transmission..........110 from the inside........56 Warning sound Transponder..........94 from the outside........56 collision warning system....174 Trip computer..........
Page 364 10 Alphabetical Index Whiplash injury, WHIPS......29 WHIPS child seat/booster cushion....29 whiplash injury........29 Windows, rearview and door mirrors..94 Windscreen washing........92 Windscreen wipers........91 rain sensor..........91 Winter driving........... 253 Winter tyres..........276 Wiper blades..........303 changing..........303 cleaning..........
Page 366 Kdakd 8Vg 8dgedgVi^dc IE &'+&( :c\a^h] ! 6I &%)+! Eg^ciZY ^c HlZYZc! <ŽiZWdg\ '%&%! 8deng^\]i © '%%%"'%&% Kdakd 8Vg 8dgedgVi^dc Int.
