Electronic Climate Control, Ecc; Heated Seats - Volvo XC60 Owner's Manual

04 Comfort and driving pleasure
Climate control

Electronic climate control, ECC

04
Fan
Air distribution
Heated front seats, left-hand side
AUTO
Heated front seats, right-hand side
Temperature control, right-hand side
AC ON/OFF – Air conditioning On/Off
Rear window and door mirror defrosters,
see page 91
Max. defroster
1 Only applies to ECC.
2 Not included if 2-stage booster cushion is selected.
*
124
Option/accessory, for more information, see Introduction.
Recirculation/Air quality system
Temperature control, left-hand side
Operation
1
Fan
Turn the knob to increase or
decrease fan speed. If AUTO
is selected then fan speed is
regulated automatically. The
previously set fan speed is
disengaged.
NOTE
If the fan is fully disengaged the air condi-
tioning is not engaged which may result in a
risk of misting windows.

Heated seats*

Front seats
Press the button once for the
highest heat level – three
lamps illuminate.
Press the button twice for a
lower heat level – two lamps
illuminate.
Press the button three times for the lowest heat
level – one lamp illuminates.
Press the button four times to switch off the
heat – no lamps illuminate.
Rear seats
Heat control takes place in the same way as for
2
the front seat .
Air distribution
The figure consists of three
buttons. When the buttons
are pressed a lamp in front of
the respective part of the fig-
ure illuminates and shows
which air distribution is
selected, see page 127.
