- Page 1 S E R I E S STARFIRE-10 STARFIRE-12 STARFIRE-MINI w w w . c h r y s a l i s a c o u s t i c s . c o m...
- Page 2 Starfire Series Manual...
-
Page 3: Table Of Contents
w w w . c h r y s a l i s a c o u s t i c s . c o m A B L E O F O N T E N T S Congratulations ....................1 Installation . -
Page 4: Congratulations
w w w . c h r y s a l i s a c o u s t i c s . c o m O N G R A T U L A T I O N S Congratulations on your purchase of a Chrysalis Starfire™... -
Page 5: Installation
w w w . c h r y s a l i s a c o u s t i c s . c o m P l a c e m e n t The first step in installing your new Starfire is to determine where it will be placed in the room. Unpack the system carefully and use the following guidelines in order to find the best room placement option. - Page 6 w w w . c h r y s a l i s a c o u s t i c s . c o m To alleviate this condition, we recommend the following steps: 1) If using line level jacks, BOTH THE LEFT AND RIGHT INPUT CAN BE USED – never use just the left or just the right input.
- Page 7 w w w . c h r y s a l i s a c o u s t i c s . c o m P h a s e A d j u s t m e n t - 0 ° / 1 8 0 ° This control allows you to “reverse”...
-
Page 8: Rear Panel Connections
w w w . c h r y s a l i s a c o u s t i c s . c o m E A R A N E L O N N E C T I O N S Figure 1.Starfire Rear Panel Connections Figure 1 shows the connections on the rear panel of the Starfire. -
Page 9: Crossovers
w w w . c h r y s a l i s a c o u s t i c s . c o m Power indicator - Red: Unit is in standby mode. Green: Unit is in operation mode. (automatically turns to STANDBY mode if no signal for eight minutes) PHASE switch - Select the switch position at which you hear a louder mid-bass sound. - Page 10 w w w . c h r y s a l i s a c o u s t i c s . c o m Figure 2a. Line-Level Subwoofer Connection Diagram Starfire Series Manual...
- Page 11 w w w . c h r y s a l i s a c o u s t i c s . c o m Figure 2b. Speaker-Level Subwoofer Connection Diagram Starfire Series Manual...
-
Page 12: Interconnect Cables
w w w . c h r y s a l i s a c o u s t i c s . c o m N T E R C O N N E C T A B L E S When installing your new Chrysalis subwoofer using the line level connections, you should always use shielded phono cables. -
Page 13: Troubleshooting And Service
w w w . c h r y s a l i s a c o u s t i c s . c o m R O U B L E S H O O T I N G A N D E R V I C E Before seeking service for your amplifier or subwoofer, please re-check all systems. -
Page 14: Specifications
w w w . c h r y s a l i s a c o u s t i c s . c o m P E C I F I C A T I O N S MODEL STARFIRE-10 STARFIRE-12 STARFIRE-MINI... -
Page 15: Chrysalis Products
w w w . c h r y s a l i s a c o u s t i c s . c o m H R Y S A L I S R O D U C T S BassMatrix™... - Page 16 w w w . c h r y s a l i s a c o u s t i c s . c o m F O R Y O U R R E C O R D S . . . Date Purchased____________________________________________________________________________ Dealer__________________________________________________________________________________ Serial #_________________________________________________________________________________...
- Page 17 C h r y s a l i s A c o u s t i c s A Velodyne Company 345 Digital Drive Morgan Hill, CA 95037 408.465.2888 voice 408.779.9227 fax 408.779.9208 service fax w w w . c h r y s a l i s a c o u s t i c s . c o m Service E-mail: service@chrysalisacoustics.com...
