Velodyne Digital Drive Series User Manual

Velodyne Digital Drive Series User Manual

Featuring software version 2.0
Hide thumbs Also See for Digital Drive Series:
Table of Contents

Advertisement

Quick Links

Digital Drive
™
Series
U S E R ' S
M A N U A L
F e a t u r i n g S o f t w a r e V e r s i o n 2 . 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digital Drive Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Velodyne Digital Drive Series

Summary of Contents for Velodyne Digital Drive Series

  • Page 1 U S E R ’ S M A N U A L F e a t u r i n g S o f t w a r e V e r s i o n 2 . 0 Velodyne...
  • Page 2 C a u t i o n ! caution il reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing qualified service personnel. The lightning flash with arrowhead symbol is intended alert the user the presence of uninsulated "dangerous voltage' within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 3 At t e n t i o n ! ATTENTION e pas ouvri Attention Alin d'eviter tout risque d'electrocution, ne enlever Ie couvercle (ou la partie amere). AuaJne piece interne ne peut etre manipulae par I'utilisateur Confiez I'entretien un personnel qualifis. «...
  • Page 4 Vo r s i c h t ! VORSICHT Vorsicht Um der Gefahr von Stromschlligen vorzubeugen, das Gehliuse (bzw. die ROckwand) nicht abnehmen. 1m Inneren befinden sich keine Teile, die vem Benutzer gewartet werden kOnnen. Reparatur- und Wartungsarbeiten nur von entsprechend qualifizierten Kundendienstlechnikem durchfOhren lassen. m~ Pfeilsp~' Das Symbol .Blitz soil den Benutzer wamen, dass im Gehause des Produkts eine nicht...
  • Page 5 At t e n z i o n e ! ATTENZIONE Attenzione Per ridurre il pericolo di scossa elellrica, non Iogliere il coperchio la parete posteriore). L'intemo non contiene parti su cui I'utente possa intervenire. Per assistenza e riparazioni, rivolgersi a personale tecnico qualificalo.

  • Page 6: Table Of Contents

    Ta b l e o f C o n t e n t s Congratulations ........... .1 Before you Begin .

  • Page 7: Congratulations

    Regardless of where you install your Velodyne subwoofer, it must remain in an upright position (woofer facing forward).

  • Page 8: Package Contents

    Pa c k a g e C o n t e n t s Your Velodyne Digital Drive Subwoofer consists of the following components: • Digital Drive Subwoofer • Power Cord • Remote Control • Digital Drive Accessory Kit, consisting of:...

  • Page 9: Remote Control

    R E M O T E C O N T R O L The Velodyne Digital Drive infrared remote control allows you to set up, adjust, and reset your subwoofer when connected to a television or a video monitor. You will also use your remote to activate preset listening values, set the subwoofer’s volume up or down, mute the subwoofer,...
  • Page 10 • SET (+/-) – Increases or decreases the Q value for a parametric EQ, or sets values on the settings page. • LIGHT – Turns the subwoofer’s front panel Velodyne logo indicator on or off. • NIGHT – Limits the peak output of the subwoofer, and illuminates the logo’s amber underlining to...

  • Page 11: Digital Drive Accessory Kit

    I n s ta l l a t i o n O v e r v i e w Your new Velodyne servo subwoofer provides for a number of installation options. Read all the installation information below in order to determine which installation option is best for your system.
  • Page 12 '"'u ..Veodyne 8 H - - - - - - - - - - - - - - + • ®®®@ "'" .- .. """" SPEAXER'lEY£L tNAn 1812~ rDigita{ (Drive Signature. r£ditio11. Figure 2: Digital Drive Rear Panel Connections w w w .
  • Page 13 POWER – Press the POWER switch to the ON position to activate the subwoofer. If the unit is to be left unused for an extended period of time, move this switch to the OFF position to prolong the life of the subwoofer. 117V~60Hz 15A –...

  • Page 14: Installation Quick Start

    I n s ta l l a t i o n – Q u i c k S ta r t To set up and take advantage of the EQ features in your new Digital Drive subwoofer in the least amount of time, perform the following steps: 1.

  • Page 15: Installation Step-By-Step

    A W o r d A b o u t S u b w o o f e r O u t p u t s The Velodyne subwoofer is designed to operate using the full range audio signal for input when using the digital built-in crossover.

  • Page 16: A Word About Interconnect Cables

    A W o r d A b o u t I n t e r c o n n e c t C a b l e s When installing your new Velodyne subwoofer using the line level connections, you should always use shielded phono cables.
  • Page 17 NOTE: When a DD subwoofer detects an incoming RS-232 command, it reverts to “Slave Mode”. This means that the subwoofer will no longer accept IR commands. To reestablish normal operations, remove the RS-232 cable and power cycle the unit. Note that the daisy chain connection ONLY allows the woofers to communicate basic “run-time” commands such as volume and preset.

  • Page 18: Subwoofer Setup - Overview

    O N - S C R E E N S e t u p This section describes adjusting the onscreen settings of your Digital Drive subwoofer. You will be performing all the setup functions using the buttons of your Velodyne-supplied remote control and seeing the results on your TV screen.
  • Page 19 Figure 3: Introductory Screen See Figure 3. This the Introductory screen. Notice that as you change settings (such as preset, volume, etc.) they are shown on this screen. You enter setup mode by pressing MENU and entering the code 12345. Upon successful entry of this code, the system takes you to the EQ Setup screen, as shown in Figure 4.
  • Page 20 Figure 4: EQ Setup screen The EQ Setup screen includes a “SYSTEM RESPONSE” “sweep” window and a graphic equalizer. You use these settings to equalize your room. The graphic equalizer features 8 bands, each of which can be used at its current frequency, or can be infinitely adjusted to the frequency and EQ you desire.
  • Page 21 Figure 5: System Settings Screen From this screen the crossover, subsonic filter, phase, polarity, theater/music, volume, and other settings can be set, as well as specifics for each preset, if desired. Your DD unit comes with 6 presets, four of which are preprogrammed at the factory. The Setup setting is used to initially set the crossovers, slopes, phase, polarity, and volume for all presets.
  • Page 22 • Night Mode Maximum Volume – When the NIGHT mode button is pressed on the remote, this setting is invoked. Night mode is indicated by the amber bar underlining the VELODYNE logo. The subwoofer will not play louder than this volume level until the night mode is defeated.

  • Page 23: Onscreen Programming And Setup - Step By Step

    Input should be configured for stereo. 5. Set the video input where you connected the video output as the active TV image. The introductory screen with the Velodyne logo and “Velodyne Digital Drive” should now appear on your TV screen, as follows: w w w .
  • Page 24 6. Press MENU and enter 12345 to enter the EQ setup screen, as follows: w w w . v e l o d y n e . c o m Digital Drive User’s Manual...
  • Page 25 Upon pressing 5, you should see the following screen: w w w . v e l o d y n e . c o m Digital Drive User’s Manual...
  • Page 26 7. Use the DD remote control to MUTE the subwoofer. 8. Raise the volume on your receiver/processor until the DD test sweep (a tone that sweeps from 20Hz up to 200Hz) can be heard from your system’s speakers. Continue to raise the volume until the “SYSTEM RESPONSE”...
  • Page 27 9. Now use the DD remote control to unmute the subwoofer, then use the volume up and down keys to match the level of the subwoofer to your full range speakers. That is, the “SYSTEM RESPONSE” graph should be relatively flat (although at this point there will be peaks and valleys that will be addressed next).
  • Page 28 Avoid these locations when possible. When using a pair of Velodyne subwoofers in stereo, it is preferable to place each subwoofer by the satellite of the same channel. If moving your satellites is an option, they too can contribute to peaks and valleys and should be likewise placed through experimentation.
  • Page 29 TIP: Here’s an easy way to find the optimal position for the subwoofer without moving it to multiple positions in the room. Start by setting the subwoofer up in your listening position. Now, move the microphone around the room and observe the response graphs for different room positions.
  • Page 30 AND REMEMBER: Use the UP , DOWN, RIGHT and LEFT directional arrow buttons that surround SELECT to move through the fields of the setup screen, and change settings by using the SELECT button, then the UP and DOWN arrow keys. Or, you can skip the SELECT button and change values using the SET +/- buttons.
  • Page 31 TIP: To see immediate feedback on the effects of your changes to the “SYSTEM RESPONSE” graph, press the TEST button. The following screen appears: Press TEST again to return to the System Settings screen. w w w . v e l o d y n e . c o m Digital Drive User’s Manual...
  • Page 32 NOTE: Some receivers/processors supply a signal that is already crossed over – i.e. just the bass frequencies. If this is the case, you will want to defeat the subwoofer’s low pass crossover. To defeat the low pass crossover, press the SELECT key, then the RESET key. The following screen appears: w w w .
  • Page 33 NOTE: Your goal in setting the low pass crossover is to make the crossover point (the point at which the subwoofer meets the main speakers in terms of frequency) as smooth as possible. Another big factor in smoothing this point in the curve is phase, discussed in step 17, below. 15.
  • Page 34 NOTE: The following step shows using the graphic equalizer (using fixed frequencies and Q) to equalize the room. 18. Next, return to the EQ setup screen and adjust the graphical EQs to eliminate peaks and valleys from the room response. Use the right and left arrow keys to position the cursor over the EQ you wish to adjust.
  • Page 35 19. Continue this process until the “SYSTEM RESPONSE” graph shows a +/– 3 dB response across the bass frequencies (that is, up to about 120Hz.). Note that this does not necessarily mean a “ruler flat” response; +/- 3dB is typical for an optimized response curve.
  • Page 36 20. To have the unit EQ itself, select the auto EQ option, as shown: When this mode is selected, the unit automatically resets all EQs to their original frequencies, and Q settings (but retains any level changes you may have made). The AUTO EQ proceeds until you either save settings, press SELECT to return to manual EQ, move the cursor off the AUTO EQ field (in which case the field automatically reverts to MANUAL), or twenty-five sweeps have occurred.
  • Page 37 NOTE: The following steps use the parametric equalizer to achieve room equalization. If you do not wish to use the parametric EQ feature, skip to step 24. 21. To use the parametric EQ feature, position the cursor over the EQ and press the SELECT button.
  • Page 38 22. To manipulate a parametric EQ, you can now use the LEFT and RIGHT arrow keys to move the frequency up and down, and the SET + and SET – keys to change the Q value. Use the UP and DOWN arrow keys to adjust the level of the EQ as before. A selected EQ that has been moved, with its level raised and Q adjusted is shown below: 23.
  • Page 39 24. Once the room has been equalized, you may want to return to the Settings Setup screen (by positioning the cursor over the NEXT field on the EQ setup screen and pressing SELECT) and review/modify the presets. This step is required ONLY if you wish to customize the presets.
  • Page 40 You can change any value in the presets column, then use the TEST key to review the curve with these settings active. This is shown below. Features of each preset are: EQ. There can be a completely different set of EQs for each preset. Simply select the preset you want on the “SYSTEM RESPONSE”...
  • Page 41 Contour frequency and level. These act as an “extra” EQ that can be used to manipulate the frequency contour of your subwoofer when this particular preset is invoked. For example, notice that preset one raises the level by 3 dB at 35Hz – this is to accommodate action/adventure movie content.
  • Page 42 24. As a final thought on matching your Digital Drive subwoofer to your room, don’t forget the “objective listening” test. That is, make sure the unit sounds good to you! Often, you may want to add a bit more bass than what would normally be considered “flat” even after you remove the major peaks and valleys to achieve a flat frequency response.

  • Page 43: Restoring Defaults

    By pressing the SELECT button, you tell the system to save your settings and return to the introduction screen. Selecting NO returns without saving (i.e. whatever previous settings were in effect will be used), and CANCEL keeps you in setup mode. When the unit saves settings, you will see the video flicker and you may hear a slight tick in your main speakers.
  • Page 44 Runtime Mode During normal use of your Digital Drive Subwoofer, you can use the preset buttons to invoke certain presets, use the volume control to raise or lower the subwoofer’s volume, use the light and night buttons to control the logo light and night mode, respectively, and use the mute button to mute the subwoofer.
  • Page 45 Runtime Inactive Modes. The following screens show other runtime messages indicating that the subwoofer is inactive. The screen below shows the message displayed when the auto-off feature has engaged (that is, the subwoofer has not had any input signal for 15 minutes: w w w .
  • Page 46 The following screen is displayed when the POWER button is depressed, powering down the subwoofer: Note that in this mode the POWER button must be pressed again to reactivate the unit. w w w . v e l o d y n e . c o m Digital Drive User’s Manual...
  • Page 47 The following screen is shown when the unit is waiting for a 12-volt trigger to activate: w w w . v e l o d y n e . c o m Digital Drive User’s Manual...

  • Page 48: About Room Equalization

    A b o u t R o o m E q u a l i z a t i o n This section gives some background on room equalization. As a sub plays in a room, the reflections of the sound waves off the walls create “standing waves,” that is, places in the room where certain frequencies are louder and others are diminished.

  • Page 49: Troubleshooting And Service

    Velodyne dealer, or directly from Velodyne. Next, proceed to the Velodyne web site and click on the link to download the software. Upon download, run the software and it will instruct you on completing the update process.

  • Page 50: Appendix A: Rs-232 Serial Overview And Commands

    Appendix A: RS-232 Serial Overview and Commands I n t r o d u c t i o n This document outlines Velodyne’s Digital Drive (DD) RS-232 protocol specification. This protocol indicates how Digital Drive products receive run-time commands from devices such as Creston Universal Remote Controls.
  • Page 51 RS232 Commands Activity Command Acceptable Example(s) Comments Format n Values Volume Control #VOnn$, 00 – 99 #VO25$, Sets volume to a value, #VO+$, #VO+$, increments volume up #VO-$, #VO-$, or down, or requests #VO?$ #VO?$ current volume setting Preset Control #PSn$, 1, 2, 3, 4, #PS1$, #PS2$,...

  • Page 52: Appendix B: Summary Of Special Remote Codes

    Appendix B: Summary of Special Remote Codes Following are special remote codes and their functions. Unless otherwise noted, the codes are active only on the cover page. Function Code Description Self-EQ 3-2-1 Initiates Self-EQ feature. Be sure to connect the microphone before engaging.

  • Page 53: Appendix C: What's New In Release 2.0

    Appendix C: What’s New in release 2.0 Your Digital Drive subwoofer has version 2.0 of the digital drive room management software installed. Following is a description of the new features for version 2.0. Feature Description Auto-EQ New option on graph screen. When set to AUTO, this option resets the EQs to default third-octave frequencies (20, 25, 32, 40, 50, 63, 80, 100 Hz), and adjusts +/- 1 dB max each sweep.
  • Page 54 Velodyne light will blink faster as the volume increases, and slower as the volume decreases. Light blink scheme for The Velodyne light blinks the number of times for the preset selection preset (e.g. three times for preset three). Accommodate all requested This was introduced in release 1.6 and has been...

  • Page 55: Appendix D: Important Subwoofer Information

    Appendix D: Important Subwoofer Information Important Information Regarding your Velodyne Digital Drive™ Series Subwoofer (DD-15 and DD-18 only) and THX™ Ultra T H X U l t r a P r e s e t s f o r t h e V e l o d y n e D i g i t a l D r i v e S e r i e s :...
  • Page 56 If VELODYNE determines the unit is defective, VELODYNE will, at VELODYNE’s option, repair or replace the product at no charge if the product is forwarded prepaid to a factory authorized service representative. Products forwarded to the factory authorized service representative should be shipped securely and properly packaged, insured and freight prepaid.
  • Page 57 Velodyne Acoustics, Inc. 345 Digital Drive Morgan Hill, CA 95037 408.465.2800 voice 408.779.9227 fax 408.779.9208 service fax www.velodyne.com Service E-mail: service@velodyne.com Product E-mail: help@velodyne.com Technical E-mail: techhelp@velodyne.com w w w . v e l o d y n e . c o m...
