Tech 21 BOOST OVER DRIVE Owner's Manual

Download this manual

Enlarged version

POWER REQUIREMENTS

Utilizes standard 9V alkaline battery (not included). NOTE: nput jack

activates battery.To conserve energy, unplug when not in use. Power

Consumption: approx. 5mA, for battery life of approximately 100 hours.

*USE DC POWER SUPPLY ONLY!

unit and void warranty. DC Power Supply Specifications:

-9V DC regulated or unregulated, 100mA minimum;

-2.1mm female plug, center negative (-).

Optional factory power supply is available: Tech 21 Model

WARNINGS:

* Attempting to repair unit is not recommended and may void warranty.

* Missing or altered serial numbers automatically void warranty. For your own

protection: be sure serial number labels on the unit's back plate and exterior

box are intact, and return your warranty registration card.

ONE YEAR LIMITED WARRANTY. PROOF OF PURCHASE RE-

QUIRED. Manufacturer warrants unit to be free from defects in materials and

workmanship for one (1) year from date of purchase to the original purchaser and

is not transferable.This warranty does not include damage resulting from accident,

misuse, abuse, alteration, or incorrect current or voltage. If unit becomes defective

within warranty period,Tech 21 will repair or replace it free of charge.After expi-

ration,Tech 21 will repair defective unit for a fee.

ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return Au-

thorization Number. Manufacturer will not accept packages without prior

authorization, pre-paid freight (UPS preferred) and proper insurance.

FOR PERSONAL ASSISTANCE & SERVICE:

Contact Tech 21 weekdays from 10:00 AM to 5:00 PM, EST.

MADE IN THE U.S.A.

Tel: 973-777-6996 / Fax: 973-777-9899

www.tech21nyc.com / info@tech21nyc.com

Failure to do so may damage the

DC2.

OWNER'S MANUAL

Page 1 21 will repair or replace it free of charge.After expi- ration,Tech 21 will repair defective unit for a fee. ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return Au- thorization Number. Manufacturer will not accept packages without prior authorization, pre-paid freight (UPS preferred) and proper insurance.
Page 2 TECH 21, THE COMPANY APPLICATIONS and CONTROLS Tech 21 was formed by a guitarist possessing the unusual combination of a trained Use with any amp --tube or solid state, vintage or modern. NOTE: You can also achieve the same results using the Boost Overdrive in conjunction with any model ear and electronics expertise.
Page 3 NOTEWORTHY NOTES 1) Tech 21 controls are unusually sensitive and tend to perform well be- yond what would be considered “normal.” So you need not set everything at max to get maximum results. 2) To find the best settings for interacting with your other gear, you may need to use radically different settings for each individual way you use it.You need...
