Page 1: Installation Manual
CD-1A Model (CD-RW drive for the VF160) Installation Manual... - Page 2 * make your original audio CD using materials recorded on the VF160, or * load song data from an audio CD. This manual describes how to install the CD-1A in the VF160. See the VF160 operation manual for details about how to save/load song data or how to make an audio CD.
-
Page 3: How To Install The Cd-1A
How to install the CD-1A <Notes on installing the CD-RW drive> Turn the VF160 over and insert the CD-1A into the slot on the front panel. Push the CD-1A firmly, without forcing, so that the connector of the CD-1A fits into its companion in the slot. -
Page 4: Opening/Closing The Tray
Use two screws supplied with the CD-1A to fix the CD-1A to the VF160 from the front panel. Tighten the screws with a screwdriver. screw position Use the screw you removed in step 1 to fix the blank panel supplied with the CD-1A to the front panel. -
Page 5: Placing/Removing A Disc
Placing/removing a disc The following are some notes on placing and/ or removing a disc. <IMPORTANT!> When placing a disc on the tray, support the tray from the bottom by your hand. If you push the disc to fit into the pivot on the tray without supporting the tray, the tray/drive may be dam- aged or broken. -
Page 6: Declaration Of Ec Directive
This equipment is compatible with the EMC Directive (89/336/EEC) - Directive on approximation of member nation's ordinance concerning the electromagnetic compatibility. This equipment is compatible only when connected to fostex specified product. The Affect of Immunity on This Equipment The affect of the European Specification EN50082-1 (coexistence of electromagnetic waves - common immunity specification) on this equipment are as shown below.
