Amana SS-PTAC50 Product Specifications

P S
roduct PecificationS
50 H
240/200 V
SS-PTAC50
z
olt
www.amana-ptac.com
PTAC
P T
ACkAged erminAl
H
And eAT
Our new PTAC is the quietest PTAC we've ever built! No
other unit in the industry offers so many extras already
built in as standard on every unit. Don't settle for anything
less than the Amana® brand Standard Advantage!
Features
• Bent Coil Design maximizes airflow through the 25%-increased
primary and secondary coil surfaces, further cooling the re-
frigerant and maximizing the sealed system life. This design
also maximizes the fan slinger ring, adding side surface for
condensate evaporation and reduced condensate overflow.
• Forward-curved 9-Blade Condenser Fan moves more air more effi-
ciently and with much less operating sound than fans with
fewer blades.
• Removable Top Condenser Shroud allows easy access to clean con-
denser coil and maintains the unit's efficiency and capacity.
• Pull-out Filter Design allows easy access to clean or replace the
filter. The slide-out design also allows you to use many op-
tional approved filter media, such as our Activated Charcoal
Filter Kit (CFK01B).
• Electronic Temperature Limiter in the DigiSmart™ PTAC allows you
to effortlessly select any of the four pre-programmed room
temperature ranges by simply flipping an easily accessible set
of switches. Save energy and money by avoiding the extreme
temperature settings that can occur with guest operation.
• Deep Base Pan & Sub-cooler holds additional condensate water
and allows more of the coil surface to be immersed in
condensate water, which further cools the refrigerant and
maximizes heat transfer. The new sub-cooler design is in
the deepened base pan and adds additional heat transfer.
• NEW Stonewood Room Front offers distinctive contours and a
modern appearance to enhance the character of even the
most luxurious room, while the sleek 7⅜" depth — one of
the shallowest in the industry — maximizes usable space
for your guests.
• NEW Stonewood Wall Sleeve has been dramatically strengthened
for more rigidity. The sleeve's base pan is now made of
drawn steel, so the sleeve has no breakable corner seams
that can potentially leak if improperly installed. (This item
purchased separately.)
A C
ir ondiTioner
P
umP
2/12
Supersedes 9/10
