Company Internal
Label Make II
Install guideline
Client handbook
Rev
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Label Make II and is the answer not in the manual?

Questions and answers

Related Manuals for Sony Ericsson Label Make II

Summary of Contents for Sony Ericsson Label Make II

  • Page 1 Company Internal Label Make II Install guideline Client handbook...
  • Page 2 Company Internal To be able to run Labelmake II you have to have a service card installed on the pc, the same as for EMMA II. (hardlock is not required). To install Labelmake II use this link: http://emma.extranet.sonyericsson.com/labelmake/ Install Click on and follow the instructions.
  • Page 3 Company Internal...
  • Page 4 Company Internal Click Install !
  • Page 5 Company Internal Click on download !!
  • Page 6 Company Internal Choose Open.
  • Page 7 Company Internal Accept the terms and click Next >...
  • Page 8 Company Internal Choose Typical and click Next >...
  • Page 9 Company Internal This part may take several minutes. So please be patient.
  • Page 10 Company Internal Click Finish To exit the wizard. Click Home...
  • Page 11 Company Internal To start the Labelmake II Client Click either the button or printer logo...
  • Page 12 Company Internal Click Start to continue.
  • Page 13 Company Internal...
  • Page 14 Company Internal This empty page is your first acquaintance with Label Make II Now let see how to print a label……..
  • Page 15 Company Internal One of the new thing with LM2 is that the search is done by the TACnr the six first digits in IMEInr Enter the first set of digits (TAC) from the IMEI number shown on the product label. The TAC may contain six or eight numbers.
  • Page 16 Company Internal Some barcode scanners insert a "22S" or "S" in front of the scanned number. With these characters in front of the number, the search function will not be able to find the correct label in the database. Use the dropdown menu to remove the 22S or S prefix Set this field to prevent the extra...
  • Page 17 Company Internal …the Number of characters in field. Number of chars in field: Selecting a number from this field determines how many characters will be allowed in the "ID" field. If the TAC has six characters, then select 6. If the TAC has eight characters, then select 8. Be careful. If 6 is selected, but a TAC with eight characters is scanned, the last two characters will not show in the "ID"...
  • Page 18 Company Internal After the search you will find Available labels to choose from. - Click on the one you need to print. Offline or Online: Select the "Offline" option to search the labels that have already been downloaded. Be careful. Using the "Offline" option for long periods of time may cause updated labels to be missed.
  • Page 19 Company Internal Choose your label, and some fields will appear...
  • Page 20 Company Internal Label Fields: The label fields that appear for the selected label must all be populated with the correct information from the product label. Position the curser over the field to see a help note appear on the screen. The help notes describe the type of information that goes in the fields.
  • Page 21 Company Internal To correct the information in a separate field use the button to the left of the field to erase the content.
  • Page 22 Company Internal One very good feature when working with batches of the same model is to use the checkbox, this will erase the content In Serial and IMEI – field automatically after the label is printed.
  • Page 23 Company Internal com1: This field allows the Print settings: client to select the Clicking this appropriate com port to button causes which the printer to the printer is connected. Print test label: print a list of Clicking this button its current causes the printer to parameter Calibrate:...
  • Page 24 Company Internal Use this dropdown menus to adjust the layout on the label. When you have chosen a value in the menu, you have to confirm it by tab the button right to the field. ….When do a test print, or go back to the first side “ Label Print” and print a proper label.
  • Page 25 Company Internal If you select “2”. Two labels with the same information will be printed. Use this when you need an extra label for the DPY/Z – box.
  • Page 26 Company Internal...
  • Page 27 Company Internal You could rename the print buttons by using the Rename buttons.
  • Page 28 Company Internal And you could of course set it to default again by using Reset buttons...
  • Page 29 Company Internal Summary of most important new features - Product labels are downloaded online from a remote server database. This is faster and easier than downloading ZIP files from CSPN, so updates are easier to obtain. - Downloaded labels are then cached on the local hard disk and ready to be printed. - One computer can be used to access the database, and it can be a server for other computers -If LabelMake II is used in LAN server mode, files are cached to the directory specified in the LAN setup tab.
  • Page 30 Company Internal Update of the software The client checks automatically if new versions of the LabelMake II software are available whenever you Start Labelmake II online from this internet page: http://emma.extranet.sonyericsson.com/labelmake/...

  • Page 31: Hardware Requirements

    Company Internal Hardware Requirements • Sony Ericsson Service Card: the client requires smart card and its drivers to be installed. • Windows 2000, Windows XP, Windows 98, Windows NT • Best configuration : 128 MB RAM minimum...

  • Page 32: Troubleshooting

    Company Internal Troubleshooting LabelMake II did not install: - Is the correct Java version selected in the Java Web Start Application Manager? In Windows, click "Start/Programs/Java Web Start/Java Web Start". In the Application Manager, click "File/Preferences/Java". Make sure there is a check mark in the "Enable"...
  • Page 33 Company Internal Printers did not install: - Were the printers powered on before launching the application? The application installs printers at start up only if they are powered on. Power on the printer and click the "Refresh printers" button on the "Label Print" screen. - Is the HOST HANDSHAKE in the Zebra printer menu set to XON/XOFF? LabelMake II may have problems finding a printer if the handshake is set to another value.
  • Page 34 Company Internal EMMA II compatibility EMMA II and LabelMake II is installed on the same PC, and EMMA II is not working properly. You may need to disable Sun Java from Internet Explorer. - You do this in: Tools -> Internet options -> Advanced -> Sun Java : disable this if it is enabled.
  • Page 35 Company Internal...
