Using the AMC modules

ASM-FB4 and ADM-XB2 modules

44
Upload rolled files in Select to compress the log files before uploading.
gzipped format
Delete files after Select to remove the log files once the FTP upoad has completed.
uploading

Log configuration using the CLI

Configure the FortiGate unit to log to the ASM-S08 using the CLI within the
FortiAnalyzer command config log disk setting enable.
For details on log configuration, see the FortiGate CLI Reference.

Viewing logs

Logs and content logs stored on the ASM-S08 are available for viewing and
analysis.
To view the FortiGate logs, go to Log&Report > Log Access.
To view the content logs, go to Log&Report > Content Archive. Select the log
type and select Local from the list box.
Note: HA logging is not available with the AMC-S08.
AMC (Advanced Mezzanine Card) modules provide additional hardware
accelerated network processing for certain eligible traffic types passing through
their SFP (small form-factor pluggable) network interfaces. This additional
processing resource frees FortiGate units' main processing resources for other
tasks, improving network performance.
FortiGate-ASM-FB4 modules can improve network throughput for:
• traffic with small packets, such as VoIP
• latency-sensitive traffic, such as streaming multimedia
• traffic with long session lifetimes, such as FTP
• IPSec VPN traffic
• active-active HA load-balanced traffic
• P2P traffic
Eligible traffic processing is off-loaded to the module. This fast path processing
leverages the additional hardware acceleration resources provided by the AMC
modules.
Ineligible traffic processing is processed normally. Normal processing by the
FortiGate unit's main processing resources (CPU, RAM, and FortiASIC content
processor) can include some FortiASIC hardware accelerated processing, but
does not utilize the additional hardware acceleration resources provided by the
modules.

Changing interfaces to operate in SGMII or SerDes mode

SFP transceivers can operate in two modes: SerDes and SGMII (Serial Gigabit
Media Independent Interface). SGMII mode is required if you have SGMII
transceivers. In SGMII mode the interface can operate at 10, 100, or 1000 Mbps.
FortiGate-3600A FortiOS 3.0 MR6 Install Guide
01-30006-0457-20080318
AMC modules
