Web Browser Management
Thank you for purchasing the IntraStack 6014DSB. This document contains important infor-
mation not described in the IntraStack 6014DSB's Quick Installation Guide or User's Manual.
It explains how to manage the IntraStack 6014DSB with a World Wide Web browser.
Overview
The IntraStack 6014DSB has a built-in HTTP (HyperText Transfer Protocol) server. The HTTP
server allows you to configure and manage the IntraStack 6014DSB via any standard World
Wide Web browser (see Table A-1 for a list of supported platforms and browsers).
This document explains the following:
Viewing and Configuring Port Information — page A-4
Web Browsers Supported
Table A-1 lists the World Wide Web browsers supported by the IntraStack 6014DSB.
Platform
PC (Windows™)
Macintosh®
UNIX®
Connecting to the IntraStack 6014DSB
Important:
IntraStack must be configured with an IP address. See "Configuring for Manage-
ment" in Chapter 2 of the IntraStack 6014DSB User's Manual for directions.
The IntraStack 6014DSB Web Browser Management requires a password. This
password is the same as the IntraStack 6014DSB's Console management pass-
word (default is Asante).
Multiple users can simultaneously connect to the IntraStack 6014DSB.
IntraStack 6014DSB Manual Addendum: Web Browser Management
IntraStack
Manual Addendum:
Table A-1 Supported Web Browsers
World Wide Web Browser
Netscape Navigator® v. 3.0 or greater
Microsoft Internet Explorer™
Netscape Navigator® v. 3.0 or greater
Microsoft Internet Explorer™ v. 3.0 or greater
Netscape Navigator® v. 3.00 or greater
To connect to the IntraStack 6014DSB with a Web browser, the
6014DSB
™
P/N 06-00362-00 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IntraStack 6014DSB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asante IntraStack 6014DSB

Summary of Contents for Asante IntraStack 6014DSB

  • Page 1 Thank you for purchasing the IntraStack 6014DSB. This document contains important infor- mation not described in the IntraStack 6014DSB’s Quick Installation Guide or User’s Manual. It explains how to manage the IntraStack 6014DSB with a World Wide Web browser. Overview The IntraStack 6014DSB has a built-in HTTP (HyperText Transfer Protocol) server.
  • Page 2 To connect to the IntraStack 6014DSB with a Web browser: Locate a computer with a functioning World Wide Web browser. Open the Web browser. Type the IP address of the IntraStack 6014DSB at the URL prompt, then press return. The IntraStack 6014DSB login window appears.
  • Page 3 The IntraStack 6014DSB Web Browser Management Page contains an interac- tive front-panel image of the device. Click once on any of the IntraStack 6014DSB’s 12 ports or two MII ports to receive configuration information and statistics for that port. Management Buttons Table A-2 describes the management buttons on the IntraStack 6014DSB Web Browser Management Page.
  • Page 4 Viewing and Configuring Port Information To view current port configuration information or statistics: Click once on a port on the IntraStack 6014DSB image. The Port Configuration/Statistics Page appears for the selected port. Figure A-3 Port Configuration/Statistics Page The information displayed in drop-down menus in the Port Confi guration window is configurable.
  • Page 5 Chapter 6 of the IntraStack 6014DSB User’s Manual. Viewing General Information To view general information on the IntraStack 6014DSB: Click once on the General Info button on the IntraStack 6014DSB Web Browser Management Page. The General Information Page appears. Figure A-4 General Information Page The General Information Page contains configurable and read-only informa-...
  • Page 6 1997 Asanté Technologies, Inc. All rights reserved. Asanté and IntraStack are registered trademarks of Asanté Technologies, Inc. Netscape Navigator is a registered trademark of Netscape Communications Corporation in the United States and other countries. All other brand names and products are trademarks of their respective holders. IntraStack 6014DSB Manual Addendum: Web Browser Management P/N 06-00362-00 Rev. A...
