Running Optitrace

4.1

Overview

This section will describe how to setup and run Optitrace after it has been installed.
4.2

TRdata.xml

For each build of software that is loaded onto the module a file called trdata.xml is
created. The purpose of this file is to tell optitrace what traces have been activated
within the build, without the correct file optitrace will be unable to interpret the
information coming out of the unit. The software revision currently loaded on the
Wireless CPU can be found by typing "AT+CGMR".
Prior to running optitrace the trdata.xml file for the corresponding build on the
module should be placed in the optitrace directory as shown in the windows
explorer screen shot below. Once you have downloaded the file from the extranet,
rename the file to "trdata.xml" and copy it to the directory that holds Optitrace.exe.
If you would like to work with more than one firmware version please review the
Optitrace users manual installed with the application.
