- Page 1 23425 drDock Connections and Quickstart Guide 23425...
-
Page 3: Table Of Contents
Setup ..........................11 Remote control ......................12 Arcam T32....................... 14 Connections ........................14 Remote control ......................15 Arcam AVR360, AVR400, AVR600, AV888 ............16 AVR Connection Example ..................16 Setup — On Screen Display ...................17 Remote control ......................18 Navigation from the Front Panel ................20 Song Selection ......................20 Changing Selection ....................21... -
Page 4: Power Adaptor Setup
Power Adaptor Setup Click! -
Page 5: Docking Your Ipod
Docking your iPod... -
Page 6: Standalone Operation
Standalone operation Connections for any amplifier Amplifier / audio system Connect power adaptor, video cable (HDMI, optional) and audio interconnects. -
Page 7: Remote Control (Cr1)
Remote control (CR1) The supplied remote control can be used to control your iPod when the drDock is not connected to a supported Arcam product. If you are using the drDock with a supported Arcam product, use the Arcam system remote instead. -
Page 8: Arcam Solo Mini
Arcam Solo Mini Connections RS232 CONTROL RIGHT LEFT SPEAKER OUTPUT REMOTE GAME TAPE/iPOD TAPE PRE OUT PROG OFF/ON... -
Page 9: Remote Control
Remote control — Solo Mini INFO Track name Artist name Album name Track no. Volume MODE Repeat track Repeat all Shuffle songs Shuffle albums Shuffle songs repeat all Shuffle albums repeat all Skip forward Play – Skip back solo remote Playback control Play <... -
Page 10: Arcam Solo Neo
Arcam Solo Neo Connections RS232 RS232 solo ZONE 2 ZONE 2 PRE OUT PRE OUT TAPE OUT TAPE OUT TAPE IN iPod GAM E GAM E AV IN AV IN CD OUT CD OUT SERIAL NO . SERIAL NO . -
Page 11: Setup
Setup — Solo Neo solo remote... -
Page 12: Remote Control
Remote control — Solo Neo INFO Track name Artist name Album name Track no. Volume MODE Repeat track Repeat all Shuffle songs Shuffle albums Shuffle songs repeat all Shuffle albums repeat all Skip forward Play – Skip back solo remote Playback control Play <... -
Page 14: Arcam T32
Arcam T32 Connections AUDIO OUT VOLTAGE SELECT 110 -120V 220 - 240V PROGRAM RS232 REMOTE ~60Hz ~50Hz... -
Page 15: Remote Control
Remote control — T32 (CR90) RND (Random play) MACRO SHUFF Shuffle play O Shuffle Songs Shuffle Albums PHONO SHIFT RPT (Repeat play) Repeat play O Repeat Song Repeat Album MODE MODE MENU BAND DISP SIRIUS iPOD VOLUME DIRECT BASS TREBLE Playback control 4 Play 0 Skip back... -
Page 16: Arcam Avr360, Avr400, Avr600, Av888
Arcam AVR360, AVR400, AVR600, AV888 AVR Connection Example... -
Page 17: Setup - On Screen Display
General Setup Auto Setup Spkr Types Spkr Distance Spkr Levels Video Inputs Audio in iPod Video Outputs iPod Accessory Mode rLead rDock Zone Settings > irDock/drDock Select the Arcam iPod accessory Network SHIFT IPOD MODE MENU DISP DIRECT BASS TREBLE... -
Page 18: Remote Control
Remote control — AVR360, AVR400, AVR600, AV888 (CR102) SHIFT+RND = RPT (Repeat play) RND (Random play) PHONO Repeat play O TAPE Shuffle play O Shuffle Songs Repeat Song Shuffle Albums Repeat Album SHIFT IPOD MODE MENU DISP VOLUME DIRECT BASS TREBLE Playback control 4 Play... -
Page 20: Navigation From The Front Panel
Navigation from the Front Panel Song Selection † 7 sec timeout † -/+ = Solo mini remote / = CR50/CR90/CR100/CR102 * Solo Neo, Solo Mini & T32 only... -
Page 21: Changing Selection
Changing Selection † 7 sec timeout † -/+ = Solo mini remote / = CR50/CR90/CR100/CR102 * Solo Neo, Solo Mini & T32 only... -
Page 22: Navigation From The On Screen Display (Avr360, Avr400, Avr600 & Av888 Only)
Navigation from the On Screen Display (AVR360, AVR400, AVR600 & AV888 only) Song Selection Media Audio Video Not Playing Make Selection Playlist Artist Album Genre Song 3 of 9 Not Playing Track Eleanor Rigby/Julia [Transition] Blackbird/Yesterday Lady Madonna All You Need Is Love Track : Eleanor Rigby/Julia [Transition] Artist : The Beatles 00:07... -
Page 23: Changing Selection
Changing Selection Track Eleanor Rigby/Julia [Transition] Blackbird/Yesterday Lady Madonna All You Need Is Love Track : Eleanor Rigby/Julia [Transition] Artist : The Beatles 00:07 Album : Love Make Selection Playlist Artist Album Genre Song 3 of 9 Track : Eleanor Rigby/Julia [Transition] Artist : The Beatles 00:07 Album : Love... -
Page 24: Legal Information
ProdUCt This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modification not expressly approved by ARCAM may void your authority, granted by the FCC, to use the product. 3. note This product has been tested and found to comply with the limits for a Class B digital device, persuant to Part 15 of the FCC Rules. - Page 26 23425 http://www.arcam.co.uk Pembroke Avenue, Waterbeach, CAMBRIDGE, CB25 9QR, England SH244E Iss. 1...
