AT&Cn CD signal control
Defines what the TA outputs as the DCD
(CD) signal on the DTE interface
AT&Dn ER signal control
Defines how the DTR (ER) signal is
interpreted by TA.
AT&F
Recall factory default setting
AT&Kn Flow control
AT&Sn DR signal control
Defines how the DSR (DR) signal is
handled by the TA
AT&Vn Display system configuration
Cause the TA to display its current
configuration
AT&Wn Write user profile
The TA 's active configuration will be
stored into the non-volatile memory as User
profile
AT&Yn Load user configuration when power on
AT&Zn=x Register speed dial number
AT%A2=n Data port protocol selection
Select the protocol on B¡þD channel
AT%A5=n Enbloc/overlap sending mode
Select the sending method for telephone
number (refer also AY*W0, AT*W1)
AT%D Data port setting display
AT%DC Show disconnect cause, source, charge
ISDN Router Manual V.1.1
0
DCD (CD) signal on at all time.
(TA's DCD signal follow PC's
*1
DTR)
DCD (CD) signal on at only
communication time.(DCD signal
high during communication time)
0
DTR signal consider on at all time.
(TA won't detect DTE's DTR, TA
consider DTR is always on)
*2 TA will detect DTE's DTR (ER)
Signal
The factory configuration contained in
the ROM is loaded to become the TA's
configuration.
0
no flow control
*3
hardware flow control (RTS/CTS)
4
software flow control (Xon/Xoff¡^
*0
TA's DSR (DR) signal follows
DTE's
1
DTR
DSR (DR) signal on at only
communication time.
(DSR signal high during
communication time)
0
Displays the current configuration
2
Display Directory Numbers and all
stored phone numbers
0
write user profile 0
1
write user profile 1
0
Use user profile 0 as active Profile
when power up
1
Use user profile 1 as active Profile
when power up
n
n = 0-19
x
x = telephone number
1
V.110
2
V.120
4
X.25 on D
8
X.75
14
Channel Bundling
*0
Overlap sending
The dialing telephone will be sent to
network after TA detect the ending
1
digit
Enbloc sending
The dialing telephone number will
be sent to network immediately
whenever the user dialing each digit
Display all corresponding setting
Display the disconnect reason and
connection fee
