AG Neovo WMK-02 Specifications

Any display can be quickly converted from
landscape to profile display orientation
Thin-profile design requires a mere 12 mm of
distance between wall and display
www.agneovo.com
WMK-02
Maximize space in any environment with
the convenient WMK-02 Wall Mount Kit.
The sturdy WMK-02 allows for easy mounting of any VESA compliant
display, and for convenient rotation between profile or landscape display
orientations. Made from high-grade anodised steel, this 1-piece bracket
is rust resistant and can accommodate displays weighing up to 18 kg. The
WMK-02 is perfect for environments such as classrooms, lobbies, retail
outlets, as well as outdoor kiosks and other public areas where space is
at a premium.
> Easy-to-use 1-piece bracket design
> Simple manual adjustment allows mounted display to rotate into a landscape or
profile configuration
> Space saving 12 mm depth
> High quality steel construction
> Anodised surface prevents rust
> Suitable for indoor/outdoor environments
> VESA standard design
> Accommodates LCD displays up to 18.0 kg (40.0 lbs)

Specifications

90
0
Bracket
Mounting
Loading
Pivot
Exterior

Dimensions

Weight
Packing
Accessories
X-
Design 1 pc
Display VESA FPMPMI Standard
(75 x 75 mm & 100 x 100 mm)
Weight Capacity 18.0 kg (40.0 lbs)
Display Swivel Manual (0°, 90°, 180° & 270°)
Material Steel
Surface Finish Electronic finish
Colour Black
Product 120 x 120 x 16.6 mm
(W x H x D) (4.7" x 4.7" x 0.7")
Packaging 140 x 160 x 27 mm
(W x H x D) (5.5" x 6.3" x 1.1")
Product Weight 0.28 kg (0.62 lbs)
Packaged Product Weight 0.35 kg (0.77 lbs)
1 Carton 30 Sets
1 Pallet 1200 Sets
Supplied User manual, screw A TA-19 mm (x3),
screw B M4-20 mm (x4),
wall anchors (x3)
All specifications are subject to change without prior notice.
Copyright © 2008 AG Neovo. All rights reserved. The name AG Neovo is a trademark of AIC.
All other trademarks are the property of their respective owners.
P/C: WMK020 Version 2.0, 20080530
