Appendix 7 – Cable and connector specifications

RS232 serial mouse to PS/2 converter cable

6pin mini-DIN
female
5
CLK
1
DAT
2
TXD
3
GND
4
+5V
6
-12V
Female
5 6
3 4
1 2
9pin D-type
female
1
DCD
NC
2
RXD
5
GND
4
DTR
6
DSR
7
RTS
3
TXD (-12V)
8
CTS
NC
9
RI
NC

AdderLink IP to power switch cable

9pin D-type female

Power switch to power switch daisy chain cable

4pin RJ9
4pin RJ9
4pin RJ9
61
